250SXR220MEFCSN22X35: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 250V, 20% +Tol, 20% -Tol, 220uF, Through Hole Mount, CAN, ROHS COMPLIANT; CategoryPassive components capacitor; File Size78KB，2 Pages; Manufacturerrubycon; Websitehttp://www.rubycon.co.jp/cn/; Environmental Compliance

Download Datasheet Parametric View All

250SXR220MEFCSN22X35 Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 250V, 20% +Tol, 20% -Tol, 220uF, Through Hole Mount, CAN, ROHS COMPLIANT

250SXR220MEFCSN22X35 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1872955220
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	220 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
leakage current	0.70356 mA
Manufacturer's serial number	SXR
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-25 °C
Package shape	CYLINDRICAL PACKAGE
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	250 V
ripple current	980 mA
surface mount	NO
Delta tangent	0.2
Terminal surface	Tin (Sn)
Terminal shape	SNAP-IN

Preview

Download Datasheet

View All

FINAL ACCEPTED ORDER DATE [2012/09]

LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS

SXR

SERIES

105

o

C , Overvoltage Vent Operation Facility,

Snap-in Terminal Type

FEATURES

•

Load Life : 105

°C

2000 hours.

•

This series has specification of vent operation in overvoltage situation. Please consult

us for any further details.

•

RoHS compliance.

SPECIFICATIONS

Items

Category Temperature Range

Rated Voltage Range

Capacitance Tolerance

Characteristics

-

25

∼

+

105

°

C

250, 450V.DC

+

-

20％ (20

°

C,

I=

3 CV

(After 5 minutes application of rated voltage)

120Hz)

Leakage Current(MAX)

I=

Leakage Current

(µA)

C=

Rated Capacitance

(µF)

V=

Rated Voltage

(V)

(tan

δ

)

Dissipation Factor(MAX)

Impedance Ratio(MAX)

Rated Voltage

(V)

°

C）（20

°

C）

Z

-

25

（

/Z

250

3

450

8

0.20(20

°

C, 120Hz)

(120Hz)

After applying rated voltage with rated ripple current for 2000hrs at 105

°

C

, the capacitors shall meet the following requirements.

Capacitance Change

Endurance

Dissipation Factor

Leakage Current

Within

+

-

20％ of the initial value.

Not more than 200％ of the specified value.

Not more than the specified value.

MULTIPLIER FOR RIPPLE CURRENT

Frequency coefficient

Frequency

Hz）

（

Coefficient

250WV

450WV

60 50） 120

（

0.80 1.00

500

1.10

1.05

1k 10k <

=

1.14 1.18

1.10 1.15

PART NUMBER

SXR

Rated Voltage

Series

Rated Capacitance

Capacitance Tolerance

Option

SN

Terminal Code

D

×

L

Case Size

Option

Code

PET Sleeve without plate

PVC Sleeve without plate

PVC Sleeve with plate

DIMENSIONS

SN [4(3.5)mm] terminal type

(mm)

EFC

OOE

Blank

VENT

SLEEVE

2-

φ

2

NEGATIVE

10

±0.1

+

L

-

2

∗

+

0.5

4

-

+

∗

For

φ

35, 3.5

-

0.5

φ

D

+

1

-

φ

D

+

1

-

MOUNTING HOLES
