積層メタライズドポリエステルフィルムコンデンサ
SMC
シリーズ
SERIES
◆特 長／FEATURES
MULTILAYER METALLIZED POLYESTER FILM CAPACITORS
SMC
•
積層構造の小型、½量のコンデンサです。
•
自己回復性があり、信頼性が高いコンデンサです。
•
Construction of Multilayer, small and light.
•
This capacitors provide self-healing.
◆規 格／SPECIFICATIONS
カテゴリ温度/
Category temperture
定格電圧/
Rated voltage (U
R
)
静電容量許容差/
Capacitance tolerance
誘電正接/
tanδ
耐電圧/
Voltage proof
絶縁抵抗/
Insulation resistance
準拠規格/
Reference standard
※−40℃∼＋105℃
DC63V, 100V, 250V
±5%(J), ±10%(K)
0.01 max at 1kHz
U
R
×150% 60s
>
0.33μF = :9000MΩmin
0.33μF < :3000ΩFmin
EIAJ RC-2343 JIS C 5101-1
◆寸法図／DIMENSIONS (mm)
A max
B max
C max
20min
F±0.8
2.0 max
φd±0.05
※定格温度（＋85℃）を超えて½用の場合P182、図-3に示す電圧½減を
行って下さい。
Derate the voltage as shown in the figure 3(182page),
when using the capacitor beyond 85℃.
◆標準品／STANDARD PRODUCTS
品 番
Part No.
SMC 103
SMC 123
SMC 153
SMC 183
SMC 223
SMC 273
SMC 333
SMC 393
SMC 473
SMC 563
SMC 683
SMC 823
SMC 104
SMC 124
SMC 154
SMC 184
SMC 224
SMC 274
SMC 334
SMC 394
SMC 474
SMC 564
SMC 684
SMC 824
SMC 105
SMC 125
SMC 155
SMC 185
SMC 225
静電容量
cap(μF)
0.01
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.1
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
DC 63V
A
B
C
F
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 3.8 6.5 5.0
7.3 4.0 6.5 5.0
7.3 4.2 6.5 5.0
7.3 4.7 6.5 5.0
7.3 5.5 6.5 5.0
7.3 5.5 6.5 5.0
7.3 5.5 6.5 5.0
7.3 5.5 6.5 5.0
10.0 4.0 10.0 7.5
10.0 4.0 10.0 7.5
10.0 5.0 10.0 7.5
10.0 5.5 10.0 7.5
10.0 6.5 10.0 7.5
10.0 7.0 10.0 7.5
10.0 8.0 10.0 7.5
10.0 8.5 10.0 7.5
10.5 9.0 12.0 7.5
10.5 9.0 13.0 7.5
10.5 9.5 13.0 7.5
11.0 10.0 13.5 7.5
: 定格電圧/Rated voltage
DC 100V
A
B
C
F
d
d
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 3.8 6.5 5.0 0.5
0.5 7.3 4.5 6.5 5.0 0.5
0.5 7.3 5.0 6.5 5.0 0.5
0.5 10.0 3.5 8.5 7.5 0.5
0.5 10.0 4.0 10.0 7.5 0.5
0.5 10.0 4.4 10.0 7.5 0.5
0.5 10.0 4.7 10.0 7.5 0.5
0.5 10.0 5.0 10.0 7.5 0.5
0.5 10.0 6.5 10.0 7.5 0.5
0.5 10.0 7.5 10.0 7.5 0.5
0.5 10.0 8.0 10.0 7.5 0.5
0.5 10.0 8.5 11.0 7.5 0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
: 静電容量許容差/Capacitance tolerance
DC 250V S(5mmピッチ) DC 250V L(7.5mmピ チ)
ッ
A
B
C
F
d
A
B
C
F
d
7.5 3.8 6.5 5.0 0.5
7.5 3.8 6.5 5.0 0.5
7.5 3.8 6.5 5.0 0.5 10.0 4.0 6.0 7.5 0.5
7.5 3.8 6.5 5.0 0.5 10.0 4.5 7.0 7.5 0.5
7.5 5.0 7.0 5.0 0.5 10.0 4.5 7.0 7.5 0.5
7.5 5.0 8.0 5.0 0.5 10.0 5.0 7.0 7.5 0.5
7.5 5.0 8.0 5.0 0.5 10.0 4.5 6.5 7.5 0.5
7.5 6.0 8.5 5.0 0.5 10.0 4.5 7.5 7.5 0.5
7.5 6.0 8.5 5.0 0.5 10.0 4.5 7.5 7.5 0.5
10.0 5.5 8.0 7.5 0.5
10.0 5.5 8.0 7.5 0.5
10.0 5.5 8.0 7.5 0.5
10.0 5.5 9.0 7.5 0.5
10.0 6.0 10.0 7.5 0.5
10.0 7.0 10.5 7.5 0.5
10.5 8.5 11.0 7.5 0.5
10.5 9.5 12.0 7.5 0.5
