CSM2512S
Vishay Foil Resistors
Bulk Metal
®
Technology High Precision, Current Sensing, Power Surface
Mount, Metal Strip Resistor with Improved Stability 0.05 %, Resistance
Value from 10 mΩ, Rated Power to 1 W and TCR to 0 ± 15 ppm/°C
FEATURES
•
Temperature coefficient of resistance (TCR):
(- 55 °C to + 125 °C, + 25 °C ref.)
± 15 ppm/°C maximum
± 10 ppm/°C maximum on special request
•
Load life stability to ± 0.05 % (70 °C, 2000 h
at rated power)
•
Power rating: 1 W
•
Tolerance: ± 0.1 %
•
Resistance range: 10 mΩ to 100 mΩ
•
Vishay Foil resistors are not restricted to standard values,
we can supply specific “as required” values at no extra cost
or delivery (e.g. 10.2345 mΩ vs. 10 mΩ)
•
Short time overload: ± 0.1 % typical
•
Thermal EMF: < 3 µV/°C
•
Maximum current: up to 10 A
•
Surface mount configuration
•
Four terminal (Kelvin) design: allows for precision accurate
measurements
•
Terminal finish: lead (Pb)-free, tin/lead alloy
•
Compliant to RoHS directive 2002/95/EC
•
Prototype samples available from 72 h. For more
information, please contact
foil@vishay.com
•
Screening in accordance with EEE-INST002 available
(MIL-PRF 55342 and MIL-PRF 49465)
•
For better performances please contact us
The CSMS series of low value current sense resistors
provides power and precision in a four terminal, surface
mount configuration. Its all welded construction is made
up of a Bulk Metal
®
resistive element with plated copper
terminations.
Our application engineering department is available to
advise and make recommendations.
For non-standard technical requirements and special
applications, please contact us.
IM
PR
O
VE
D
R
I
I
I
1
E
1
E
2
I
2
V
Percent of Rated Power
TABLE 1 - PERFORMANCE SPECIFICATIONS
PARAMETER
Resistance Range
Maximum Current
Power Rating at 70 °C
Maximum Working Voltage
Tightest Tolerance
Temperature Coefficient Maximum (- 55 °C to + 125 °C, + 25 °C ref.)
Operating Temperature Range
Weight (maximum)
* Pb containing terminations are RoHS compliant, exemptions may apply
Document Number: 63145
Revision: 14-May-09
For any questions, contact:
foil@vishay.com
PR
O
DU
CT
FIGURE 1 - POWER DERATING CURVE
+ 70 °C
100
80
60
40
20
0
- 65 - 50
- 25
0
25
50
75
100
125
150
170
Ambient Temperature (°C)
CSM2512S
10 mΩ to 100 mΩ
1W
10 A
(P x R)
1/2
± 0.1 %
± 15 ppm/°C, ± 10 ppm/°C is available
- 65 °C to + 170 °C
0.09 g
www.vishay.com
1
CSM2512S
Vishay Foil Resistors
FIGURE 2 - DIMENSIONS AND IMPRINTING
in inches (millimeters)
CSM2512S DIMENSIONS
(1)
CSM2512S LAND PATTERN
I
1
H
B
L
T
W
A
DIMENSIONS - TOLERANCES ± 0.010 (± 0.254), * ± 0.015 (± 0.381)
RESISTANCE RANGE (Ω)
0.01 to 0.1
L
0.250 (6.350)
W
