8-1617540-5

Description
POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.013A (COIL), 26.5VDC (COIL), 351mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT
CategoryMechanical and electronic products    relay
File Size128KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

8-1617540-5 Online Shopping

Suppliers Part Number Price MOQ In stock
8-1617540-5 - - View Buy Now

8-1617540-5 Overview

POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.013A (COIL), 26.5VDC (COIL), 351mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT

8-1617540-5 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codecompliant
ECCN codeEAR99
Factory Lead Time28 weeks 6 days
Other featuresWITH COIL SUPPRESSION DIODE
body height7.11 mm
Body length or diameter9.4 mm
Maximum coil current (DC)0.013 A
Coil operating voltage (DC)14.4 V
Coil power351 mW
Coil release voltage (DC)8 V
Coil resistance2000 Ω
Maximum coil voltage (DC)26.5 V
Nominal coil voltage26.5 V
Coil/Input Power TypeDC
Maximum contact current (AC)1 A
Maximum contact current (DC)1 A
Contact (DC) maximum rated R load1A@28VDC
Maximum contact voltage (DC)28 V
Contact/Output Power TypeDC
Electrical life100000 Cycle(s)
Input switching control typeRandom
Installation featuresTHROUGH HOLE-STRAIGHT MOUNT
Number of terminals8
operating hours2 ms
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
physical size9.4mm x 7.11mm
Relay actionMOMENTARY
Relay style1 FORM C
Relay functionSPDT
Relay typePOWER/SIGNAL RELAY
release time7.5 ms
sealHERMETICALLY SEALED
surface mountNO
Terminal length0.038 inch
Termination typeSOLDER
Base Number Matches1

Preview

Download Datasheet
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Relays > Product Feature Selector > Product Details
J1MAWT­26XL Product Details
Military/Aerospace High Performance Relays
Not EU RoHS or ELV Compliant
 (
Find RoHS Compliant Alternates
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
1MAT TO­5 Relay Series
Input Voltage = 26.5 VDC
Contact ­ Arrangement = 1 Form C, SPDT, 1 C/O
Contact ­ Rated Current = 1 A
Non Polarized, Monostable Coil ­ Magnetic System
J1MAWT­26XL
(8­1617540­5)
TE Internal Number: 8­1617540­5
View all Features
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
MOSFET Driver = Without
Mechanical Attachment:
Mounting Options = PC Board
Electrical Characteristics:
Input Voltage (VDC) = 26.5
Contact ­ Rated Current (A) = 1
Coil Suppression Diode = With
Coil Polarity Protection Diode = Without
Coil ­ Resistance (Ω) = 2000
Coil Power Measurement = Milliwatts
Coil ­ Rated Power, DC (mW) = 351
Actuating System = DC
Shock = 75 G's, 6ms
Vibration = 30G's, 10 to 3000Hz
Termination Features:
Termination Type = Long Leads
Body Features:
Enclosure Type = Hermetically Sealed
Configuration Features:
Contact ­ Arrangement = 1 Form C, SPDT, 1 C/O
Coil ­ Magnetic System = Non Polarized, Monostable
Transistor Driver = With
Industry Standards:
Government/Industry Qualification = Yes
Government/Industry Part Number = M28776/5­018L
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Not suitable for lead free processing
Approved Standards = M28776 Qualified, L Level
Conditions for Usage:
Temperature Range (°C) = ­65 – +125
Other:
Series = 1MAT TO­5 Relay
Brand = CII
