TE Connectivity quality and reliability are guaranteed in this range of insulated and
shielded RF Inductors. The insulated range has a self-extinguishing polyolefin sleeve.
Their small size make them ideal for use when space is at a premium. And they are also
fully protected from environmental factors. Electrostatic and electromagnetic screening is
provided by the magnetic enclosure. A wide range of values are available and the self
extinguishing polyolefin sleeve enhances environmental protection. The SC series was
originally designed for military applications but now has widespread industrial use.
Characteristics - Electrical
SC15
SC30
SC55
See Table - E12 Grid
(Non-standard values available to special order)
Selection Tolerance:
±10%
±10%
±10%
±10%
Power Rating at 70°C:
0.33W
See Below
0.25W
0.30W
Isolation Voltage:
700V DC or AC peak
Limits of Inductance Change:
5% after 1000 hours endurance
Operating Temperature Range:
-55°C to +100°C
-55°C to +100°C -55°C to +100°C
-55°C to +125°C
Recommended Storage Temperature:
0°C to +35°C
Climatic Category:
55/100/21
55/100/21
55/100/21
55/125/21
Inductance Range:
SC15 Power Rating Values between 0.15uH and 4.7uH - Power Rating 0.33 Watt
Values between 5.6uH and 330uH - Power Rating 0.20 Watt
SC10
Packaging and Marking
Type
SC10
SC15
SC30
SC55
Ammo Pack
500 Pieces
500 Pieces
500 Pieces
500 Pieces
Reeled
1500 Pieces
1500 Pieces
2500 Pieces
1500 Pieces
Weight per Component
–
–
–
0.6g
Marking
LC10
LC15
LC30
LC55
Dimensions
Size
SC10
SC15
SC30
SC55
L Max.
10.0mm
10.0mm
7.0mm
11.4mm
D Max.
4.2mm
4.5mm
2.8mm
5.2mm
l Min.
25mm
30mm
25mm
30mm
d
0.6mm
0.6mm
0.5mm
0.6mm
1773282 CIS BI 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Axial Leaded Power Inductors
Type SC10, SC15, SC30, SC55 Series
Characteristics - Electrical - Type SC10 - Section 1
Inductance
Value - μH
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
Inductance
Code
R10
R12
R15
R18
R22
R27
R33
R39
R47
R56
R68
R82
1R0
1R2
1R5
1R8
2R2
2R7
3R3
Test Freq.
MHz
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
Q Factor
Min.
50
50
50
50
50
50
50
50
50
50
45
45
45
32
32
32
32
32
32
S.R.F.
MHz Min.
500
475
450
425
400
380
360
330
300
280
260
235
210
190
170
156
140
125
115
Max. DC
Direct Current
Resistance
at 70°C
Ohms at 20°C
Max. mA
0.055
0.060
0.065
0.070
0.075
0.085
0.095
0.11
0.12
0.14
0.16
0.26
0.30
0.50
0.60
0.75
1.10
1.40
1.90
2060
1970
1900
1830
1770
1660
1570
1460
1390
1290
1210
950
880
685
625
560
460
410
350
Type SC10 - Section 2
Inductance
Value - μH
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
Inductance
Code
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
Test Freq.
MHz
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
Q Factor
Min.
45
45
45
45
45
45
55
55
55
55
55
55
55
55
S.R.F.
MHz Min.
75
65
60
55
50
45
40
35
30
27
25
22
20
18
Max. DC
Resistance
Ohms at 20°C
0.25
0.35
0.40
0.55
0.75
0.9
1.1
1.5
2.7
3.0
4.5
5.2
7.5
9.6
Direct Current
at 70°C
Max. mA
970
820
765
650
560
510
460
395
295
280
230
210
175
156
Type SC10 - Section 3
Inductance
Value - μH
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Inductance
Code
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
Test Freq.
MHz
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
Q Factor
Min.
55
55
50
50
40
40
45
45
45
45
45
45
45
45
45
40
S.R.F.
MHz Min.
11
10
8.5
7.0
6.5
5.5
5.0
4.2
3.8
3.3
3.1
2.9
2.7
2.5
2.3
2.2
Max. DC
Direct Current
Resistance
at 70°C
Ohms at 20°C
Max. mA
8.1
9.0
10.0
11.0
12.0
13.0
15.0
17.0
19.5
22.0
24.5
26.5
30.0
33.0
36.5
40.0
170
161
153
146
140
134
125
117
110
103
98
94
88
84
80
76
Section 1 was formerly the TE Connectivity C10 Series, Section 2 was formerly the TE Connectivity C11 Series,
Section 3 was formerly the TE Connectivity C12 Series
1773282 CIS BI 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Axial Leaded Power Inductors
Type SC10, SC15, SC30, SC55 Series
Characteristics - Electrical
Type SC15
Inductance
Value - μH
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
24*
27
30
33
36*
39
43*
47
51*
56
62*
68
75*
82
91*
100
110*
120
130*
150
160*
180
200*
220
240*
270
300*
330
Inductance
Code
R15
R18
R22
R27
R33
R39
R47
R56
R68
R82
1R0
1R2
1R5
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
240*
270
300
330
360*
390
430*
470
510*
560
620*
680
750*
820
910*
101
111*
121
131*
151
161*
181
201*
221
241*
271
301*
331
Test Freq.
