319-138
"Wide Mouth" Composite Swing-Arm Strain Relief
with Shield Sock and
Self-Locking Rotatable Coupling
Finish Symbol
(See
Table III)
Composite
Backshells
CONNECTOR DESIGNATOR:
A
A
F
H
MIL-DTL-5015, -26482 Series II, and
-83723 Series I and III
MIL-DTL-38999 Series I, II
(see note 3)
MIL-DTL-38999 Series III and IV
Product Series
319
- EMI/RFI Shield
Sock Assemblies
Custom Braid Length
Specify In Inches
(Omit for Std. 12" Length)
Connector Designator
A, F, and H
Optional Braid Material
B
- See Table IV for Options
(Omit for Std. Nickel/Copper)
SELF-LOCKING
ROTATABLE COUPLING
319
H
138
Basic Part
Number
XB
15
B
R - 8
B
LOW PROFILE
Connector
Shell Size
(See
Table II)
Split Ring / Band Option
Split Ring (687-749) and Band
(600-052-1) supplied with
R
option
(Omit
for none)
Anti-Rotation Device
EMI Shroud
12.00 Min
Standard Shield Length
J
G
C
K
E
Closed
Screw Locks Arm
in 45° Increments
H
F
D
Crimp Ring
Standard Shield
IAW 107-030 Ni/Cu
(See Table III for
optional materials) Self-Locking
Hardware
.062 Min
.250 Max
Screw Protrusion
E
Clamp Body, Arm,
Coupling Nut and
Saddles: Black Color
Termination Area
Free of Cadmium
Detail B
Finish XN
Cross Recessed
Screw Head
Same Side
F
L Between
Body Ears
Split Ring
(687-749)
Band
(600-052-1)
G
© 2009 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-24
REV 22 NOVEMBER 2013
with Shield Sock and
Self-Locking Rotatable Coupling
TABLE II: SHELL SIZE
Shell Size
A, F
08
10
12
14
16
18
20
22
24
H
09
11
13
15
17
19
21
23
25
E
± .031
.350 (8.9)
.436 (11.1)
.636 (16.2)
.706 (17.9)
.790 (20.1)
.872 (22.1)
F
Min
.350 (8.9)
G
Max
± .06
H
± .060
J
Max
.94 (23.9)
.97 (24.6)
1.03 (26.2)
1.09 (27.7)
1.12 (28.4)
1.15 (29.2)
1.18 (30.0)
1.25 (31.8)
1.28 (32.5)
L
Max
.393 (10.0)
.455 (11.6)
.598 (15.2)
.710 (18.0)
.839 (21.3)
.934 (23.7)
1.068 (27.1)
K
Diameter
A Code
.265 (6.7)
.370 (9.4)
.506 (12.9)
.580 (14.7)
.705 (17.9)
.784 (19.9)
.909 (23.1)
F Code
.275 (7.0)
.412 (10.5)
.526 (13.4)
.651 (16.5)
.776 (19.7)
.872 (22.1)
1.007 (25.6)
H Code
.264 (6.7)
.390 (9.9)
.504 (12.8)
.630 (16.0)
.756 (19.2)
.843 (21.4)
.969 (24.6)
1.045 (26.5) .936 (23.8)
.455 (11.6) 1.045 (26.5) 1.172 (29.8)
.640 (16.3) 1.170 (29.7) 1.406 (35.7)
.710 (18.0) 1.170 (29.7) 1.500 (38.1)
.835 (21.2) 1.295 (32.9) 1.562 (39.7)
.922 (23.4) 1.295 (32.9) 1.687 (42.8)
.996 (25.3) 1.008 (25.6) 1.467 (39.5) 1.969 (50.0)
1.060 (26.9) 1.197 (30.4) 1.467 (39.5) 2.094 (53.2)
1.123 (28.5) 1.323 (33.6) 1.461 (37.1) 2.281 (57.9)
1.197 (30.4) 1.034 (1.034) 1.132 (28.8) 1.091 (27.7)
1.323 (33.6) 1.149 (29.2) 1.257 (31.9) 1.217 (30.9)
TABLE III: FINISH
Symbol
XB
Finish
Composite Material–No Plating,
Color Black, Brass Interface Shroud
and Adapter–Nickel Plated
2000 Hour Corrosion Resistant
Ni-PTFE, Nickel-Fluorocarbon
Polymer.
1000 Hour Grey
TM
Composite Material–No Plating,
Color Black and Brown, Brass
Interface Shroud and Adapter–
Selectively Cadmium Plated
(See Detail B)
TABLE IV: BRAID TYPE
Symbol
A
B
L
Standard
T
Braid Type
100% AmberStrand
®
75%/25% AmberStrand
®
Blend
100% ArmorLite
TM
XMT
Nickel/Copper 34awg
Tin/Copper 34awg
XN
NOTES
1.
2.
3.
4.
See Table I in Intro for front-end dimensional details.
See composite thermoplastic shield sock assembly procedure for detailed installation instructions.
Add mod code -475 to end of part number for use with Series II connectors. Backshell to be supplied less shroud.
Coupling nut supplied unplated.
© 2009 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-25
Rev. 12 FEBRUARY 2013
Composite
Backshells
319-138
"Wide Mouth" Composite Swing-Arm Strain Relief
A
B
C
D
E
F
G
