CARDINAL COMPONENTS
Surface Mount Clock Oscillator
●
●
●
●
5.0 mm x 3.2 mm x 1.2 mm
Low power consumption
Tight stability available
Tri-state capable
Series CC532
Instrument Part Number:
CC532
SERIES
CC532
CC532 L Z - A1 B2 45 - 33.333 TS
Z
A1
OPERATING TEMP
Blank = 0°C ~ +70°C
A1 = -10°C ~ +70°C
L
VOLTAGE
Blank = 5V
L = 3.3V
E = 3.0V
B2
STABILITY
Blank = ±100 PPM
B2 = ±50 PPM
45
SYMMETRY
Blank = 40 / 60%
45 = 45 / 55%
33.333
FREQUENCY
0.0137 ~ 133.0 MHz
TS
TRI-STATE
TS = Tristate Standard
PACKAGING
Blank = Bulk Pack
Z = Tape and Reel
Specifications:
Description
Frequency Range:
Available Stability Options:
Output Format
Low Output Voltage:
High Output Voltage:
Output Load:
Input Voltage:
(Standard)
(Standard)
Min
13.7 KHz
-100.0
-50.0
Typ
-
-
-
HCMOS
Max
133.00 MHz
100.0
50.0
Unit
PPM
PPM
PACKAGE OUTLINE
-
V
DD
* 0.9
-
-
15
V
DD
* 0.1
-
V
V
pF
Pin #
1
2
3
4
Function
Tri-state
GND
Output
V
DD
4.5
2.97
2.7
3.6
2.2
-
-
40
45
-40
-10
5.0
3.3
3.0
-
-
-
-
-
-
-
-
5.5
3.63
3.3
-
-
0.8
10
60
55
+85
+70
V
V
V
V
V
V
ns
%
%
°C
°C
Tri-state Enable:
Tri-state Disable:
Rise/Fall Time:
Duty Cycle:
Storage Temperature Range:
(@ 5V)
(@3.3V)
For optimal performance, place a by-pass capacity of 0.1μF as close to the
part as possible between V
DD
and GND pads
Operating Temperature Range:
Cardinal Components
1801 Broadway Street
Charlottesville, VA 22902
1 of 1
Telephone: (973)785-1333
Email: sales@cardinalxtal.com
Website: www.cardinalxtal.com
