DEUTSCH 983 Series Connectors
CONTENTS
SECTION 1 :
Sealed Connectors
section 1-1 : sealed connectors standard
section 1-2 : sealed connectors with integral accessory
section 1-3 : arrangements
section 1-4 : PART-NUMBERING
STANDARD
ASD-STAN
9
10
12
14
17
SECTION 2 :
Hermetic Receptacles
section 2-1 : hermetic receptacles stainless steel
section 2-2 : arrangements
section 2-3 : PART-NUMBERING
STANDARD
ASD-STAN
21
22
24
27
SECTION 3 :
Backshells
section 3-1 : open backshells
section 3-2 : open backshells for K6 and Quadrax arrangements
section 3-3 : closed backshells for K6 and Quadrax arrangements
SECTION 4 :
Protective Covers
29
30
32
32
33
SECTION 5 :
Dummy Receptacles
35
SECTION 6 :
Panel Seals
37
SECTION 7 :
Mated & Unmated Dimensions
section 7-1 : for sealed connectors
section 7-2 : for sealed connectors with integral accessory
section 7-3 : for hermetic receptacles
SECTION 8 :
Contacts & Tooling
39
40
41
42
43
TE Components . . . TE Technology . . . TE Know-how . . .
AMP | AGASTAT | CII | HARTMAN | KILOVAC | MICRODOT | NANONICS | POLAMCO | Raychem | Rochester | DEUTSCH
SEACON Phoenix | LL Rowe | Phoenix Optix | AFP | SEACON
Get your product to market faster with a smarter, better solution.
AEROSPACE, DEFENSE & MARINE
/// DEUTSCH 983 SERIES CONNECTORS
PAGE 2
DEUTSCH 983 SERIES CONNECTORS
INTRODUCTION
TE Connectivity’s (TE) DEUTSCH 983 series connector was created in the 90’s.
This connector has been especially designed for harsh environment aircraft zone
applications such as engines and boosters.
Available in two versions, TE’s DEUTSCH 983 series connector is used in its stain-
less steel version on harsh constraint-facing areas such as engines, landing gears,
APU (Auxiliary Power Unit), wings, pylons, leading edges whereas the aluminum
version is used in cargo compartments.
Qualified to EN2997 specification for its stainless steel and aluminum version, TE’s
DEUTSCH 983 series is also qualified to ADS (Aerospace Defense and Security)
ESC10, Boeing BACC63 and Airbus ABS specifications. In addition, TE’s DEUTSCH
983 series is fully intermateable with MIL-DTL-83723 Series III connectors.
TE’s DEUTSCH 983 series connector uses contacts qualified to the EN3155 and
ADS ESC30 specifications.
TE’s DEUTSCH 983 Series connectors are distinguishable from MIL-DTL-83723
connectors by following improvements :
- Shell-to-shell metal bottoming (plug and receptacle mated)
- Anti-rotation system on 360° by tightening
- Self-locking system all plug
- Reduced elastomer barriers to use new and old generations of wires
All TE’s DEUTSCH 983 electrical connectors series are intermateable and interchan-
geable with connectors in accordance with MIL-DTL-83723 series III.
A large accessories range completes TE’s DEUTSCH 983 connector series :
- Backnut
- Straight cable clamp
- 90° cable clamp
HIGH RELIABILITY
• Self-locking system
HARSH ENVIRONMENT
RESISTANCE
• High temperature operating (260°C)
• Fireproof inserts (thermoset and
fluorinated silicon)
• Fluid resistant inserts
APPLICATION-MATCHED
VERSIONS
• Sealed stainless steel
• Sealed aluminum
• Hermetic stainless steel
• Hermetic aluminum
HERMETIC ALUMINUM
IMPROVED PERFORMANCES
• Aluminum shell (weight saving)
• Nickel plated shells (better
continuity)
• Copper alloy contacts (higher
intensity)
• Glass-to-metal sealing
3
1
2
4
5
6
7
8
LARGE ACCESSORIES RANGE
• Backnut
• Straight cable clamp
• 90° cable clamp
• Custom design
1 Connector’s rear part fitted with
a teeth anti-rotation system (360°)
assuming an effective tightening
and clamping of accessories / EMI
shielding improvement
2 Self locking control
3 Shell to shell metal bottoming
4 RFI grounding fingers for electrical
continuity between plug and receptacle
5 Individual contact sealing at coupling
stage by compression of elastomer
conical risers on hard insert
6 Interface sealing assumed by
High Frequency (H.F.) gasket
7 Shell/insert assumed by potting
8 Sealing on each wire thanks to several
sealing barriers
AEROSPACE, DEFENSE & MARINE
/// DEUTSCH 983 SERIES CONNECTORS
PAGE 3
