Type AHA
SMT Aluminum Electrolytic Capacitors -55 °C to +105 °C - Long Life
Long Life Filtering, Bypassing, Power Supply Decoupling
Type AHA Capacitors deliver twice the life of many
SMT aluminum capacitor types, and they handle
high levels of ripple current. The AHA can handle the
ripple current of Type AVS at 20 °C higher tempera-
ture. The vertical cylindrical cases facilitate automatic
mounting and reflow soldering and Type AHA offers a
significant cost savings over tantalum capacitors.
Highlights
•
•
•
+105 °C, Up to 2000 Hour Load Life
Capacitance Range: 0.1 µF to 1500 µF
Voltage Range: 6.3 Vdc to 100 Vdc
Specifications
OperatingTemperature:
Rated Voltage:
Capacitance:
D.F. (@ 20 °C):
Capacitance Tolerance:
Leakage Current:
Ripple Current Multipliers:
−55 °C to +105 °C
6.3, 10, 16, 25, 35, 50, 63 & 100 Vdc
0.1 µF to 1500 µF
See Ratings Table
20% @ 120 Hz and +20 °C
0.01 CV or 3 µA @ +20°C after two minutes (whichever is greater)
Frequency
50/60 Hz
0.7
120 Hz
1
1 kHz
1.3
10 kHz & up
1.7
Load Life:
1000 h @ +105 °C, 4.0 - 6.3 mm dia.
2000 h @ +105 °C, 8.0 - 10.0 mm dia.
∆ Capacitance ±20%
DF: < 200% of limit
DCL: ≤100% of limit
W.V. Vdc
–25 °C /+20 °C
–40 °C /+20 °C
6.3
4
8
10
3
6
16
2
4
25
2
4
Shelf Life:
1000 h @ +105 °C
∆ Capacitance ±20%
DF: < 200% of limit
DCL: ≤100% of limit
Maximum Impedance Ratio at 120 Hz
35
2
3
50
2
3
63
3
4
100
3
4
AHA Series Marking
Outline Drawing
Indicator for lead
free product
(black square)
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type AHA
SMT Aluminum Electrolytic Capacitors -55 °C to +105 °C - Long Life
Case Dimen-
Case
Code
B
C
D
X
E
F
G
D ± 0.5
4
5
6.3
6.3
8
8
10
L
5.4 +.1,-.2
5.4 +.1,-.2
5.4 +.1,-.2
7.7 ±.3
6.2 ±.3
10.2 ±.3
10.2 ±.3
A ± 0.2
4.3
5.3
6.6
6.6
8.3
8.3
10.3
H (max) I (ref)
5.5
6.5
7.8
7.8
9.5
10
12
1.8
2.2
2.6
2.6
3.4
3.4
3.5
W
0.65 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.90 ± 0.2
0.90 ± 0.2
P (ref)
1
1.5
1.8
1.8
2.2
3.1
4.6
K
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.70 ± 0.20
0.70 ± 0.20
Ratings
Cap
(µF)
22.0
33.0
47.0
47.0
100.0
100.0
220.0
330.0
330.0
470.0
1000.0
1000.0
1500.0
22.0
33.0
33.0
47.0
100.0
100.0
220.0
220.0
470.0
470.0
1000.0
10.0
22.0
22.0
33.0
47.0
47.0
100.0
220.0
220.0
220.0
330.0
330.0
470.0
470.0
4.7
10.0
10.0
22.0
22.0
33.0
33.0
47.0
47.0
100.0
100.0
220.0
220.0
330.0
330.0
470.0
Catalog
Part Number
AHA226M06B12T-F
AHA336M06B12T-F
AHA476M06B12T-F
AHA476M06C12T-F
AHA107M06C12T-F
AHA107M06D16T-F
AHA227M06D16T-F
AHA337M06X16T-F
AHA337M06F24T-F
AHA477M06F24T-F
AHA108M06F24T-F
AHA108M06G24T-F
AHA158M06G24T-F
AHA226M10B12T-F
AHA336M10B12T-F
AHA336M10C12T-F
AHA476M10C12T-F
AHA107M10D16T-F
AHA107M10E16T-F
AHA227M10X16T-F
AHA227M10F24T-F
AHA477M10F24T-F
AHA477M10G24T-F
AHA108M10G24T-F
AHA106M16B12T-F
AHA226M16B12T-F
AHA226M16C12T-F
AHA336M16C12T-F
AHA476M16C12T-F
AHA476M16D16T-F
AHA107M16D16T-F
AHA227M16X16T-F
AHA227M16F24T-F
AHA227M16G24T-F
AHA337M16F24T-F
AHA337M16G24T-F
AHA477M16F24T-F
AHA477M16G24T-F
AHA475M25B12T-F
AHA106M25B12T-F
AHA106M25C12T-F
AHA226M25C12T-F
AHA226M25D16T-F
AHA336M25C12T-F
AHA336M25D16T-F
AHA476M25D16T-F
AHA476M25E16T-F
AHA107M25E16T-F
AHA107M25F24T-F
AHA227M25F24T-F
AHA227M25G24T-F
AHA337M25F24T-F
AHA337M25G24T-F
AHA477M25G24T-F
Max
DCL
2 min.
