3.0SMCJ78C datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 3.0SMCJ78C

3.0SMCJ78C: DescriptionTrans Voltage Suppressor Diode, 3000W, 78V V(RWM), Bidirectional, 1 Element, Silicon, DO-214AB, PLASTIC PACKAGE-2; CategoryDiscrete semiconductor diode; File Size117KB，5 Pages; ManufacturerWorld Produts Inc.; Websitehttp://www.worldproducts.com

Download Datasheet Parametric View All

3.0SMCJ78C Overview

Trans Voltage Suppressor Diode, 3000W, 78V V(RWM), Bidirectional, 1 Element, Silicon, DO-214AB, PLASTIC PACKAGE-2

3.0SMCJ78C Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	DO-214AB
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	UL RECOGNIZED
Maximum breakdown voltage	110 V
Minimum breakdown voltage	86.7 V
Maximum clamping voltage	139 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 code	DO-214AB
JESD-30 code	R-PDSO-C2
JESD-609 code	e0
Maximum non-repetitive peak reverse power dissipation	3000 W
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	BIDIRECTIONAL
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	78 V
surface mount	YES
technology	AVALANCHE
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

World Products Inc. | Transient Voltage Suppression Diodes | 3.0SMCJ Series

Page 1 of 5

Transient Voltage Suppression Diodes

3.0SMCJ Series

Surface Mount

3000 Watt Specifications

Features

Absolute Maximum Ratings

Mechanical Characteristics

Mechanical Dimensions

Standard Mounting Pad Layout

Electrical Characteristics

Features

RoHS Compliance Standard

3000 watt peak pulse power dissipation

Available in voltages from 5.0V to 170V

Unidirectional and bidirectional

Glass passivated junction

Low clamping factor

Available in tape and reel (Reel quantity = 3,000 pieces)

Each device 100% surge tested

UL 497B Recognized, File # E135015

Tape and Reel to EIA Standard RS-481-A

Absolute Maximum Ratings

Parameter

Value

Peak pulse power dissipation (P

PPM

) at 25°

Operating and storage temperatures

3000W

-55° to + 150°

Mechanical Characteristics

DO214AB package

UL94V-0 Thermoset Epoxy

Solder plated terminals

Solderable per MIL-STD-750 Method 2026

Mechanical Dimensions

http://www.worldproducts.com/TVS_30SMCJ.htm

4/6/2009
