390241-3 Product Details
Live Product Chat
Product View
Memory Sockets
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
390241-3
T E I nternal N umber: 3 9 0 2 4 1 - 3
Product Highlights:
l
DIMM 2P
l
Gold (15) C ontact Mating Area Plating Material
l
Number of Positions = 184
l
DRAM Type = Double Data Rate (DDR)
l
DRAM Voltage = 2.5 V
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
SOC KET ASSEMBLY, DIMM2P 184 POSITION, DDR
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = DIMM 2P
l
Number of Positions
= 184
l
DRAM Type
= Double Data Rate (DDR)
l
PC B Mount Style = Through Hole
l
Module Orientation
= Vertical
l
PC B Retention Feature = No
l
Profile = Standard
Mechanical Attachment:
l
C enter Retention Hole Diameter (mm [in])
= 2.44 [0.096]
Electrical Characteristics:
l
DRAM Voltage
= 2.5 V
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.79 [0.110]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Row-to-Row Spacing (mm [in])
= 1.90 [0.075]
l
C enterline (mm [in])
= 1.27 [0.050]
l
Number of Rows
= Dual
l
Ejector Type = Locking
l
Ejector Location
= Both Ends
l
Number of Keys
= 1
l
Mount Type = Printed C ircuit Board
l
Module Key Type = C enter
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold (15)
l
C ontact Base Material = Phosphor Bronze
l
Retention Post(s) Location
= None
Housing Related Features:
l
Housing Material = Polyphthalamide (PPA)
l
Housing C olor = Black
Configuration Related Features:
l
Insertion Style
= Direct Insert
l
C enter Key (mm [in])
= None
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Packaging Related Features:
l
Packaging Method = Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
