8000 Series D-Subminiature
High Density Solder Cup
PLUG
B
A
C
5
1
1
6
11
RECEPTACLE
B
SEE MOUNTING
STYLE OPTIONS
A
C
SEE MOUNTING
STYLE OPTIONS
.156 [3.96]
6
11
5
10
15
.327 [8.3]
.156 [3.96]
.078
[1.98]
.492 [12.5]
10
15
.311 [7.9]
.078 [1.98]
E TYP.
E TYP.
.492 [12.5]
.425 [10.8]
.236 [6.0]
.425 [10.8]
.228 [5.8]
.181 [4.6]
D
.110 [2.8]
D
.181 [4.6]
.110 [2.8]
.423 [10.75]
.423 [10.75]
NO. OF CONTACTS
CONNECTOR TYPE
A
0.984 [25.00]
0.984 [25.00]
1.312 [33.32]
1.312 [33.32]
1.852 [47.04]
1.852 [47.04]
2.500 [63.50]
2.500 [63.50]
B
1.213 [30.80]
1.213 [30.80]
1.543 [39.20]
1.543 [39.20]
2.091 [53.10]
2.091 [53.10]
2.732 [69.40]
2.732 [69.40]
C
0.666 [16.92]
0.642 [16.30]
0.994 [25.25]
0.969 [24.60]
1.534 [38.96]
1.508 [38.30]
2.182 [55.42]
2.157 [54.80]
0.756
0.756
1.091
1.091
1.618
1.618
2.256
2.256
D
[19.20]
[19.20]
[27.70]
[27.70]
[41.10]
[41.10]
[57.30]
[57.30]
E
0.090 [02.29]
0.090 [02.29]
0.090 [02.29]
0.090 [02.29]
0.090 [02.29]
0.090 [02.29]
0.095 [02.41]
0.095 [02.41]
15 Plug
15 Rec.
26 Plug
26 Rec.
44 Plug
44 Rec.
62 Plug
62 Rec.
Dimensions are in inches [mm]
80 XX
SERIES CODE
NO. OF CONTACTS
15, 26, 44, 62
PART NUMBERING
07 X
XX X X
XX
50µ” Nickel Underplate
Mating Area
Tail
100µ” Tin Lead
05
= Au Flash
100µ” Tin Lead
20
= 15µ” Gold
100µ” Tin Lead
30
= 30µ” Gold
CONTACT PLATING
CONNECTOR TYPE
P
= Plug
S
= Receptacle
SHELL PLATING
50µ” Nickel Underplate
MOUNTING STYLE OPTIONS
1
= Tin Plating (standard)
2
= Yellow Chromate
See Page E-05 For Options
01
= .120 Riveted Front and Rear Shell
04
= Riveted #4-40 UNC Open Nut on Rear Shell
05
= Riveted #4-40 UNC Closed Nut on Front Shell
06
= Riveted #4-40 UNC Open Nut on Front Shell
07
= Riveted #4-40 UNC Closed Ground Stand Off on Rear Shell
Consult Factory for other Mounting Options
1
= Black (Standard)
2
= White
3
= Blue
INSULATOR COLOR