(µA)
3.0
3.0
3.0
3.0
6.3
6.3
13.9
20.8
20.8
29.6
63.0
63.0
94.5
3.0
3.3
3.3
4.7
10.0
10.0
22.0
22.0
47.0
47.0
100.0
3.0
3.5
3.5
5.3
7.5
7.5
16.0
35.2
35.2
35.2
52.8
52.8
75.2
75.2
3.0
3.0
3.0
5.5
5.5
8.3
8.3
11.8
11.8
25.0
25.0
55.0
55.0
82.5
82.5
117.5
Max
DF
120 Hz /20 ºC
0.30
0.35
0.35
0.30
0.35
0.30
0.35
0.30
0.35
0.35
0.35
0.35
0.35
0.30
0.30
0.22
0.30
0.30
0.26
0.22
0.26
0.26
0.26
0.26
0.16
0.26
0.16
0.26
0.26
0.16
0.26
0.16
0.20
0.20
0.20
0.20
0.20
0.20
0.14
0.20
0.14
0.20
0.14
0.20
0.14
0.20
0.16
0.16
0.16
0.16
0.16
0.16
0.16
0.16
Max
Max
ESR
Ripple Current
120 Hz /20 ºC
120 Hz /105 °C
(
Ω
)
(mA)
6.3 Vdc ( 8 Vdc Surge)
22.6
29
17.6
29
12.3
36
10.6
46
5.8
47
5.0
71
2.6
74
1.5
105
1.8
230
1.2
300
0.6
300
0.6
400
0.4
480
10 Vdc ( 13 Vdc Surge)
22.6
28
15.1
29
11.1
43
10.6
43
5.0
70
4.3
110
1.7
105
2.0
160
0.9
200
0.9
270
0.4
580
16 Vdc ( 20 Vdc Surge)
26.5
28
19.6
28
12.1
39
13.1
35
9.2
39
5.6
70
4.3
70
1.2
105
1.5
150
1.5
210
1.0
170
1.0
230
0.7
190
0.7
340
25 Vdc ( 31 Vdc Surge)
49.4
22
33.2
22
23.2
28
15.1
35
10.6
55
10.0
42
7.0
65
7.1
70
5.6
91
2.7
91
2.7
130
1.2
160
1.2
190
0.8
180
0.8
340
0.6
360
Case
Code
B
B
B
C
C
D
D
X
F
F
F
G
G
B
B
C
C
D
E
X
F
F
G
G
B
B
C
C
C
D
D
X
F
G
F
G
F
G
B
B
C
C
D
C
D
D
E
E
F
F
G
F
G
G
Size
DxL
(mm)
4 x 5.4
4 x 5.4
4 x 5.4
5 x 5.4
5 x 5.4
6.3 x 5.4
6.3 x 5.4
6.3 x 7.7
8 x 10.2
8 x 10.2
8 x 10.2
10 x 10.2
10 x 10.2
4 x 5.4
4 x 5.4
5 x 5.4
5 x 5.4
6.3 x 5.4
8 x 6.2
6.3 x 7.7
8 x 10.2
8 x 10.2
10 x 10.2
10 x 10.2
4 x 5.4
4 x 5.4
5 x 5.4
5 x 5.4
5 x 5.4
6.3 x 5.4
6.3 x 5.4
6.3 x 7.7
8 x 10.2
10 x 10.2
8 x 10.2
10 x 10.2
8 x 10.2
10 x 10.2
4 x 5.4
