THJ Series
High Temperature Tantalum Chip Capacitor
FEATURES
• Improved reliability – 2x standard
• 175°C @ 0.5V
R
continuous operation
• CV range: 0.10-220μF / 6.3-50V
• 5 case sizes available
• Low ESR options on approval
• High temperature automotive and industry applications
LEAD-FREE COMPATIBLE
COMPONENT
SnPb termination option is not
RoHS compliant.
APPLICATIONS
• Automotive ECU and ABS control electronics
• Geothermal instrumentation
CASE DIMENSIONS:
millimeters (inches)
Code
A
B
C
D
EIA
Code
EIA
Metric
L±0.20
(0.008)
W+0.20 (0.008)
-0.10 (0.004)
1.60 (0.063)
2.80 (0.110)
3.20 (0.126)
4.30 (0.169)
4.30 (0.169)
H+0.20 (0.008)
–0.10 (0.004)
1.60 (0.063)
1.90 (0.075)
2.60 (0.102)
2.90 (0.114)
4.10 (0.162)
W
1
±0.20
(0.008)
1.20 (0.047)
2.20 (0.087)
2.20 (0.087)
2.40 (0.094)
2.40 (0.094)
A+0.30 (0.012)
-0.20 (0.008)
0.80 (0.031)
0.80 (0.031)
1.30 (0.051)
1.30 (0.051)
1.30 (0.051)
S Min.
1.10 (0.043)
1.40 (0.055)
2.90 (0.114)
4.40 (0.173)
4.40 (0.173)
1206
3216-18 3.20 (0.126)
1210
3528-21 3.50 (0.138)
2312
6032-28 6.00 (0.236)
2917
7343-31 7.30 (0.287)
2917
7343-43 7.30 (0.287)
MARKING
A, B, C, D, E CASE
AVX LOGO
Capacitance Value in pF
227 = 220µF
Rated Voltage Code
A = 10V
ID Code
Polarity
Band
(Anode+)
E
W
1
dimension applies to the termination width for A dimensional area only.
227 A
XXXXX
HOW TO ORDER
THJ
B
105
Type
Case Size
See table
above
Capacitance Code
pF code: 1st two
digits represent
significant figures
3rd digit represents
multiplier (number of
zeros to follow)
*
Tolerance
K=±10%
M=±20%
035
R
JN
—
Rated DC Voltage
006=6.3Vdc
010=10Vdc
016=16Vdc
020=20Vdc
025=25Vdc
035=35Vdc
050=50Vdc
Packaging
R = Pure Tin 7" Reel
S = Pure Tin 13" Reel
A = Gold Plating 7" Reel
B = Gold Plating 13" Reel
H = Tin Lead 7" Reel
(Contact Manufacturer)
Standard
Suffix
OR
0100
Low ESR
in mΩ
Additional
characters may be
added for special
requirements
V = Dry pack Option
(selected codes only)
K = Tin Lead 13" Reel
(Contact Manufacturer)
H, K = Non RoHS
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage (V
R
)
Category Voltage (V
C
)
Category Voltage (V
C
)
Surge Voltage (V
s
)
Surge Voltage (V
s
)
Surge Voltage (V
s
)
Temperature Range:
Reliability:
Termination Finish:
All technical data relate to an ambient temperature of +25°C
0.10 μF to 220 μF
±10%; ±20%
6.3
10
16
20
25
35
50
4
7
10
13
17
23
33
3
5
8
10
12
17
25
8
13
20
26
32
46
65
5
8
13
16
20
28
40
4
6
10
12
15
21
30
-55ºC to 175°C voltage derating.
0.5% per 1000 hours at 85°C, V
R
with 0.1Ω/V series impedance,
60% confidence level, 3.5 Fits at 40°C, 0.5V
R
Sn Plating (standard), Gold Plating available on request
Meets requirements of AEC-Q200
JUNE 2014
+85°C:
+125°C:
+175°C:
+85°C:
+125°C:
+175°C:
■
141
THJ Series
High Temperature Tantalum Chip Capacitor
CAPACITANCE AND RATED VOLTAGE RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
μF
Code
0.10
104
0.15
154
0.22
224
0.33
334
0.47
474
0.68
684
1.0
105
1.5
155
2.2
225
3.3
335
4.7
475
6.8
685
10
106
15
156
22
226
33
336
47
476
68
686
100
107
150
157
220
227
6.3V (J)
10V (A)
Rated voltage (V
R
) to 85°C (Voltage Code)
16V (C)
20V (D)
25V (E)
35V (V)
A
A
A
A
B
B
A/B
C
C
C
C
D
D
D
D, D(300)
E
50V (T)
A
A
A
A
A
A
A
B
B
B
C
C
D
D
A
A
A
A/B
B
B
C
C
D
D
E
A
A
A/B
A/B
B
B
C, C(500)
C
C/D
D
E
B, B(1500)
B
C
C
C
D
D
D
D
D
D
D/E
Available Ratings, (ESR ratings in mOhms in brackets)
Engineering samples - please contact manufacturer
*Codes under development - subject to change
Note: Voltage ratings are minimum values. AVX reserves the right to supply
higher ratings in the same case size, to the same reliability standards.