MHz
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
Q Factor
Min.
50
45
50
45
45
45
45
50
50
50
50
33
33
33
33
33
33
33
33
45
50
50
55
65
65
75
75
60
60
65
65
60
60
60
55
55
55
55
55
55
50
50
50
60
65
65
65
65
65
65
65
65
65
65
65
S.R.F.
MHz Min.
525
480
450
400
360
350
310
280
250
220
200
180
160
150
135
120
110
100
90
60
55
50
45
42
40
34
30
27
25
21
19
15.5
14.5
13.7
13.0
12.7
12.0
11.5
11.0
10.5
10.3
10.0
9.5
8.9
8.7
8.5
8.0
7.5
7.0
6.5
6.2
5.9
5.7
5.4
5.1
Max. DC
Direct Current
Resistance
at 70°C
Ohms at 20°C
Max. mA
0.030
0.040
0.055
0.070
0.090
0.100
0.120
0.135
0.15
0.22
0.29
0.42
0.50
0.65
0.95
1.20
2.00
2.30
2.60
0.32
0.50
0.60
0.90
1.10
1.40
2.25
2.50
2.50
2.60
2.80
3.00
2.50
2.60
2.70
2.75
2.85
3.00
3.15
3.30
3.70
3.90
4.30
4.50
4.90
5.20
5.45
6.05
6.40
6.75
7.10
7.45
7.80
9.00
11.50
12.50
2790
2420
2060
1830
1610
1530
1400
1320
1250
1030
900
750
685
600
495
440
340
320
300
690
550
505
415
375
330
260
250
250
242
230
227
250
244
238
235
231
225
220
215
203
200
188
185
176
170
167
160
154
150
147
144
140
131
118
111
1773282 CIS BI 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Axial Leaded Power Inductors
Type SC10, SC15, SC30, SC55 Series
Characteristics - Electrical
Type SC30
Inductance
Value - μH
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Inductance
Code
R022
R027
R033
R039
R047
R056
R068
R082
R10
R12
R15
R18
R22
R27
R33
R39
R47
R56
R68
R82
1R0
1R2
1R5
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
Test Freq.
MHz
50
50
50
50
50
50
50
50
25
25
25
25
Q Factor
Min.
33
33
33
33
33
33
33
33
40
40
38
35
S.R.F.
MHz Min.
1245
1200
1175
1130
1060
990
900
750
680
640
600
550
Max. DC
Direct Current
Resistance
at 70°C
Ohms at 20°C
Max. mA
0.006
0.010
0.026
0.033
0.038
0.048
0.055
0.065
0.080
0.090
0.10
0.12
3000
2800
2620
2320
2170
1930
1800
1650
1490
1400
1330
1210
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
33
33
30
30
30
30
28
28
25
25
28
30
30
37
45
45
45
50
50
55
55
45
45
50
50
50
45
45
45
45
50
50
50
30
30
30
30
30
30
30
30
30
30
30
30
510
430
410
365
330
300
275
250
230
150
140
125
115
100
90
80
75
65
60
55
50
40
35
30
25
20
24
22
20
18
15
14
13
12
11
10
9
8
7
6.5
6
5
4
3.8
3.4
0.14
0.16
0.22
0.30
0.35
0.50
0.60
0.85
1.00
0.18
0.22
0.30
0.40
0.55
0.85
1.0
1.2
1.8
2.0
2.7
3.7
2.7
2.8
3.1
3.3
3.5
3.4
3.6
4.5
5.7
6.7
7.3
8.0
13.0
15.0
17.0
21.0
25.0
28.0
35.0
42.0
46.0
60.0
65.0
72.0
1120
1050
900
770
710
595
540
455
420
990
895
765
665
565
455
420
384
314
298
256
219
256
251
239
232
225
228
222
198
176
162
156
149
116
108
102
92
84
79
71
65
62
54
52
49
The SC30 Series was formerly the TE Connectivity C30 Series
1773282 CIS BI 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Axial Leaded Power Inductors
Type SC10, SC15, SC30, SC55 Series
Characteristics - Electrical
Type SC55
Inductance
Value (μH)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
Inductance
Code
1R0
1R5
2R2
3R3
4R7
6R8
100
150
220
330
470
680
101
151
221
331
471
681
102
Q
Min.
45
65
60
50
50
60
50
55
65
85
70
65
65
80
80
80
80
85
85
Test Freq
MHz
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
S.R.F.
MHz Min.
