5011204-3 Product Details
Live Product Chat
Drawer Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5011204-3
T E I nternal N umber: 5 0 1 1 2 0 4 - 3
Product Highlights:
l
C onnector
l
Receptacle
l
Drawer Style = Micro
l
30 Positions
l
Preloaded
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Receptacle
l
Number of Positions
= 30
l
Mount
= Panel, Printed C ircuit Board
l
Proprietary Name = C HAMP
l
C onnector Type = Blindmate
l
Panel Thickness (mm [in]) = 0.79 – 1.20 [0.031 – 0.047]
l
PC B Mount Angle = Vertical
l
Retention Leg Material = Brass
Mechanical Attachment:
l
Preloaded
= Yes
l
Retention Leg Plating = Tin
l
Tine Plate Material = PPA, 33% Glass-Filled
Electrical Characteristics:
l
High C urrent
= No
Termination Related Features:
l
Solder Tail C ontact Plating = Tin over Nickel
Body Related Features:
l
Drawer Style
= Micro
l
C enterline (mm [in]) = 1.00 [0.039]
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
l
C ontact Finish = Gold (30) over Nickel (50), Gold Flash over
Palladium Nickel over Nickel
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
l
Housing C olor = Black
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C , Reflow
solder capable to 245?C , Reflow solder capable to 260?C , Pin-in-
Paste capable to 245?C , Pin-in-Paste capable to 260?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = Tyco Electronics
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