THJ 175°C Voltage vs Temperature Rating
120%
100%
100%
80%
80%
60%
40%
20%
0%
-55°C
66%
50%
Rated range
100%
100%
0°C
40°C
60°C
85°C
105°C
125°C
175°C
142
■
JUNE 2014
THJ Series
High Temperature Tantalum Chip Capacitor
RATINGS & PART NUMBER REFERENCE
AVX
Part No.
Case Capacitance
Size
(μF)
Rated
Voltage
(V)
Rated
Category Category
Temperature Voltage Temperature
(ºC)
(V)
(ºC)
DCL
(μA)
Max.
DF
%
Max.
ESR
Max. (Ω)
@ 100kHz
100kHz RMS Current (mA)
MSL
25ºC
85ºC
125ºC
175ºC
THJD226*035#JN
THJD226*035#0300
THJE336*035#JN
THJD335*050#JN
THJD475*050#JN
THJD685*050#JN
THJD106*050#JN
THJE106*050#JN
D
D
E
D
D
D
D
E
22
22
33
3.3
4.7
6.8
10
10
35
35
35
50
50
50
50
50
85
85
85
85
85
85
85
85
17
175
17
175
17
175
50 Volt @ 85°C
25
175
25
175
25
175
25
175
25
175
7.7
7.7
11.6
1.7
2.4
3.4
5
5
6
6
6
6
6
6
6
6
0.6
0.3
0.5
1.1
0.9
0.7
0.7
0.7
1
1
1
1)
1
1
1
1
1
1)
500
707
574
369
463
408
463
486
450
636
517
332
417
367
417
437
200
283
230
148
185
163
185
194
100
141
115
74
93
82
93
97
1
1)
Dry pack option (see How to order) recommended for reduction of stress during soldering. Dry pack parts should be treated as MSL 3.
Moisture Sensitivity Level (MSL) is defined according to J-STD-020
All technical data relates to an ambient temperature of +25°C. Capacitance and DF are measured at 120Hz, 0.5V RMS with a maximum DC bias of 2.2 volts.
DCL ismeasured at rated voltage after 5 minutes.
The EIA & CECC standards for low ESR Solid Tantalum Capacitors allow an ESR movement to 1.25 times catalogue limit post mounting.
For typical weight and composition see page 202.
NOTE: AVX reserves the right to supply a higher voltage rating or tighter tolerance part in the same case size, to the same reliability standards.
QUALIFICATION TABLE
TEST
THJ series (Temperature range -55ºC to +175ºC)
Characteristics
Visual examination
no visible damage
Determine after application of rated voltage for 2000
+48/-0 hours at 85±2ºC and then leaving 1-2 hours at
DCL
1.25 x initial limit
room temperature. Also determine of 175ºC tempera-
ΔC/C
within ±10% of initial value
ture, category voltage for 2000 +48/-0 hours and
DF
initial limit
then leaving 1-2 hours at room temperature. Power
supply impedance to be ≤0.1Ω/V.
ESR
1.25 x initial limit
Visual examination
no visible damage
DCL
1.25 x initial limit
175ºC, 0V, 2000h
ΔC/C
within ±10% of initial value
DF
initial limit
ESR
1.25 x initial limit
Visual examination
no visible damage
DCL
2 x initial limit
Determine after leaving for 1000 hours at 85±2ºC,
85% relative humidity and rated voltage and then
ΔC/C
within ±10% of initial value
recovery 1-2 hours at room temperature.
DF
1.2 x initial limit
ESR
1.25 x initial limit
Condition
Step
1
2
3
4
5
6
Temperature°C
+20±2
-55+0/-3
+20±2
+85+3/-0
+175+3/-0
+20±2
Duration(min)
15
15
15
15
15
15
Endurance
Storage Life
Biased
Humidity
Temperature
Stability
DCL
ΔC/C
DF
ESR
+20ºC -55ºC
IL*
n/a
n/a
+0/-10%
IL*
1.5 x IL*
1.25 x IL* 2.5 x IL*
+20ºC +125ºC +175ºC +20ºC
IL*
10 x IL* 12.5 x IL*
IL*
±5%
+10/-0% +18/-0% ±5%
IL*
1.5 x IL*
2 x IL*
IL*
1.25 x IL* 1.25 x IL* 1.25 x IL* 1.25 x IL*
Visual examination
Surge
Voltage
Test temperature: 175ºC+3/0ºC
Test voltage: 1.3 x category voltage at 175ºC
Series protection resistance 1000±100Ω
Discharge resistance: 1000Ω
Number of cycles: 1000x
Cycle duration: 6 min; 30 sec charge,
5 min 30 sec discharge
no visible damage
initial limit
within ±5% of initial value
initial limit
1.25 x initial limit
DCL
ΔC/C
DF
ESR
*Initial Limit
144
■
JUNE 2014
