480W Single Output with PFC Function
Features :
SP-480
series
Universal AC input / Full range
Built in active PFC function, PF>0.95
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan
3
High power density 5.18w/in
Low profile:43mm thickness
Built-in remote ON-OFF control
Built-in remote sense function
Active AC surge current limiting
3 years warranty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
PEAK LOAD(10min.)
OUTPUT
VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
POWER FACTOR (Typ.)
INPUT
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
PROTECTION OVER VOLTAGE
OVER TEMPERATURE
Note.4
FUNCTION
REMOTE CONTROL
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC
(Note 6)
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
DIMENSION
PACKING
SP-480-3.3
3.3V
85A
0 ~ 85A
280.5W
Note.5
280.5W
SP-480-5
5V
85A
0 ~ 85A
425W
425W
80mVp-p
4.5 ~ 5.5V
2.0%
0.5%
1.0%
SP-480-12
12V
40A
0 ~ 43A
480W
516W
120mVp-p
10.8 ~ 13.2V
1.5%
0.3%
0.5%
SP-480-15
15V
32A
0 ~ 35A
480W
525W
150mVp-p
13.5 ~ 18V
1.5%
0.3%
0.5%
SP-480-24
24V
20A
0 ~ 22A
480W
528W
150mVp-p
22 ~ 27.6V
1.0%
0.2%
0.5%
SP-480-48
48V
10A
0 ~ 11A
480W
528W
240mVp-p
41~ 56V
1.0%
0.2%
0.5%
RIPPLE & NOISE (max.)
Note.2
80mVp-p
2.9 ~ 3.6V
VOLTAGE TOLERANCE
Note.3
2.0%
0.5%
1.0%
18ms/230VAC
Note.7
85 ~ 264VAC
1000ms, 80ms/230VAC
2500ms, 80ms/115VAC at full load
18ms/115VAC at full load
120 ~ 370VDC
PF>0.98/115VAC at full load
79%
3.5A/230VAC
40A/230VAC
11.55 ~ 14.85A
57.6 ~ 67.2V
85%
85%
87%
89%
47 ~ 63Hz
PF>0.95/230VAC
73%
6.5A/115VAC
20A/115VAC
<2mA / 240VAC
87 ~ 103A
87 ~ 103A
45.15 ~ 58.05A
36.75 ~ 47.25A
23.1 ~ 29.7A
Protection type : Constant current limiting, recovers automatically after conditions is removed
3.8 ~ 4.45V
5.75 ~ 6.75V
13.8 ~ 16.2V
18 ~ 21V
28.8 ~ 33.6V
Protection type : Shut down o/p voltage, re-power on to recover
80 (TSW1) detect on heatsink of power transistor
90 (TSW2) detect on heatsink of power diode
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
RC+/RC-: 0 ~ 0.8V=power on ; 4 ~ 10V=power off
-20 ~ +60 (Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-40 ~ +85
0.03%/
, 10 ~ 95% RH
(0 ~ 50
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1 approved
I/P-O/P:3KVAC
I/P-FG:1.5KVAC
O/P-FG:Short
I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25 / 70% RH
Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), light industry level, criteria A
120.5K hrs min. MIL-HDBK-217F (25 )
278*127*43mm (L*W*H)
1.7Kg; 6pcs/11.3Kg/0.67CUFT
NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. TSW1: Detect on heatsink of power transistor.
TSW2: Detect on heatsink of output diode.
5. 33% Duty cycle maximum within every 30 minute. Average output power should not exceed the rated power.
6. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
7. Derating may be needed under low input voltages. Please check the derating curve for more details.
File Name:SP-480-SPEC 2011-08-23
