Chassis Transformer Range
Features:
•
•
•
•
•
•
•
Made in the UK
Power: 6 ~ 2KVA 50/60Hz
High Quality Transformer
Double section metric bobbins
Temperature Class: - Class B (130
O
C)
Dielectric Strength: 3750Vrms
Manufactured and tested in accordance to
EN61558, EN60950, CE
VA Rating
6
12
20
25
50
75
100
150
200
Tolerance
250-2000
Dimension (mm) Excluding Tags
Reg %
A
B
C
D
E
F
G
H
I
J
K
Weight (g)
24
16
12
10
9
8
10
9
8
2
55
74
74
83
94
102
102
-
-
+/-1
68
90
90
97
106
118
118
-
-
+/-1
37
50
50
58
65
75
75
-
-
+/-1
45
60
60
69
79
89
89
-
-
+/-1
36
45
52
53
58
65
65
-
-
+/-1
-
-
-
-
-
-
-
62
68
+/-1
-
-
-
-
-
-
-
63
72
+/-1
-
-
-
-
-
-
-
49
56
+/-1
-
-
-
-
-
-
-
88
102
+/-1
-
-
-
-
-
-
-
74
85
+/-1
-
-
-
-
-
-
-
78
85
+/-1
170
390
530
675
985
1400
1550
2100
2750
approx
D0003 Issue 2
Please contact us to discuss your requirements
Please contact Vigortronix for any enquires. Products can be altered to suit custom requirements.
The information contained in this document is subject to change without notice.
Vigortronix
, 16 De Havilland Way, Witney, Oxfordshire, OX29 0YG, UK
T
el. +44 (0)1993 777570 Fax. +44 (0)1993 777580
Web. www.vigortronix.com E-mail: sales@vigortronix.com
