Series
Positive Voltage Regulators
NCMOS
Low Power Consumption
NDropout
Voltage
: 0.16V @ 100mA,
0.40V @ 200mA
NMaximum
Output Current : 250mA (V
OUT
=5.0V, TYP)
NHighly
Accurate
: ± 2%
NOutput
Voltage Range : 1.3V ~ 6.0V
NSOT-25
/ SOT-89 / TO-92 Package
NCapacitors
can be Tantalum or Ceramic
■Applications
GMobile
phones
GCordless
phones
GCameras,
video recorders
GPortable
games
GPortable
AV equipment
GReference
voltage
GBattery
powered equipment
3
■General Description
The XC6201 series are highly precise, low power consumption, positive
voltage regulators manufactured using CMOS and laser trimming
technologies.
The series provides large currents with a significantly small dropout
voltage.
The XC6201 consists of a current limiter circuit, a driver transistor, a
precision reference voltage and an error amplifier. Output voltage is
selectable in 0.1V steps between 1.3V ~ 6.0V.
SOT-25 (250mW), SOT-89 (500mW) and TO-92 (300mW) packages are
available.
■Features
Maximum Output Current
Dropout Voltage
Maximum Operating Voltage
Output Voltage Range
Highly Accurate
Low Power Consumption
: 250mA (TYP.)
: 0.16V @ 100mA
: 10V
: 1.3V ~ 6.0V
(selectable in 0.1V steps)
: ± 2%
: TYP 2.0
µA
Operational Temperature Range
: -40°C ~ 85°C
Ultra Small Packages
: SOT-25 (250mW),
SOT-89 (500mW),
TO-92 (300mW)
Capacitors can be Tantalum or Ceramic
■Typical Application Circuit
V
IN
V
OUT
■Typical Performance
Characteristic
XC6201P332
3.0
Supply Current:I
SS
(µA)
V
SS
1.0µF(tantalum)
1.0µF(tantalum)
2.5
2.0
1.5
1.0
0.5
0.0
0
Topr=85°C
25°C
-40°C
2
4
6
8
10
Input Voltage:V
IN
(V)
185
XC6201
Series
■Pin Configuration
V
OUT
5
NC
4
１
V
IN
2
V
SS
3
NC
１
V
OUT
2
V
SS
SOT-89
(TOP VIEW)
3
V
IN
SOT-25
(TOP VIEW)
3
■Pin Assignment
PIN NUMBER
SOT-25
5
2
1
3
4
SOT-89/TO-92（T）
1
2
3
−
−
TO-92（L）
2
1
3
−
−
1
2
3
1
2
3
V
OUT
V
SS
V
IN
TO-92（T Type）
（TOP VIEW）
V
SS
V
OUT
V
IN
TO-92 (L Type)
(TOP VIEW)
PIN NAME
V
OUT
V
SS
V
IN
（NC）
（NC）
FUNCTION
Output
Ground
Power Input
No Connection
No Connection
■Product Classification
GOrdering
Information
X C 6 2 0 1 P
erty
↑ ↑
q w
DESIGNATOR SYMBOL DESCRIPTION DESIGNATOR SYMBOL
DESCRIPTION
Indicates the
Output Voltage Accuracy
q
01
product number
r
1/2
e.g.1 : ±1.0%
2 : ±2.0%
Type of
w
P
regulator 3-pin
M
Package Type ：SOT-25
P
：SOT-89
t
T
：TO-92（Standard）
Output Voltage
L
：TO-92（Custom pin configuration）
e.g. 30 : 3.0V
13∼60
e
R
Embossed Tape:Standard Feed
50 : 5.0V
L
Embossed Tape:Reverse Feed
y
H
Paper Type（TO-92）
B
Bag（TO-92）
186
XC6201
Series
■Marking
GSOT-89,
SOT-25
q
Represents the product name
q
w
e
r
SYMBOL
１
PRODUCT NAME
XC6201PXXXXX
w
Represents the type of regulator
VOLTAGE（V）
SOT-89
SYMBOL
0.1∼3.0
5
3.1∼6.0
6
6.1∼9.0
７
3
qwer
e
Represents the Output Voltage
SYMBOL
0
1
SOT-25
2
3
4
5
6
7
8
9
A
B
C
D
E
OUTPUT VOLTAGE (V)
−
−
−
−
−
−
−
−
−
−
−
−
1.3
1.4
1.5
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
3.9
4.0
4.1
4.2
4.3
4.4
4.5
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
SYMBOL
F
H
K
L
M
N
P
R
S
T
U
V
X
Y
Z
OUTPUT VOLTAGE (V)
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
3.0
4.6
4.7
4.8
4.9
5.0
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
5.9
6.0
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
r
Represents the assembly lot no.
0∼9, A∼Z repeated (G, I, J, O, Q, W excepted)
189
