XT46C
Vishay Dale
Surface Mount Crystal
FEATURES
•
Ultra-miniature size
•
Wide frequency range
•
Seam sealing
•
Ceramic package
This part is an ultra miniature package with size of 6.0 x 3.5
x 1.0 mm. With its ceramic base and metal cover it provides
the durability and reliability necessary for strenuous process
like infrared and vapor phase reflow.
•
Emboss taping
•
Reflow soldering
•
100 % Lead (Pb)-free and RoHS compliant
RoHS
COMPLIANT
STANDARD ELECTRICAL SPECIFICATIONS
PARAMETER
Frequency Range
Frequency Tolerance
Temperature Stability
Operating Temperature Range
Storing Temperature Range
Shunt Capacitance
Load Capacitance
Insulator Resistance
Drive Level
Aging
SYMBOL
F
O
ΔF/F
O
TC
T
OPR
T
STG
C
O
CL
IR
DL
Fa
CONDITION
at 25 °C
ref to 25 °C
UNIT
MHz
ppm
ppm
°C
°C
pF
pF
MΩ
µW
ppm
MIN
10.000
± 10
± 10
- 10
- 40
10
500
100
- 5.0
TYPICAL
± 30
± 30
MAX
80.000
± 50
± 50
+ 60
+ 85
7
Series
300
+ 5.0
Customer Specified
100 V
DC
at 25 °C, per year
EQUIVALENT SERIES RESISTANCE (ESR) AND MODE OF VIBRATION (MODE)
FREQUENCY RANGE (MHz)
10.000 to 15.999
16.000 to 39.999
40.000 to 80.000
MAX ESR (
Ω)
60
40
70
MODE
Fundamental
Fundamental
3
rd
Overtone
DIMENSIONS
in inches [millimeters]
0.236 ± 0.008
[6.0 ± 0.2]
0.035 [0.9]
0.089 [1.5]
0.035 [0.9]
MARKING
AREA
0.138 ± 0.008
[3.5 ± 0.2]
0.055
[1.4]
0.118 ± 0.004
[3.0 ± 0.10]
0.055
[1.4]
Note: Pin#2 and #4 are connected through
cover, in case connected to GND.
Frequency might be drifted.
0.055 [1.4]
0.039 ± 0.4
[1.0 ± 0.1]
0.236 ± 0.008
[6.0 ± 0.2]
0.043 [1.1]
0.055 [1.4]
0.077
[1.95]
0.094
[2.4]
0.077
[1.95]
Recommended Solder Pattern
ORDERING INFORMATION
XT46C
MODEL
- 20
LOAD
Blank = Series
- 20 = 20 pF Standard
- 32 = 32 pF
25 M
FREQUENCY/MHz
e4
JEDEC LEAD (Pb)-FREE
STANDARD
GLOBAL PART NUMBER
X
T
MODEL
4
6
2
LOAD
0
A
PACKAGE
CODE
2
5
FREQUENCY
M
www.vishay.com
18
For technical questions contact: frequency@vishay.com
Document Number: 35021
Revision: 18-Oct-07
