5W Output Switching Power Supply
¡½
Features :
¡E
Universal AC input / Full range
PM-05
series
¡E
Protections: Short circuit / Overload / Over voltage
¡E
Ultra-miniature size, light weight
¡E
Cooling by free air convection
¡E
Isolation class
¢º
¡E
Medical safety approved (2 x MOPP between primary to secondary)(Note.6)
¡E
No load power consumption<0.5W
¡E
100% full load burn-in test
¡E
Fixed switching frequency at 67KHz
¡E
High reliability
¡E
3 years warranty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
PM-05-3.3
3.3V
1.25A
0 ~ 1.25A
4.125W
PM-05-5
5V
1A
0 ~ 1A
5W
80mVp-p
PM-05-12
12V
0.42A
0 ~ 0.42A
5.04W
150mVp-p
PM-05-15
15V
0.33A
0 ~ 0.33A
4.95W
150mVp-p
PM-05-24
24V
0.23A
0 ~ 0.23A
5.52W
240mVp-p
RIPPLE & NOISE (max.)
Note.2
80mVp-p
VOLTAGE TOLERANCE
Note.3
¡Ó
3.0%
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
¡Ó
2.0%
¡Ó
1.0%
¡Ó
1.0%
24ms/115VAC at full load
120 ~ 370VDC
71%
0.08A/230VAC
¡Ó
2.0%
¡Ó
0.5%
¡Ó
1.0%
¡Ó
2.0%
¡Ó
0.5%
¡Ó
1.0%
¡Ó
2.0%
¡Ó
0.5%
¡Ó
0.5%
¡Ó
1.0%
¡Ó
1.0%
1000ms, 20ms/230VAC
100ms/230VAC
85 ~ 264VAC
47 ~ 440Hz
67%
0.12A/115VAC
1000ms, 20ms/115VAC at full load
INPUT
73%
45A/230VAC
74%
76%
COLD START 25A/115VAC
Note.5
Touch current < 80 A/264VAC
£g
Above 105%
rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
13.8 ~ 16.2V
3.8 ~ 4.95V
5.75 ~ 6.75V
Protection type : Shut off o/p voltage, clamping by zener diode
-20 ~ +70
¢J
(Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-40 ~ +85
¢J
, 10 ~ 95% RH
17.25 ~ 20.25V
27.6 ~ 32.4V
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC
(Note 4)
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
NOTE
¡Ó
0.03%/
¢J
(0 ~ 50
¢J)
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved
I/P-O/P:4KVAC
I/P-O/P:100M Ohms / 500VDC / 25
¢J
/ 70% RH
Compliance to EN55011(CISPR11),EN55022 (CISPR22) Class B, EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-2, EN61204-3, medical level, criteria A
1513.4Khrs min.
MIL-HDBK-217F (25
¢J
)
62.85*50*19.7mm (L*W*H)
0.085Kg; 120pcs/11.2Kg/0.97CUFT
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25
¢J
of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
5. Touch current was measured from primary input to DC output.
6
. Suitable for BF application with appropriate system consideration.