4 x 5.4
5 x 5.4
5 x 5.4
6.3 x 5.4
5 x 5.4
6.3 x 5.4
6.3 x 5.4
8 x 6.2
8 x 6.2
8 x 10.2
8 x 10.2
10 x 10.2
8 x 10.2
10 x 10.2
10 x 10.2
Quantity
per Reel
2000
2000
2000
1000
1000
1000
1000
900
500
500
500
500
500
2000
2000
1000
1000
1000
1000
900
500
500
500
500
2000
2000
1000
1000
1000
1000
1000
900
500
500
500
500
500
500
2000
2000
1000
1000
1000
1000
1000
1000
1000
1000
500
500
500
500
500
500
CDE Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8561
•
Fax: (508)996-3830
•
www.cde.com
Type AHA
SMT Aluminum Electrolytic Capacitors -55 °C to +105 °C - Long Life
Cap
(µF)
4.7
10.0
10.0
22.0
22.0
33.0
33.0
47.0
47.0
100.0
100.0
100.0
220.0
220.0
330.0
0.10
0.22
0.33
0.47
1.0
2.2
3.3
4.7
10.0
22.0
33.0
33.0
33.0
47.0
47.0
47.0
100.0
100.0
220.0
10.0
22.0
22.0
33.0
47.0
47.0
3.3
4.7
4.7
10.0
22.0
22.0
33.0
Catalog
Part Number
AHA475M35B12T-F
AHA106M35B12T-F
AHA106M35C12T-F
AHA226M35C12T-F
AHA226M35D16T-F
AHA336M35D16T-F
AHA336M35E16T-F
AHA476M35E16T-F
AHA476M35F24T-F
AHA107M35X16T-F
AHA107M35F24T-F
AHA107M35G24T-F
AHA227M35F24T-F
AHA227M35G24T-F
AHA337M35G24T-F
AHA104M50B12T-F
AHA224M50B12T-F
AHA334M50B12T-F
AHA474M50B12T-F
AHA105M50B12T-F
AHA225M50B12T-F
AHA335M50B12T-F
AHA475M50C12T-F
AHA106M50D16T-F
AHA226M50E16T-F
AHA336M50X16T-F
AHA336M50E16T-F
AHA336M50F24T-F
AHA476M50X16T-F
AHA476M50F24T-F
AHA476M50G24T-F
AHA107M50F24T-F
AHA107M50G24T-F
AHA227M50G24T-F
AHA106M63E16T-F
AHA226M63E16T-F
AHA226M63F24T-F
AHA336M63G24T-F
AHA476M63F24T-F
AHA476M63G24T-F
AHA335M2AE16T-F
AHA475M2AE16T-F
AHA475M2AF24T-F
AHA106M2AF24T-F
AHA226M2AF24T-F
AHA226M2AG24T-F
AHA336M2AG24T-F
Max
DCL
2 min.
