GPS0002 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> GPS0002

GPS0002: DescriptionGPS Antenna; CategoryWireless rf/communication Radio frequency and microwave; File Size29KB，1 Pages; ManufacturerRadiall; Websitehttps://www.radiall.com/

Download Datasheet Parametric View All

GPS0002 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GPS0002	-	-	View	Buy Now

GPS0002 Overview

GPS Antenna

GPS0002 Parametric

Parameter Name	Attribute value
Maker	Radiall
Reach Compliance Code	unknown
RF/Microwave Device Types	GPS ANTENNA
Base Number Matches	1

Preview

Download Datasheet

View All

GPS/DUAL BAND

Radiall/Larsen offers unique

options in GPS and dual band

antenna designs.

Active GPS antenna. Available in

black or white.

GPS / UHF dual band mobile

antenna w/active GPS module.

MODEL

GPS0001

GPS0002

GPS0003

GPS0004

GPS0005

GPS0006

GPS0007

GPS0008

GPS0009

GPS0010

GPS0011

GPS0012

COLOR

WHITE

BLACK

WHITE

BLACK

WHITE

BLACK

WHITE

BLACK

WHITE

BLACK

WHITE

GLACK

CONN

MCX

MMCX

SMB

NO CONN

SMA

BNC

MODEL FREQUENCY

GPSU001

GPSU002

GPSU003

GPSU004

GPSU005

GPSU006

GPSU007

GPSU008

GPSU009

GPSU010

1575.4/450-470 MHz

CONN

MCX/FME

MMCX/FME

SMB/FME

None

SMA/FME

COLOR

White

Black

White

Black

White

Black

White

Black

White

Black

SPECIFICATIONS

FREQUENCY

LNA GAIN

TYPE

BANDWIDTH

PATTERN

VSWR

INPUT IMPEDANCE

POLARIZATION

COAX

DIMENSIONS

OPERATING TEMP

VOLTAGE

NOISE TEMP

1575.4 MHz

26 dBic ± 2 dB

Active

2 MHz Minimum

Hemispherical

<2:1

50 ohms

Right Hand Circular Polarized

RG174

2" Dia., .62" H.

-40º to 80º

5V DC

1.5 dB typical

SPECIFICATIONS

GAIN

TYPE

BANDWIDTH

PATTERN

VSWR

IMPEDANCE

POLARIZATION

COAX

DIMENSIONS

OPER TEMP

VOLTAGE

MOUNTING

2 dBi/26 dBic (LNA)

PCB/Active

22 MHz/ 2 MHz Min.

Omni/Hemispherical

2.0:1/1.5:1

50 ohms

Vertical/RHCP

19.7’ RG58/RG174

1.25” Hx4.5” Dx6.5” L

-40° to 85° C

5 V DC

Direct Feed 3/4” hole
