XBS303V19R-G
Schottky Barrier Diode, 3A, 30V Type
ETR16022-001
■FEATURES
Forward Voltage
Forward Current
Repetitive Peak Reverse Voltage
: V
F
=0.355V (TYP.)
: I
F(AVE)
=3A
: V
RM
=30V
■APPLICATIONS
●Rectification
●Protection
against reverse connection of battery
■ABSOLUTE
MAXIMUM RATINGS
Ta=25℃
PARAMETER
Repetitive Peak Reverse Voltage
Reverse Voltage
Forward Current (Average)
Non Continuous
Forward Surge Current
Junction Temperature
Storage Temperature Range
*1
■PACKAGING
INFORMATION
SMA-XG
4.45±0.2
SYMBOL
V
RM
V
R
I
F(AVE)
I
FSM
Tj
Tstg
RATINGS
30
30
3
60
125
-55½+150
UNITS
V
V
A
1.5±0.15
Unit: mm
A
℃
℃
*1: Non continuous high amplitude 60Hz half-sine wave.
5.1±0.25
①②③④⑤⑥:
303V19(Product Number)
: Assembly Lot Number
1.2±0.3
(0.2)
⑦⑧
■PRODUCT
NAME
PRODUCT NAME
XBS303V19R-G
(*1)
(*1)
PACKAGE
SMA-XG
ORDER UNIT
2,000/Reel
The “-G” suffix denotes Halogen and Antimony free as well as being fully RoHS compliant.
■ELECTRICAL
CHARACTERISTICS
PARAMETER
Forward Voltage
Reverse Current
Inter-Terminal Capacity
Reverse Recovery Time
SYMBOL
V
F1
V
F2
V
F3
I
R
Ct
trr
CONDITIONS
I
F
=0.5A
I
F
=1A
I
F
=3A
V
R
=30V
V
R
=1V , f=1MHz
I
F
=I
R
=10mA , irr=1mA
MIN.
-
-
-
-
-
-
TYP.
0.265
0.295
0.355
0.35
385
90
MAX.
0.34
0.36
0.39
3
-
-
UNITS
V
V
V
mA
pF
ns
0.2MAX
Ta=25℃
CIRCUIT
①
①
①
②
③
④
2.1±0.2
2±0.15
■MARKING
RULE
2.6±0.2
1/4
XBS303V19R-G
■TEST
CIRCUITS
LCR Meter
Bias
Device Under test
Pulse Generatrix
Oscilloscope
■NOTES
ON USE
1) Please use this IC within the absolute maximum ratings.
2) Even within the ratings, in case of high load use continuously such as high temperature, high voltage, high current and
thermal stress may cause reliability degradation of the IC. Adequate “Derating” should be taken into consideration while
designing.
3) Torex places an importance on improving our products and their reliability. We request that users incorporate fail-safe
designs and post-aging protection treatment when using Torex products in their systems.
2/4
XBS303V19R-G
■TYPICAL
PERFORMANCE CHARACTERISTICS
(1) Forward Current vs. Forward Voltage
(2) Reverse Current vs. Reverse Voltage
10
Reverse Current: I
R
(mA)
Reverse Current I
R
(mA)
100
Ta=125℃
Forward
Current I
F
(A)
Forward
Current: I
F
(A)
10
100℃
1
Ta=125℃
-25℃
75℃
1
0.1
75℃
25℃
0.1
25℃
0.01
0
0.2
0.4
0.6
Forward Voltage: V
F
(V)
Forward Voltage V
F
(V)
(3) Forward Voltage vs. Operating Temperature
0.01
0
10
20
30
Reverse Voltage: V
R
R
(V)
Reverse Voltage V (V)
(4) Reverse Current vs. Operating Temperature
0.6
100
V
R
=20V
10V
5V
1V
Reverse Current: I
R
(mA)
Reverse Current I
R
(mA)
Forward Voltage: V
F
(V)
Forward Voltage V
F
(V)
10
0.4
I
F
=3A
1
0.2
1.5A
0.5A
0.1A
0.1
0.0
-50
0
50
100
150
0.01
0
50
100
150
Operating Temperature: Ta (℃)
Operating Temperature Ta (℃)
(5) Inter-Terminal Capacity vs. Reverse Voltage
Operating Temperature: Ta (℃)
Operating Temperature Ta (℃)
(6) Average Forward Current vs. Operating Temperature
1000
Average Forward Current: IF
AV
(A)
Average Forward Current IF
AV
(A)
Ta=25℃
4.0
Inter-Terminal Capacity: C
t
(pF)
Inter-Terminal Capacity Ct (pF)
800
3.0
600
2.0
400
200
1.0
0
0
10
20
30
0.0
0
50
100
150
Reverse Voltage: V
R
(V)
Reverse Voltage V
R
(V)
Operating
Temperature: Ta
(℃)
Operating
Temperature Ta
(℃)
3/4
XBS303V19R-G
