SLCC (CNP)
Vishay Sfernice
Hermetic, 50 Mil Pitch, Leadless Chip Resistor Networks
FEATURES
•
High stability ultrafilm (0.05 % at 1000 h at
+ 70 °C under Pn)
•
Custom available (CNP)
•
Low noise < 35 dB
•
SMD
•
Hermetic package
Actual Size
•
Leadless chip carrier
•
10
Ω
to 100 kΩ
•
Compliant to RoHS directive 2002/95/EC
•
Halogen-free according to IEC 61249-2-21 definition
Capable of meeting the characteristics of MIL-PRF-83401
these networks are available in a wide range of resistance
values: several standard configurations are presented with
the SLCC series.
TYPICAL PERFORMANCE
ABS
TCR
TOL.
25 ppm/°C
ABS
0.1 %
TRACKING
2 ppm/°C
RATIO
0.1 %
Resistance Range: Noted on schematics
SCHEMATIC
SLCC 20 A01
1 kΩ - 100 kΩ
13 12 11 10 9
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
14
15
16
17
18
19 20 1 2 3
SLCC 20 A03
1 kΩ - 100 kΩ
13 12 11 10 9
8
7
6
5
4
14
15
16
17
18
SLCC 20 A06
1 kΩ - 100 kΩ
13 12 11 10 9
8
7
6
5
4
19 20 1
2 3
SLCC 20A
(10 Isolated Resistors)
10
Ω
- 100 kΩ
13 12 11 10 9
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
14
15
16
17
18
SLCC 20B
(19 Resistors + 1 Common Point)
10
Ω
- 100 kΩ
13 12 11 10 9
8
7
6
5
4
19 20 1 2 3
Gold Terminals
Option: Tin/silver plating: 076
Notes
• For values outside ohmic range please consult Vishay/Sfernice
• For custom networks a specific part number is used CNPxxxx. Please consult Vishay/Sfernice
document number: 60014
Revision: 20-Aug-09
For technical questions, contact:
sfer@vishay.com
www.vishay.com
97
SLCC (CNP)
Vishay Sfernice
Hermetic, 50 Mil Pitch, Leadless Chip Resistor Networks
STANDARD ELECTRICAL SPECIFICATIONS
TEST
PIN NUMBER
TCR:
Tolerance:
Power rating:
Tracking
Absolute
Ratio
Absolute
Resistor
Package
SPECIFICATIONS
20
± 2 ppm/°C (typical)/5 ppm/°C maximum
± 25 ppm/°C maximum
± 0.1 % to 1.0 % tighter specs on request
± 0.1 % to 5.0 % tighter specs on request
50 mW
500 mW
0.05 %
< 0.1 ppm/V
100 V
DC
on
R
- 55 °C to + 155 °C
- 55 °C to + 155 °C
- 35 dB typical
0.1 µV/°C
< 50 ppm
CONDITIONS
- 55 °C to + 155 °C
- 55 °C to + 155 °C
Stability (ΔR ratio)
Voltage coefficient
Working voltage
Operating temperature range
Storage temperature range
Noise
Thermal EMF
Shelf life stability
at + 70 °C
at + 70 °C
1000 h at + 70 °C under Pn
1 year at + 25 °C
DIMENSIONS
in millimeters [inches]
B
SLCC-20A06
1K
D
max.
G
typ.
R typ.
Terminal #1
Indicator
C
Terminal
#1
A
typ.
F
E
typ.
H
Index
Corner
A
B
C
D
E
F
G
H
20 Pin
1.27 [0.050]
8.89 [0.350]
8.89 [0.350]
1.96 [0.077]
0.635 [0.025]
1.27 [0.050]
1.02 [0.040]
0.508 [0.020]
PACKAGING
Tape and reel 250 pieces per tape
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: SLCC20A01-10KF005
AO
F
S
L
C
C
2
0
A
0
1
-
1
0
K
F
T
0
0
5
GLOBAL MODEL
SLCC20
SCHEMATIC
A
B
A01
A03
A06
VALUE
Decimal
R, K
or
M
TOL.
B
(0.1 %
D
(0.5 %
F
(1.0 %
G
(2.0 %
J
(5.0 %
0.1 %)
0.25 %)
0.5 %)
1.0 %)
1.0 %)
PACKAGING
T:
Tape and reel
Blank:
Tube
OPTION
Leave blank
if no option
For custom specification:
CNP
GLOBAL MODEL
1186
REFERENCE
Reference is assigned by Vishay/Sfernice
Historical Part Number example: SLCC 20 A01 10K F R0005 e4
SLCC 20
GLOBAL MODEL
A01
SCHEMATIC
10K
VALUE
F
TOL.
R0005
OPTION
Leave blank
if no option
www.vishay.com
98
For technical questions, contact:
sfer@vishay.com
document number: 60014
Revision: 20-Aug-09
e4
RoHS