0.125 (3.175)
H
T
0.025 (0.635)
LAND PATTERN DIMENSIONS - TOLERANCES ± 0.003 (± 0.076)
RESISTANCE RANGE (Ω)
0.01 to 0.1
a
0.065 (1.65)
b
0.145 (3.68)
c
d
0.045 (1.14)
Note
(1)
White dot indicates top side of part for mounting purposes
TABLE 2 - CSM2512S PERFORMANCE SPECIFICATIONS
IM
PR
O
VE
D
TEST
CONDITIONS
Thermal Shock
- 55 °C to + 150 °C, 1000 cycles, 15 min at
each extreme
2000 h, 70 °C at rated power
85 °C, 85 % humidity
10 % bias, 1000 h
Load Life Stability
Bias Humidity
Short Time Overload
5 x rated power for 5 s
1000 h, 170 °C
High Temperature Exposure
Low Temperature Storage
Moisture resistance
Shock
MIL-PRF-49465
MIL-STD-202, method 106, 0 % power,
7a and 7b not required
100 g, 6 ms
Vibration
(10 Hz to 2000 Hz) 20 g
10 s to 12 s at + 260 °C
MIL-STD-202
Resistance to Soldering Heat
Solderability
www.vishay.com
2
For any questions, contact:
foil@vishay.com
PR
O
DU
CT
e
E
1
E
2
I
2
d
c
I
Kelvin Connection
I
1
, I
2
- Current
E
1
, E
2
- Sense
a
b
A
B
0.030 (0.762)
0.030 (0.762)*
0.032 (0.813)*
e
l
0.021 (0.53)
0.055 (1.39)
0.160 (4.06)
MIL-PRF-49465B
ΔR
LIMITS
± (0.5 % + 0.0005R)
± (1.0 % + 0.0005R)
± (0.5 % + 0.0005R)
± (0.5 % + 0.0005R)
± (1.0 % + 0.0005R)
± (0.5 % + 0.0005R)
± (0.5 % + 0.0005R)
± (0.1 % + 0.0005R)
± (0.1 % + 0.0005R)
± (0.25 % + 0.0005R)
95 % coverage
TYPICAL
ΔR
LIMITS
0.1 %
0.05 %
0.05 %
0.1 %
0.2 %
0.05 %
0.02 %
0.02 %
0.02 %
0.05 %
-
MAXIMUM
ΔR
LIMITS
0.2 %
0.2 %
0.2 %
0.2 %
0.3 %
0.1 %
0.05 %
0.05 %
0.05 %
0.1 %
Document Number: 63145
Revision: 14-May-09
CSM2512S
Vishay Foil Resistors
TABLE 3 - GLOBAL PART NUMBER INFORMATION
NEW GLOBAL PART NUMBER: Y44870R10000B0R (preferred part number format)
DENOTES PRECISION
Y
VALUE
R
=
Ω
CHARACTERISTICS
(1)
0
= standard part, tin/lead termination
9
= standard part, lead (Pb)-free termination
1 - 999
= custom
Y
4
4
8
7
0
R
PRODUCT CODE
4487
= CSM2512S
RESISTANCE TOLERANCE
B
C
D
F
= ± 0.1 %
= ± 0.25 %
= ± 0.5 %
= ± 1.0 %
FOR EXAMPLE: ABOVE GLOBAL ORDER Y4487 0R10000 B 0 R:
TYPE: CSM2512S
VALUE: 100.0 mΩ
ABSOLUTE TOLERANCE: ± 0.1 %
TERMINATION: standard tin/lead
PACKAGING: tape and reel
HISTORICAL PART NUMBER: CSM2512S 0R1000 B B T (will continue to be used)
CSM2512S
MODEL
0R1000
OHMIC VALUE
0R1000
= 0.100
Ω
B
ABS. TOLERANCE
B
C
D
F
= ± 0.1 %
= ± 0.25 %
= ± 0.5 %
= ± 1.0 %
IM
PR
O
VE
D
Note
(1)
For non-standard requests, please contact application engineering.
Document Number: 63145
Revision: 14-May-09
For any questions, contact:
foil@vishay.com
PR
O
DU
CT
1
0
0
0
0
B
0
R
PACKAGING
W
= waffle pack
R
= tape and reel
B
T
TERMINATION
S
= lead (Pb)-free
B
= tin/lead
PACKAGING
T
= tape and reel
W
= waffle pack
www.vishay.com
3