190.0
155.0
130.0
110.0
95.0
85.0
65.0
55.0
45.0
35.0
20.0
16.0
14.0
9.5
8.0
7.5
6.5
5.0
3.0
Max. DC
Resistance
Ohms
0.04
0.05
0.06
0.07
0.12
0.22
0.35
0.60
1.10
2.00
2.50
3.00
4.00
5.80
7.30
12.00
20.00
24.00
30.00
Direct Current
Body
at 85°C
Marking
Max. mA
2200
2000
1800
1700
1300
1000
750
600
430
300
270
250
220
230
200
160
120
110
100
1uH0-K
1uH5-K
2uH2-K
3uH3-K
4uH7-K
6uH8-K
10uH-K
15uH-K
22uH-K
33uH-K
47uH-K
68uH-K
mH10-K
mH15-K
mH22-K
mH33-K
mH47-K
mH68-K
1mH0-K
How to Order
SC30
Common Part
SC10
SC15
SC30
SC55
Please state code given
in data above
R - Reeled
K - 10%
T - Ammo Pack
104
Inductance Value
K
Tolerance
T
Packaging
TE Connectivity, TE connectivity (logo) and TE (logo) are trademarks.
Other logos, product and Company names mentioned herein may be trademarks of their respective owners.
While TE has made every reasonable effort to ensure the accuracy of the information in this datasheet, TE does not guarantee that it is error-free, nor does TE make any other
representation, warranty or guarantee that the information is accurate, correct, reliable or current. TE reserves the right to make any adjustments to the information contained herein
at any time without notice. TE expressly disclaims all implied warranties regarding the information contained herein, including, but not limited to, any implied warranties of merchantabili-
ty or fitness for a particular purpose. The dimensions in this datasheet are for reference purposes only and are subject to change without notice. Specifications are subject to change
without notice. Consult TE for the latest dimensions and design specifications.
[i=s]This post was last edited by jameswangsynnex on 2015-3-3 19:58[/i] Although the "hidden rules" in the PC processor industry have long been an "open secret", Mao Junbiao, vice president of Hedy's ...
TI's zigbee protocol stack has problems when porting from LM3S8962 to LM3S3739? Can anyone tell me what the reason is? The picture is in the attachment, and it will not upload the picture....
[color=#333333]I would like to ask the experts whether OPT101 is used to measure the frequency of incident light. Does it output different voltages for incident light of different frequencies or outpu...
The two most important indicators for evaluating the quality of synthesis are whether the speed is fast and whether the area is small; synplify is a logic synthesis tool specifically for FPGA/ CPLD ; ...
It snowed this morning like foam plastic, sticking to pedestrians and hair. It didn’t fall off or melt for a long time. It reminded me of the costume movies from Hong Kong and Taiwan when I was a kid....
Raspberry Pi 4 IP address setting, source replacement, adding power button and heat dissipation.
1. Fixed IP address setting
After the Raspberry Pi is installed, it will automatically obtain an IP add...
1. Several nouns
ABI:
The specifications that an executable file must follow in order to run in a specific execution environment;
Separately generated relocatabl...[Details]
1. Equipment Overview
Shell-and-tube heat exchangers are a common heat exchange device used in chemical evaporation and heating equipment. Currently, the tubesheets of shell-and-tube heat exch...[Details]
The mass production process of the new generation of cockpit platform has started, and the smart cockpit market has entered a new bonus cycle of technology iteration and platform upgrade.
...[Details]
Whether it is an electric car or an ordinary fuel car, for the vast majority of car buyers, the final cost of use is what they care about most. For fuel cars, how to save fuel is what drivers care ...[Details]
Current Development Status of DVR Market
A DVR, or digital video recorder, uses a hard disk for recording, unlike traditional analog video recorders. It's often called a DVR because it's a com...[Details]
White light LEDs are voltage-sensitive devices. In actual operation, their upper limit is 20mA. However, the current often increases due to various reasons during use. If no protective measures are...[Details]
Amidst the wave of intelligent automotive transformation, advanced driver assistance is gradually emerging from cutting-edge technology into the mainstream, becoming a new frontier of industry comp...[Details]
The Automotive Testing and Quality Assurance Expo (ATE 2025) will open on August 27th. At the expo, Rohde & Schwarz (R&S) will showcase six automotive testing solutions, themed "Intelligently Drivi...[Details]
For autonomous vehicles to safely navigate the road, they must identify far more complex objects than just traffic lights, pedestrians, and other familiar objects. Among these obstacles is a crucia...[Details]
Since its invention in the mid-1940s, the microwave oven has evolved from a humble beginning to commercial use, entering homes in the 1960s and rapidly gaining popularity. Its basic functionality a...[Details]
Charging is a familiar process for new energy vehicles, and as a source of battery energy, charging piles are crucial. New energy vehicle charging can be divided into fast charging and slow chargin...[Details]
During daily operation of an R-type power transformer, the voltage used varies as the equipment being used adjusts. This raises the question: can the transformer change voltage at this point? The a...[Details]
According to foreign media reports, Ford Motor has applied to the U.S. Patent and Social Security Office (USPTO) for a patent for a door anti-collision system that may be used in future Ford vehicl...[Details]
To improve the lateral active safety of intelligent connected vehicles, the identification and definition of unexpected functional safety scenarios for the EPS (Electronic Steering System) ...[Details]
With growing environmental awareness, the continuous improvement of three-electric technology and the increasing deployment of infrastructure such as charging stations, the electrification of new e...[Details]
Mobile and portable
京公网安备 11010802033920号
EEWORLD