(µA)
3.0
3.6
3.6
7.7
7.7
11.6
11.6
16.5
16.5
35.0
35.0
35.0
77.0
77.0
115.5
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
5.0
11.0
16.5
16.5
16.5
23.5
23.5
23.5
50.0
50.0
110.0
6.3
13.9
13.9
20.8
29.6
29.6
3.3
4.7
4.7
10.0
22.0
22.0
33.0
Max
DF
120 Hz /20 ºC
0.12
0.16
0.12
0.16
0.12
0.16
0.14
0.14
0.14
0.12
0.14
0.14
0.14
0.14
0.14
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.18
0.18
0.18
0.18
0.18
0.18
0.18
0.18
0.18
0.18
0.18
0.18
0.18
35
Max
Max
ESR
Ripple Current
120 Hz /20 ºC
120 Hz /105 °C
(
Ω
)
(mA)
Vdc (44 Vdc Surge)
42.3
22
26.5
22
19.9
30
12.1
35
9.0
60
8.0
42
7.0
84
4.9
84
4.9
98
2.0
84
2.3
120
2.3
160
1.1
170
1.1
210
0.7
250
Vdc (63 Vdc Surge)
1990.0
1
905.0
2
603.0
3
424.0
5
199.0
10
90.5
16
60.3
16
42.4
23
19.9
35
9.0
70
6.0
60
6.0
70
6.0
91
4.2
63
4.2
95
4.2
100
2.0
110
2.0
120
0.9
150
Vdc (75 Vdc Surge)
29.9
25
13.6
30
13.6
30
9.0
45
6.3
50
6.3
50
Vdc (125 Vdc Surge)
90.5
30
63.5
30
63.5
50
29.8
55
13.6
55
13.6
60
9.0
65
Case
Code
B
B
C
C
D
D
E
E
F
X
F
G
F
G
G
B
B
B
B
B
B
B
C
D
E
X
E
F
X
F
G
F
G
G
E
E
F
G
F
G
E
E
F
F
F
G
G
Size
DxL
(mm)
4 x 5.4
4 x 5.4
5 x 5.4
5 x 5.4
6.3 x 5.4
6.3 x 5.4
8 x 6.2
8 x 6.2
8 x 10.2
6.3 x 7.7
8 x 10.2
10 x 10.2
8 x 10.2
10 x 10.2
10 x 10.2
4 x 5.4
4 x 5.4
4 x 5.4
4 x 5.4
4 x 5.4
4 x 5.4
4 x 5.4
5 x 5.4
6.3 x 5.4
8 x 6.2
6.3 x 7.7
8 x 6.2
8 x 10.2
6.3 x 7.7
8 x 10.2
10 x 10.2
8 x 10.2
10 x 10.2
10 x 10.2
8 x 6.2
8 x 6.2
8 x 10.2
10 x 10.2
8 x 10.2
10 x 10.2
8 x 6.2
8 x 6.2
8 x 10.2
8 x 10.2
8 x 10.2
10 x 10.2
10 x 10.2
Quantity
per Reel
2000
2000
1000
1000
1000
1000
1000
1000
500
900
500
500
500
500
500
2000
2000
2000
2000
2000
2000
2000
1000
1000
1000
900
1000
500
900
500
500
500
500
500
1000
1000
500
500
500
500
1000
1000
500
500
500
500
500
50
63
100
Part Numbering System
AHA
I
106
I
104 = 0.1 µF
105 = 1.0 µF
106 = 10.0 µF
107 = 100.0 µF
108 = 1000.0 µF
M
I
Capacitance
Tolerance
M = ±20%
16
I
Voltage
06 = 6.3 Vdc 35 = 35 Vdc
10 = 10 Vdc 50 = 50 Vdc
16 = 16 Vdc 63 = 63 Vdc
25 = 25 Vdc 2A = 100 Vdc
B
I
Case
Code
B=B
12T
I
Packaging
Information
12 = Carrier Tape
Width (mm)
T = Tape & Reel
B = Bulk
–F
I
RoHS
Compliant
Series Capacitance
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type AHA
SMT Aluminum Electrolytic Capacitors -55 °C to +105 °C - Long Life
Typical Performance Curves
1.4
Capacitance vs. Temperature & Frequency
1500
µ
F @ 6.3 Vdc (10 X 10.2 mm)
1.4
Capacitance vs. Temperature & Frequency
470
µ
F @ 16 Vdc (10 X 10.2 mm)
1.2
105°C
1.2
105°C
Ratio to 25°C, 120 Hz Value
Ratio to 25°C, 120 Hz Value
85°C
1
85°C
65°C
45°
65°C
1
45°
0.8
0.8
25°C
0°C
0.6
25°C
0.4
0°C
0.2
–20°C
–40°C
–55°C
0
10
100
1,000
10,000
100,000
1,000,000
0.6
–20°C
0.4
–40°C
–55°C
0.2
0
10
100
1,000
10,000
100,000
1,000,000
Frequency (Hz)
