SMT Power Inductors
Power Beads - PA5041 Series
Current Rating:
Over 89Apk
Inductance Range:
120nH to 330nH
Height:
11mm Max
Footprint:
7.2mm x 6.7mm Max
Part
Number
PA5041.121HLT
PA5041.151HLT
PA5041.221HLT
PA5041.331HLT
NOTES:
Inductance
1
@ 0A
DC
(nH ±10%)
120
150
220
330
IN
AR
Y
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
7
Irated
(ADC)
40
40
40
22
3
Inductance
2
@Irated
(nH TYP)
120
150
DCR
(mΩ )
4
Saturation Current
5
(A TYP)
25°C
75
72
100°C
74
63
22
Heating Current
6
(A TYP)
220
0.29±10%
50
28
42
40
300
1. Inductance measured at 100kHz, 100mVrms.
2. Inductance at Irated is the value of the inductance at 25°C at the listed rated current.
6. The heating current is the DC current which causes the part temperature to increase by
approximately 40°C when used in a typical application.
7. In high volt*time applications, additional heating in the component can occur due to core
losses in the inductor which may neccessitate derating the current in order to limit the tem-
perature rise of the component. To determine the approximate total losses (or temperature
rise) for a given application, the coreloss and temperature rise curves can be used.
8. Parts with the HLT suffix are sold in tape and reel packaging. Pulse complies to industry
standard tape and reel specification EIA-481.
Samples of these parts can be ordered by removing the HLT suffix and replacing with HL.
9. The temperature of the component (ambient plus temperature rise) must be within the
stated operating temperature range.
4. The nominal DCR is measured from point
①
to point
②
, as shown below on the
mechanical drawing.
EL
1
5. The saturation current is the typical current which causes the inductance to drop by 20%
at the stated ambient temperatures (25°C, 100°C ). This current is determined by placing
the component in the specified ambient environment and applying a short duration pulse
current (to eliminate self-heating effects) to the component.
IM
Mechanical
power.pulseelectronics.com
3. The rated current as listed is either the saturation current (25°C or 100°C) or the heating
current depending on which value is lower.
PR
Schematic
PA5041.XXXHLT
Weight
...........................1.8 grams
Tape & Reel
...................300/reel
Dimensions: mm
Unless otherwise specified,
all tolerances are
±0.25
P868. PRE (12/18)
http://www.power.pulseelectronics.com/contact
SMT Power Inductors
Power Beads - PA5041 Series
PA5041.XXXNL CoreLoss (W)
0.50
0.45
0.40
0.30
0.25
0.20
0.15
0.10
0.05
0.00
0
500
IN
AR
Y
1000
1500
2000
DeltaB
where DeltaB = .32 * L(nH) * DeltaI
400kHz
500kHz
600kHz
300kHz
700kHz
1.0MHz
0.35
CoreLoss (W)
2500
200kHz
1.2MHz
Temp Rise above Ambient (C)
PR
50
40
30
20
10
0
0
0.2
0.4
0.6
0.8
Power (W)
1
1.2
1.4
Total Power Dissipation (W) = CopperLoss + CoreLoss
CopperLoss = Irms^2 * Rdc(mOhms) / 1000
CoreLoss = (from table)
EL
70
60
3
IM
PA5041.XXXHL Temp Rise vs Power Dissipation
power.pulseelectronics.com
P868. PRE (12/18)
http://www.power.pulseelectronics.com/contact
SMT Power Inductors
Power Beads - PA5041 Series
TAPE & REEL INFO
IM
TYPE
PA5041.XXXHLT
REEL SIZE (mm)
A
W
1
W
2
Ø330
24.4
30.4
IN
AR
Y
SURFACE MOUNTING TYPE, REEL/TAPE LIST
E
F
D
0
1.5
P
0
4
TAPE SIZE (mm)
P
1
16
N
P
2
2
W
24
T
0.6
K
0
11.2
100
1.75
11.5
Pulse China Headquarters
Pulse Electronics (ShenZhen) CO., LTD
D708, Shenzhen Academy of
Aerospace Technology,
The 10th Keji South Road,
Nanshan District, Shenzhen,
P.R. China 518057
Tel: 86 755 33966678
Fax: 86 755 33966700
Pulse North China
Room 2704/2705
Super Ocean Finance Ctr.
2067 Yan An Road West
Shanghai 200336
China
Tel: 86 21 62787060
Fax: 86 2162786973
Pulse South Asia
3 Fraser Street
0428 DUO Tower
Singapore 189352
Tel: 65 6287 8998
Fax: 65 6280 0080
QTY
PCS/REEL
300
PR
For More Information
Pulse Worldwide
Pulse Europe
Headquarters
Pulse Electronics GmbH
15255 Innovation Drive Ste 100
Am Rottland 12
San Diego, CA 92128
58540 Meinerzhagen
U.S.A.
Germany
EL
Pulse North Asia
1F., No.111 Xiyuan Rd
Zhongli City
Taoyuan City 32057
Taiwan (R.O.C)
Tel: 858 674 8100
Fax: 858 674 8262
Tel: 49 2354 777 100
Fax: 49 2354 777 168
Tel: 886 3 4356768
Fax: 886 3 4356820
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may
be trademarks or registered trademarks of their respective owners. © Copyright, 2018. Pulse Electronics, Inc. All rights reserved.
4
power.pulseelectronics.com
P868. PRE (12/18)
http://www.power.pulseelectronics.com/contact
