660C, 660R
www.vishay.com
Vishay Cera-Mite
High Voltage Ceramic DC Disc Capacitors with Axial Leads,
10 kV
DC
to 30 kV
DC
FEATURES
• Class 1 and class 2 ceramic
• High insulation resistance
• Epoxy encapsulated
• Wide capacitance range
• Ceramic singlelayer capacitor
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Available
DESIGN SUPPORT TOOLS
Models
Available
click logo to get started
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
QUICK REFERENCE DATA
DESCRIPTION
Ceramic Class
Ceramic Dielectric
Voltage (V
DC
)
Min. Capacitance (pF)
Max. Capacitance (pF)
Mounting
1
N4700 (T3M)
15 000 20 000
390
220
1500
1000
VALUE
2
X7R
15 000 20 000
100
100
3900
2700
Axial
2
Z5U
15 000 20 000
1000
680
6800
5000
10 000
470
2000
30 000
180
680
10 000
180
4700
30 000
100
2000
10 000
1500
10 000
30 000
470
3300
MARKING
Capacitance value and tolerance, rated DC voltage, T/C
code, production date code, CM mark.
OPERATING TEMPERATURE RANGE
-30 °C to +85 °C
RATED VOLTAGE
MATERIAL
Capacitor elements made from class 1 or class 2 ceramic in
a molded case, high temperature epoxy construction.
Leads: tinned copper clad steel.
(1)
DIELECTRIC STRENGTH
150 % of rated voltage (in dielectric fluid), charging current
limited to 50 mA.
N4700 (T3M):
2 x 10
-3
(1 kHz)
X7R, Z5U:
20 x 10
-3
(1 kHz)
Standard version
• 660C10A### 10 kV
DC
(3.5 kV
RMS
)
• 660C15A### 15 kV
DC
(5.6 kV
RMS
)
• 660C20A### 20 kV
DC
(7.0 kV
RMS
)
• 660C30A### 30 kV
DC
(10.6 kV
RMS
)
RoHS compliant version
• 660R10A### 10 kV
DC
(3.5 kV
RMS
)
• 660R15A### 15 kV
DC
(5.6 kV
RMS
)
• 660R20A### 20 kV
DC
(7.0 kV
RMS
)
• 660R30A### 30 kV
DC
(10.6 kV
RMS
)
Note
(1)
All kV
RMS
values up to 60 Hz
DISSIPATION FACTOR tan
INSULATION RESISTANCE
Min. 200 000 M, at 180 V
DC
or 1000
F
DIMENSIONS
in millimeters (inches)
Tinned Copper Clad
Steel
20 AWG 0.80 (0.032)
Min. 32 (1.250)
H max.
D max.
Revision: 29-Mar-18
Document Number: 22209
1
