RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
ZLJ
ZLJ
SERIES
UPGRADE
105℃ High Ripple Current, Long Life, Low Impedance
・
Load Life : 105℃ 6000∼10000 hours.
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−40∼＋105℃
6.3∼100Vdc
±20％
（20℃，
120Hz）
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
I＝0.01CV
or 3μA whichever is greater.(After 2 minutes)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
6.3 10 16 25 35 50 63 80 100
(Vdc)
tanδ
0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08 0.08
（20℃，
120Hz）
Dissipation Factor(MAX)
(tanδ)
When capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After applying rated voltage with rated ripple current for specified time at 105℃,
the capacitors shall meet the following requirements.
Capacitance Change
Endurance
Dissipation Factor
Leakage Current
Within ±25％ of the initial value.
(6.3Vdc, 10Vdc ±30%)
：
Not more than 200％ of the specified value.
Not more than the specified value.
Life Time(hrs)
6.3Vdc 10∼50Vdc 63∼100Vdc
φD≦6.3
6000
7000
6000
8000
9000
8000
8×11.5
9000
9000
9000
10×12.5
9000
9000 10000
8×16,8×20
10×16,10×20,10×25
10000
φD≧12.5
Case Size
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
6.3
(Vdc)
Z
（−25℃） （20℃） 2
/Z
Z
（−40℃） （20℃） 3
/Z
10
2
3
16
2
3
25
2
3
35
2
3
50
2
3
63
2
3
80 100
（120Hz）
2
3
2
3
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆DIMENSIONS
100k≦
1.00
1.00
1.00
1.00
1.00
SLEEVE(PET)
（mm）
F ±0.5
φD＋0.5MAX
φd
120
0.42
0.50
0.55
0.60
0.70
1k
0.70
0.73
0.77
0.80
0.85
10k
0.90
0.92
0.94
0.96
0.98
8.2∼33μF
47∼270μF
Coefficient
330∼680μF
820∼1800μF
2200∼8200μF
L＋ MAX
α
15MIN
4MIN
φD
φd
5
6.3
0.5
8
10 12.5
0.6
16
18
0.8
7.5
◆OPTION
PET Sleeve
Code
Blank
F
α
2.0
2.5
3.5
5.0
L≦16 : α
＝1.5 L≧20 : α
＝2.0
◆PART NUMBER
□□□
Rated Voltage
ZLJ
Series
□□□□□
Capacitance
Ｍ
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
