55D111X
Issue 3
26th November 2010
Specification Control Drawing
Page 1 of 2
Page 2 is for internal use only
ONE CONDUCTOR CABLE, MODIFIED FLUOROPOLYMER INSULATED, SHIELDED AND JACKETED,
LIGHTWEIGHT, 150°C, 600 VOLT
The complete requirements for procuring the wire described herein shall consist of this document.
Shield -
Silver Coated Copper, coverage 85% minimum
Component wire -
55D011X
Silver Plated High Strength
Copper Alloy (0) (size 26 and 24)
Silver Plated Copper (2) (size 22 to 12)
Jacket -
Radiation Crosslinked
Modified ETFE
C9
Part
Description
55D1110-26-*-*
55D1110-24-*-*
55D1112-22-*-*
55D1112-20-*-*
55D1112-18-*-*
55D1112-16-*-*
55D1112-14-*-*
55D1112-12-*-*
Wire
Size
Code
001
002
004
006
010
012
020
030
Shield
Size
(mm)
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
C10
Jacket
Thickness
Min. (mm)
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
C12
C13
C29
C14
NSN
6145-
99-
038-
4154
4155
4156
4157
4158
4159
4160
4161
Def Stan 61-12(Part 33)
Supplement 001 Table 9
OD
Max. (mm)
1.72
1.81
1.98
2.25
2.49
2.72
3.19
3.64
Weight
Max. (kg/km)
6.54
7.40
9.66
13.30
18.92
21.85
30.18
42.08
Overall
Diameter
(mm)
Target
Max.
1.49
1.59
1.59
1.69
1.76
1.86
1.99
2.09
2.27
2.42
2.41
2.56
2.75
2.95
3.21
3.41
Weight
kg/km
Target
Max.
5.40
6.05
6.41
7.10
8.28
9.04
11.67
12.61
15.56
17.15
19.01
20.58
25.23
28.17
37.75
40.44
COLOUR CODE:
NOTE:
The '*' in the part number shall be replaced by a standard colour code designator
in accordance with Mil Std 681.
e.g. 55D1112-24-9-9, core white, jacket white
Nato Stock Numbers (NSN) apply to white - white cable only.
PERFORMANCE
REQUIREMENTS:
To be tested to and meet the requirements of the issue in effect of
Def Stan 61-12(Part 33) and Supplement 001, Table 9.
MARKING
REQUIREMENT:
Every 400 ± 100 mm
Mark shall be, e.g. 55D111#-XX DSP33/001-1S-YYY-1SJ-*-*-GB-SS-V
Where:
"#" = Conductor material either 2 or 0 (see above part description)
"XX" = AWG size from part description
"YYY" = Wire Size Code
Colour Code Designator "*-*" is NOT required for white - white cable.
NOTE:
and
V" = the Year Code in accordance with the table below.
This drawing does not cover Armament cables, refer to 55DA111X
APPROVAL:
Electronic sign off - no signatures will appear.
©2010 Tyco Electronics Corporation. All International Rights Reserved.
