V I S H ay I n T e R T e C H n O l O g y, I n C .
ReSISTIVe PRODuCTS
NiCKeL THiN FiLm THermisTOr
TFP T
PRODuCT SHeeT
Nickel Thin Film PTC Thermistor with
Linear Tracking
Key BeNeFiTs
• Terminations: nickel barrier, pure tin or tin/lead wraparound
• Operation range: - 55 °C to + 125 °C (+ 150 °C)
• Sizes available: 0603, 0805, 1206
• TCR @ 25 °C = 4110 ppm/K
• Standard tolerances: ± 0.5 %, ± 1 %, ± 5 %
• High stability (drift < 0.25 %)
• Reproducible curve with algorithm
APPLiCATiONs
• Temperature compensation and sensing in consumer, industrial, and
automotive applications
• Printers
• Cell phones
• Pagers
• DC motors
w w w. v i s h a y. c o m
Datasheet is available on our web site at www.vishay.com
for TFPT - http://www.vishay.com/doc?33017
TFPT
Vishay
TFPT
Vishay
smD PTC - Nickel Thin Film Linear Thermistors
FEATURES
•
Alumina substrate base with nickel based PTC
thin film element
•
0603, 0805 and 1206 sizes available
•
Available in tape and reel packaging
•
Standard
R
25
tolerances: ± 0.5 %, ± 1 %, ± 5 %
•
Operation range - 55 °C to + 125 °C (+ 150 °C)
•
Compliant to RoHS directive 2002/95/EC
SMD PTC - Nickel Thin Film Linear Thermistors
STANDARD ELECTRICAL SPECIFICATIONS
TCR AT ROOM TEMPERATURE
(25 °C) SEE TYPICAL CURVE
FOR TCR AT OTHER TEMPS.
4110 ppm/K
TCR
(1)
TOLERANCE
ppm/K
± 400
R
25
VALUE RANGE in
Ω
(0.5 %, 1 %, 5 % TOLERANCE)
(2)
0603
MIN.
MAX.
100 to 1K
0805
MIN.
MAX.
100 to 5K
1206
MIN.
MAX.
100 to 10K
Notes
(1)
Contact Vishay if closer TCR lot tolerance is desired
(2)
Other
R
values and tolerances are available upon request
25
STANDARD RESISTANCE VALUES
at 25 °C in
Ω
100
120
150
180
220
270
330
390
470
560
680
820
1K
1.2K
1.5K
1.8K
2.2K
2.7K
3.3K
3.9K
4.7K
5.6K
6.8K
8.2K
10.0K
STANDARD TECHNICAL SPECIFICATIONS
PART NUMBER
TFPT 0603
TFPT 0805
TFPT 1206
(3)
P
70
MAXIMUM POWER at 70 °C
75 mW
100 mW
125 mW
MAXIMUM WORKING VOLTAGE RCWV
(3)
30 V
DC
40 V
DC
50 V
DC
Note
Rated Continuous Working Voltage is maximum working voltage or square root of the power rating times resistance value, whichever is less.
GLOBAL PART NUMBER INFORMATION
Global Part Numbering: TFPT1206L1002FM (preferred part number format)
T
F
P
T
1
2
0
6
L
1
0
0
2
F
M
GLOBAL MODEL
TFPT0603
TFPT0805
TFPT1206
CHARACTERISTIC
L
= Linear
RESISTANCE VALUE
1002
= 10K
TOLERANCE CODE
D
= ± 0.5 %
F
=±1%
J
=±5%
PACKAGING
F
= Lead (Pb)-free, bulk
M
= Lead (Pb)-free, T/R (5000 pieces)
V
= Lead (Pb)-free, T/R (1000 pieces)
P
= Tin/lead, bulk
Z
= Tin/lead, T/R (5000 pieces)
Y
= Tin/lead, T/R (1000 pieces)
Revision 06-nov-09
