CrystalFree™ Oscillator
Ultra Low Power Oscillators
3CP02
PRELIMINARY DATA SHEET
Features
Frequency Range:
Output Type:
Frequency Tolerance:
Supply Voltage:
Power Consumption:
Standby Current:
Standard Package:
Operating Temperature:
4 to 133 MHz
CMOS
± 100 ppm
1.8 to 3.3 V
1.9 mA
(1.8 V)
< 1 uA
5.0 x 3.2 mm
0 to 70 °C
-20 to 70 °C
This product is rated “Green”, please contact
factory for environmental compliancy information
Specification
Specifications
Conditions
2.5 V
3.3 V
Nominal
4 to 133 MHz
See ordering code
± 100 ppm
Total Frequency Stability*
1.9 mA
2.0 mA
2.2 mA
Typical; No load condition; 25°C
1 uA
STBY# = GND
0.3 VDD (max)
At STBY# pin
0.7 VDD (min)
0.1 VDD (max)
I
OL
= - 1mA
0.9 VDD (min)
I
OH
= 1mA
2.75ns
2.3ns
1.9ns
20% to 80% x VDD. Output load (CL) = 4pF
45% / 55%
For frequencies < 100MHz;
SYM
Symmetry
40% / 60%
For frequencies > 100MHz;
Start-up time
T
ST
Output valid time after VDD meets the specified range & STBY# transition
100 us
Period Jitter
PJ
RMS
4pF load; 75MHz
17 ps
6 ps
5 ps
Cycle to Cycle Jitter
CCJ
MAX
120 ps
50 ps
40 ps
4pF load; 75MHz
* Stability over temperature, supply variation, 3x reflow, load variation, aging (10 years)
1.8 V
Parameter
Supply Voltage
Output Frequency
Frequency Stability
Supply Current
Quiescent Current
Input LOW level
Input HIGH level
Output LOW level
Output HIGH level
Rise/Fall Time
Symbol
VDD
F
OUT
F
STB
IDD
I
STBY
V
IL
V
IH
V
OL
V
OH
T
R
/T
F
Package Outline and Dimensions
Typical PCB Land Pattern
3.20 ±0.05
0.90 ±0.05
1.20 ±0.05
Pin #1 ID
Chamfer
0.5 x 45°
0.85 ±0.05
0.0-0.05
2.2
5.0 x 3.2
(mm)
STBY#
5.0 x 3.2mm
VDD
2.5
4L SMD
5.00 ±0.05
2.54
GND
0.203 Ref.
OUT
1.4
1.6
Top View
Bottom View
Side View
April 1, 2011
www.IDT.com
©2011 Integrated Device Technology, Inc
3CP02 Datasheet
CrystalFree™ Oscillator
Absolute Maximum Ratings
Temperature (°C)
Stresses beyond those listed under
Absolute Maximum Ratings
may cause permanent damage to the device. These ratings are
stress specifications only. Functional operation of product at
these or under any condition beyond those listed in the
operating specifications is not implied. Exposure to absolute
maximum rated conditions may affect product reliability.
Item
VDD
STBY#
OUT
Storage Temperature
Solder Reflow Profile
40 sec (max)
250
200
150
100
50
150°C
60-180
sec
(260°C max)
245°C
217°C
s c
sec
°
/
6
°
C
60-150
sec
a
ma x
4.6V
-0.5V to VDD + 0.5V
-0.5V to VDD + 0.5V
-65°C to 150°C
3
°
C/
se
Maximum Absolute Rating
cm
ax
Time
Pin Descriptions
Pin #
1
2
3
4
Output Wave Form
Description
T
R
0.8 VDD
T
F
V
OH
Name
STBY#
GND
OUT
2
VDD
Standby Mode
1
(0 = Output Disabled)
Ground
CMOS Output
Power
0.5 VDD
1. Pulled high internally
2. Weak pull down to GND during STBY# enable and startup
0.2 VDD
V
OL
SYM = t
1
/ t
2
t
1
t
2
Ordering Information
3CP02 -
Frequency
4 to 133MHz
7.15909
14.3182
133.000
NS
Temp
C:
E:
0 to 70°C
-20 to 70°C
E
8
Shipping
Blank: Tubes
8:
Tape and Reel
6024 Silver Creek Valley Road
San Jose, California 95138
Sales
800-345-7015 (inside USA)
+1 408-284-8200 (outside USA)
Fax: 408-284-2775
Technical Support
crystalfreetechsupport@idt.com
+408-739-5400
