DIAMOND
Fiber Optic Components
Specifications:
STANDARD
Insertion loss (IL)
Return loss (RL)
Repeatability of IL
Service life
Operating temperature
Storage temperature
Strain relief (cable)
Multimode
Single mode
Single mode 8° APC Units Test conditions
dB IEC 1300-3-6;
λ
= 1300/1550nm
dB Over service life
°C
May be further limited
°C
by cable specifications
N
typ 0.15 max 0.5 typ 0.2max 0.5 typ 0.2 max 0.5 dB IEC 1300-3-4;
λ
= 1300/1550nm
typ 40
max
±0.1
50
max
±0.1
-40 / +85
-40 / +90
> 100
1000 mate/demate cycles
min 70*
max
±0.1
"ALBERINO"
PRETERMINATED
PATCHCORDS WITHOUT
CONNECTOR BODY
SINGLE MODE PC/APC
MULTIMODE
PC
* Measured with high resolution reflectometer HP 8504A
Description
The preterminated pigtails or patchcords of DIAMOND are products which
allow the customer to choose the needed connector at the moment of the
installation without loss of quality thanks to the technology of the DIAMOND's
"ALBERNO".
Offering a complete range of solutions,this technology is the right one for
applications that presents different kind of connectors, simplifying cabling
and allowing a great reduction of very expensive material storage.
Use
Laser manufacturer, plumbers, system manufacturer, system integrators,
telcommunication, CATV, LAN ...
L
Design
The patchcord/pigtail design is based on following components:
- PC or APC prepolished "alberino" for:
E-2000
™
or
SC
or
FC
or
™
ST
connectors.
Zirconia/copper-nickel alloy insert (Pilzferrule)
Ferrule material:
- Standard cable boot of PUR plastic.
- Fiber/cable of your choice.
DIAMOND SA
Via dei Patrizi 5
CH-6616 LOSONE
Tel. ++41-91/785 45 45
Fax ++41-91/785 45 00
e-mail: info@diamond-fo.com
Specifications subject to change
without notice
002-037-207P003073
ORDER INFORMATION
Pigtails/Patchcords
SINGLE MODE
Type designation:
Polish geometry:
Dimensions
Fiber/Cable
9/125/900
9/125/900/2100
9/125/900/2500
9/125/900/3000
9/125/900/3500
ALB-S0.66
Convex (PC)
Order Number
Unterminated connector
290 - 000 - 001 L 000
290 - 000 - 002 L 000
290 - 000 - 003 L 000
290 - 000 - 004 L 000
290 - 000 - 005 L 000
Terminated assembly
290 - xxx - 001 L xxx
290 - xxx - 002 L xxx
290 - xxx - 003 L xxx
290 - xxx - 004 L xxx
290 - xxx - 005 L xxx
1
2
3
4
Connectors for other fiber and cable dimensions available upon request
MULTIMODE
Type designation:
Polish geometry:
Dimensions
Fiber/Cable
50/125/900
50/125/900/2100
50/125/900/2500
50/125/900/3000
50/125/900/3500
ALB-M0.66
Convex (PC)
Order Number
Unterminated connector
291 - 000 - 001 L 000
291 - 000 - 002 L 000
291 - 000 - 003 L 000
291 - 000 - 004 L 000
291 - 000 - 005 L 000
Terminated assembly
291 - xxx - 001 L xxx
291 - xxx - 002 L xxx
291 - xxx - 003 L xxx
291 - xxx - 004 L xxx
291 - xxx - 005 L xxx
1
2
3
4
Connectors for other fiber and cable dimensions available upon request
SINGLE MODE APC CONVEX
Type designation:
ALB-S8.66
Polish geometry:
8° angled convex (APC)
Dimensions
Fiber/Cable
9/125/900
9/125/900/2100
9/125/900/2500
9/125/900/3000
9/125/900/3500
Order Number
Unterminated connector
292 - 000 - 001 L 000
292 - 000 - 002 L 000
292 - 000 - 003 L 000
292 - 000 - 004 L 000
292 - 000 - 005 L 000
Terminated assembly
292 - xxx - 001 L xxx
292 - xxx - 002 L xxx
292 - xxx - 003 L xxx
292 - xxx - 004 L xxx
292 - xxx - 005 L xxx
1
2
3
4
Connectors for other fiber and cable dimensions available upon request
Housing
Description
E-2000 PC
E-2000
™
APC*
SC PC
SC APC*
FC PC (2.14 mm)*
FC APC (2.14 mm)*
FC APC (2 mm)*
ST™ PC/APC
™
Material
Plastic blue
Plastic green
Plastic blue**
Plastic green**
Metal, Plastic black**
Metal, Plastic black**
Metal, Plastic red**
Plastic black**
070
070
070
070
070
070
070
070
-
-
-
-
-
-
-
-
Order Number
501
501
025
025
025
025
025
025
-
-
-
-
-
-
-
-
099
099
128
128
124
124
124
126
V
V
V
V
V
V
V
V
101
202
001
002
0 11
0 12
022
001
* For the angled connectors the position of the ferrule assembly is given by keeping the black stipe on the back
end at the same side as the antirotation key
** Protection caps available upon request.
Tools
Description
Order Number
221
221
221
221
-
-
-
-
100
100
100
100
-
-
-
-
032
041
093
094
V
V
V
V
001
001
001
001
E-2000
™
pliers for housing assembly
SC
pliers for housing assembly
FC
pliers for housing assembly
ST
™
pliers for housing assembly
Order Number Codes
1
Connector code
2
Connector code for termination on other end of assembly
- For pigtails:
insert 000
- For patch assemblies: insert connector code for other connector
3
Code for fiber or cable
4
Length in meters
See ordering information for additional details