Frequency (Hz)
ESR vs. Temperature and Frequency
1000
ESR vs. Temperature and Frequency
100
1500
µF
@ 6.3 Vdc (10 X 10.2 mm)
470
µF
@ 16 Vdc (10 X 10.2 mm)
Ratio to 25°C, 120 Hz Value
Ratio to 25°C, 120 Hz Value
100
–55°C
–55°C
10
–40°C
10
–20°C
0°C
1
25°C
45°C
65°C
85°C
10
100
1,000
10,000
105°C
100,000
1,000,000
–40°C
–20°C
0°C
1
25°C
45°C
65°C
105°C
85°C
0.1
0.1
10
100
1,000
10,000
100,000
1,000,000
Frequency (Hz)
Frequency (Hz)
Impedance vs. Temperature and Frequency
100
1500
µ
F @ 6.3 Vdc (10 X 10.2 mm)
–55°C
Impedance vs. Temperature and Frequency
100
470
µF
@ 16 Vdc (10 X 10.2 mm)
Ratio to 25°C, 120 Hz Value
Ratio to 25°C, 120 Hz Value
10
–40°C
10
–20°C
1
0°C
25°C
45°C
65°C
0.1
85°C
105°C
–55°C
1
–40°C
–20°C
0.1
0°C
25°C
45°C
65°C
85°C
105°C
100,000
1,000,000
0.01
10
100
1,000
10,000
100,000
1,000,000
0.01
10
100
1,000
10,000
Frequency (Hz)
Frequency (Hz)
CDE Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8561
•
Fax: (508)996-3830
•
www.cde.com
Type AHA
SMT Aluminum Electrolytic Capacitors -55 °C to +105 °C - Long Life
Capacitance vs. Temperature & Frequency
1.2
220
µF
@ 50 Vdc (10 X 10.2 mm)
105°C
85°C
65°C
45°C
ESR vs. Temperature and Frequency
1000
220µF @ 50 Vdc (10 X 10.2 mm)
1
Ratio to 25°C, 120 Hz Value
0.8
25°C
Ratio to 25°C, 120 Hz Value
100
–55°C
–40°C
10
–20°C
0°C
1
25°C
45°C
65°C
0.1
10
100
1,000
85°C
10,000
105°C
100,000
1,000,000
0.6
0°C
0.4
–20°C
0.2
–40°C
–55°C
10
100
1,000
10,000
100,000
1,000,000
0
Frequency (Hz)
Frequency (Hz)
Impedance vs. Temperature and Frequency
100
220
µF
@ 50 Vdc (10 X 10.2 mm)
Capacitance Change vs Time
10
5
Capacitance Change (%)
Ratio to 25°C, 120 Hz Value
10
–55°C
0
-5
-10
-15
-20
-25
-30
10
µF@
16 Vdc (4 x 5.4 mm)
47
µF@
16 Vdc ( 6.3 x 5.4 mm)
330
µF
@ 16 Vdc (10 x 10.2 mm)
–40°C
1
–20°C
0°C
25°C
45°C
65°C
105°C
10,000
100,000
1,000,000
0.1
85°C
0.01
10
100
1,000
0
250
500
750
1,000
1,250
1,500
1,750
2,000
Frequency (Hz)
Time (Hours)
Reflow Soldering Temperature Profile for Part Numbers Ending in –F
Peak
Temp.
(see chart)
200
°C
160
°C
120 seconds
Preheat
5 seconds
maximum
Case
Code
B, C, D, X
Peak
Max. Time
Number
Temperature at or above 200°C of Reflow
(°C)
(sec.)
Processes
250
235
60
60
1
1
Maximum
Time @ 200
°C
(see chart)
E, F, G
ime
T
See SMT application guide for land pattern, tape and reel specifications, and cleaning information.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
/aha106m16b12t-f_pdf/pg_0001.png)
京公网安备 11010802033920号
EEWORLD/aha106m16b12t-f_pdf/1.png)
/aha106m16b12t-f_pdf/2.png)
/aha106m16b12t-f_pdf/3.png)
/aha106m16b12t-f_pdf/4.png)
/aha106m16b12t-f_pdf/5.png)
/aha106m16b12t-f_pdf/pg_0002.png)
/aha106m16b12t-f_pdf/pg_0003.png)
/aha106m16b12t-f_pdf/pg_0004.png)
/aha106m16b12t-f_pdf/pg_0005.png)
