342728-3: Description5 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER; CategoryThe connector The connector; File Size117KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

342728-3 Overview

5 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER

342728-3 Parametric

Parameter Name	Attribute value
Objectid	8040913414
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	342728
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	5

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors - Wire to Board - Power

Product Feature Selector

> Product Details

342728-3 Product Details

Live Product Chat

Product View

MTA, CST-100 II, MT-6 and SL Connectors and Headers

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

342728-3

T E I nternal N umber: 3 4 2 7 2 8 - 3

Product Highlights:

MT-7 C onnectors

Number of Positions = 5

Mating Type = Header

Wire-to-Board Application

2.54 mm C ontact C enterline Spacing

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Automachine and General Products

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = MT-7 C onnectors

Number of Positions

= 5

Mating Type

= Header

PC B Mount Angle

= Vertical

Mating Polarization

= With

Mating C onnector Lock = Without

Four Points of C ontact

= Without

Shrouded

= Yes

Mounting Ears

= Without

Mechanical Attachment:

Panel Attachment

= Without

Termination Related Features:

Solder Tail C ontact Plating

= Tin

Contact Related Features:

C ontact C enterline Spacing (mm [in])

= 2.54 [0.100]

C ontact Mating Area Plating Material

= Tin

C ontact Base Material

= Brass

Housing Related Features:

Housing C olor = Black

Housing Flammability Rating = UL 94V-2

Housing Material = Nylon

Configuration Related Features:

Backwall/Post Interruption(s)

= Without

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Terminate To

= Printed C ircuit Board

Operation/Application:

Application

= Wire-to-Board

Other:

Brand = AMP

Additional Information:

Product Line Information

Additional Product Images:

PC B Layout
