RESISTANCE WELD MINIATURE CRYSTAL
CRYSTALS
HC80
The HC80 Quartz Crystal is a miniature resistance welded package
that provides for an excellent hermetic seal and frequency aging.
This high quality crystal offers a smaller footprint in a wide
frequency range, in addition to a low profile which eliminates the
need for hold down pins and thereby provides additional savings of
labor cost.
FEATURES
Miniature Package
Wide Frequency Range
Small Footprint
Low Profile
Excellent Aging
HC80 STANDARD SPECIFICATIONS *
PARAMETERS
Frequency Range
Frequency Tolerance
Frequency Stability, ref @ 25ºC
Temperature Range
Operating
(T
OPR
)
Storage
(T
STG
)
Shunt Capacitance
(Co)
Load Capacitance
(C
L
)
Drive Level
Aging
Frequency Range (MHz)
3.579545 ~ 4.000
4.000+ ~ 5.000
5.000+ ~ 6.000
6.000+ ~ 7.000
7.000+ ~ 8.000
8.000+ ~ 10.000
CONDITIONS
Ta = 25ºC
Ta = -20ºC ~ +70ºC
MIN
3.579545
-30
-50
-20
-40
Customer Specified
3.579545 ~ 200.000 MHz
Ta = 25ºC; per year
10.0
-3.0
MAX
200.000
+30
+50
+70
+85
7.0
Series
1.0
+3.0
UNITS
MHz
PPM
PPM
ºC
pF
pF
mW
PPM
Operating Mode Max ESR
W
Frequency Range (MHz) Operating Mode Max ESR
W
Fundamental
300
10.000+ ~ 11.000
Fundamental
60
11.000+ ~ 50.000
Fundamental
250
Fundamental
40
180
25.000 ~ 65.000
Fundamental
3rd OT
60
60.000 ~ 130.000
Fundamental
120
5th OT
100
130.000 ~ 200.000
100
Fundamental
7th OT
150
90
Fundamental
* Other tolerances, stabilities & operating temperature ranges available. Consult Fox Customer Service for specific requirements, or use crystal order form on page 6.
All specifications subject to change without notice. Rev. 03/01/00
All dimensions are in millimeters.
