3635BR30PT: Description1 ELEMENT, 0.0008uH, IRON-CORE, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT; CategoryPassive components inductor; File Size99KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

3635BR30PT Overview

1 ELEMENT, 0.0008uH, IRON-CORE, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT

3635BR30PT Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	4949
Reach Compliance Code	unknow
ECCN code	EAR99
uppercase and lowercase codes	4949
structure	Chi
core material	IRON
DC Resistance	0.0008 Ω
Nominal inductance(L)	0.0008 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3635
Number of functions	1
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package height	5 mm
Package length	12.5 mm
Package form	SMT
Package width	12.5 mm
method of packing	TR
Maximum rated current	38 A
series	3635
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	25%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

Passive C omponents

>

Product Feature Selector

> Product Details

3635BR30PT Product Details

Live Product Chat

Inductors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3635BR30PT

(1-1676949-6)

T E I nternal N umber: 1 - 1 6 7 6 9 4 9 - 6

Product Highlights:

l

Inductor

l

Inductor Type = Shielded Power Wirewound

l

Lead Type = Surface Mount Terminals

l

Wirewound

l

Inductance = .3 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

SHIELDED SMD POWER INDUC TORS SERIES 3635

(PDF, English)

Catalog Pages/Data Sheets:

l

Shielded SMD Power Inductor - Type 3635 Series - Tyc...

(PDF, English)

Product Specifications:

l

None Available

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

Product Type

= Inductor

l

Inductor Type = Shielded Power Wirewound

l

Element

= Wirewound

l

Shielded

= Yes

Electrical Characteristics:

l

Inductance (?H)

= 0.3

l

DC Resistance (?)

= 0.0008

l

C urrent, Maximum (mA)

= 38000

l

Package Type

= Taped and Reeled

l

Tolerance (%) = 25

Body Related Features:

l

Lead Type

= Surface Mount Terminals

l

Series

= 3635

l

Package, C omponent Size

= 12.5 x 12.5

l

Mount Style

= Surface Mount

Industry Standards:

l

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

l

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

l

RoHS/ELV C ompliance History = Always was RoHS compliant

Operation/Application:

l

Application

= High Power C ircuitry

Other:

l

Brand = Sigma Inductors

Additional Information:

l

Product Line Information

3635BR30PT Related Products

	3635BR30PT	1-1676949-6
Description	1 ELEMENT, 0.0008uH, IRON-CORE, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT	1 ELEMENT, 0.3uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
Reach Compliance Code	unknow	unknow
ECCN code	EAR99	EAR99
DC Resistance	0.0008 Ω	0.0008 Ω
Nominal inductance(L)	0.0008 µH	0.3 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3635	3635
Number of functions	1	1
Number of terminals	2	2
Maximum rated current	38 A	38 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	YES	YES
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	25%	25%
Base Number Matches	1	1
