5-353297-9 Product Details
Live Product Chat
Product View
1.5mm AMP Mini CT Connectors
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-353297-9
T E I nternal N umber: 5 - 3 5 3 2 9 7 - 9
Product Highlights:
l
Post Header
l
C onnector Type = DIP
l
Number of Positions = 9
l
Without Panel Attachment
l
Terminate To Printed C ircuit Board
View all Features
Superseded
Search for Replacement Parts
View 3D PDF
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
PERSONAL SYSTEMS PRODUC TS
(PDF, English)
Product Specifications:
l
AMP Mini C ommon Termination (C T) C onnector 1.5mm Pit...
(PDF, English)
l
AMP Mini C ommon Termination(C T) C onnector
(PDF, English)
l
AMP Mini C ommon Termination (C T) C onnector 1.5mm Pit...
(PDF, English)
Application Specifications:
l
AMP Mini C ommon Termination (C T) C onnector 1.5mm Pit...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version E)
l
3D Model
(IGES, Version E)
l
3D Model
(STEP, Version E)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Post Header
l
C onnector Type
= DIP
l
Number of Positions
= 9
l
PC B Mount Angle
= Vertical
l
PC B Mount Style
= Through Hole
l
C olor
= Blue
l
PC B Retention Feature
= Yes
l
PC B Mount Polarization
= With
l
Post Size (mm [in]) = 0.50 [.020]
l
PC B Thickness (mm [in]) = 1.60 [0.063]
l
PC B Mount Polarization Type = Mounting Boss
Mechanical Attachment:
l
Panel Attachment
= Without
Body Related Features:
l
Number of Rows
= 1
l
PC B Retention Method = Boardlock(s)
l
C enterline (mm [in]) = 1.50 [0.059]
Contact Related Features:
l
C ontact Base Material = Brass
l
C ontact Mating Area Plating Material = Tin-Lead
l
C ontact Shape = Square
Housing Related Features:
l
Housing Material = Nylon GF
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Packaging Related Features:
l
Packaging Method
= Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
