Tripp Lite's OMNISMART700 line-interactive UPS system offers voltage regulation, surge suppression and long-lasting battery support for personal
computers, internetworking equipment and other sensitive electronics. Supports entry-level PC systems for up to 45 min. during power failures so that
connected equipment can be shut down without data loss. Automatic voltage regulation (AVR) circuits regulate brownouts as low as 75V and overvoltages as
high as 147V back to normal 120V levels without consuming battery power. Offers complete desktop power protection in an attractive black upright tower
configuration. Includes 3 battery-supported outlets for computer, monitor and one vital system peripheral, plus 3 additional surge suppression-only outlets for
printers and other system accessories not requiring battery support. DB9 port and HID-compliant USB port enable optional unattended system shutdown
without data loss in the case of extended power failure, cabling included. HID-compliant USB port enables integration with built-in power management and
auto shutdown features of Windows and Mac OS X. PowerAlert software available via free download from www.tripplite.com. Built-in dataline protection jacks
offer protection of a single dialup tel/DSL line or network Ethernet connection. Built-in audible alarm and 4 front panel LEDs indicate line power status, battery
power status, battery low/replace status and overload. 700VA/450W power-handling ability supports entry-level PCs, network workstations, point-of-sale
equipment, small business phone systems, audio/video equipment and home theater systems. Provides 2.2 min. battery runtime with a full load of
700VA/450W and 8.3 min. with a half load of 350VA/225W. Supports user battery replacement via built-in access panel. $200,000 Ultimate Lifetime Insurance
(USA and Canada Only).
Features
OMNISMART700 line-interactive UPS system offers voltage regulation and battery support, plus complete AC and tel/DSL/Ethernet line surge
suppression
Supports entry-level PC systems for up to 45 min. during power failures to enable safe system shutdown
Supports a full load of 700VA/450W for 2.2 min. and a half load of 350VA/225W for 8.3 min.
Automatic voltage regulation (AVR) circuits correct brownouts as low as 75V and overvoltages as high as 147V back to normal 120V levels without
consuming battery power
Attractive black tower configuration
Includes 6 NEMA 5-15R outlets: 3 battery-supported and 3 surge suppression-only outlets. 6-ft. AC line cord with NEMA 5-15P plug
DB9 port and HID-compliant USB port enable unattended shutdown without data loss during extended power failures; complete cabling included
Built-in comunications ports support on battery, low battery, power restored, AC line voltage, DC battery voltage and battery capacity messaging;
interface supports timed inverter shutoff after unattended shutdown, activate
/
self-test and 10-sec. reboot of connected equipment
1 5
interface supports timed inverter shutoff after unattended shutdown, activate self-test and 10-sec. reboot of connected equipment
HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
PowerAlert UPS monitoring and unattended shutdown software available via free download from www.tripplite.com
Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting completely locked
computers by automatically switching UPS power off and back on again (part # WATCHDOGSW)
Built-in dataline suppression jacks protect a single dialup tel/DSL line or network Ethernet line connection
Built-in audible alarm and 4 front panel LEDs indicate UPS system and line power status
700VA/425W power-handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment
Supports hot-swap battery replacement via built-in access panel
Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
Compatible with 120V/60Hz applications for USA, Canada, Mexico and more
$200,000 Ultimate Lifetime Insurance (USA and Canada Only)
Specifications
OUTPUT
Output Volt Amp Capacity (VA)
Output Watt Capacity (watts)
Nominal Output Voltage(s)
Supported
Frequency compatibility
Output voltage regulation (line mode)
Output voltage regulation (Battery
mode)
Built-in UPS output receptacles
Surge suppression only outlets
Hot-Swap PDU options
Output AC waveform (AC mode)
Output AC waveform (battery mode)
700
450
115V; 120V
60 Hz
-18%, +8%
115V (+/- 5%)
6 5-15R outlet(s)
3 UPS outlets, 3 surge-only outlets
PDUB15 (2U / 8 5-15R outlets)
Sine wave
PWM sine wave
INPUT
Rated input current (at maximum
load)
Nominal Input Voltage(s) Supported
UPS input connection type
UPS Input cord length (ft.)
UPS Input cord length (m)
Recommended Electrical Service
Input cord length (ft.)
12A
120V AC
5-15P
6
1.8
15A 120V
6
2/5
Input cord length (m)
Phase
1.8
Single-Phase
BATTERY
Full load runtime (minutes)
Half load runtime (minutes)
DC system voltage (VDC)
Battery recharge rate (included
batteries)
Replacement battery cartridge
(internal UPS battery replacement)
Battery Access
Battery replacement description
2.2 min. (450w)
8.3 min. (225w)
12
Less than 4.5 hours from 10% to 90%
RBC51
Battery access door
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation description
Overvoltage correction
Undervoltage correction
Severe undervoltage correction
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 75 to 147
Input voltages between 128 and 147 are reduced by 12%
Input voltages between 93 and 107 are boosted by 14%
Input voltages between 75 and 92 are boosted by 30%
LEDS ALARMS & SWITCHES
LED Indicators
Alarms
Alarm cancel operation
Switches
4 LEDs indicate line power, battery power, overload and battery low/replace status
Audible alarm indicates power-failure and low-battery conditions
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule rating
UPS AC suppression response time
UPS Dataline suppression
EMI / RFI AC noise suppression
AC suppression joule rating
AC suppression response time
Dataline suppression
510
Instantaneous
1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
Yes
510
Instantaneous
1 line TEL / DSL or 10Base T Ethernet protection
PHYSICAL
3/5
Installation form factors supported
with included accessories
Installation form factors supported
with optional accessories
Primary form factor
UPS / Power Module dimensions in
primary form factor (height x width x
depth / inches)
UPS / Power Module dimensions in
primary form factor (height x width x
depth / cm)
UPS / Power Module weight (lbs)
UPS / Power Module weight (kg)
UPS Shipping dimensions (height x
width x depth / inches)
UPS Shipping dimensions (height x
width x depth / cm)
Shipping weight (lbs)
Shipping weight (kg)
UPS housing material
Tower
Wallmount (UPSWM - tower mounting kit)
Tower
10.8 x 5.2 x 7.5
27.3 x 13.3 x 19
20
9.1
14 x 8.2 x 10.4
35.6 x 21 x 26.4
22
10
PVC
ENVIRONMENTAL
Operating Temperature Range
Storage Temperature Range
Relative Humidity
AC mode BTU / hr. (full load)
Battery mode BTU / hr. (full load)
AC mode efficiency rating (100%
load)
Audible Noise
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
0 to 95%, non-condensing
47.3
431.5
97%
<40dB @ 1m
COMMUNICATIONS
Communications interface
PowerAlert software
Communications cable
WatchDog compatibility
USB (HID enabled); DB9 Serial
Free download from www.tripplite.com
USB and DB9 serial cabling included
Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time
Low voltage transfer to battery
power (setpoint)
2-4 milliseconds
75
4/5
High voltage transfer to battery
power (setpoint)
147
SPECIAL FEATURES
Cold Start (startup in battery mode
during a power failure)
High availability UPS features
Green & high efficiency features
Cold-start operation supported
Hot swappable batteries
Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications
Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
