Designing and manufacturing innovative frequency control devices since 1927
SURFACE MOUNT, PECL OUTPUT VCXO
FEATURES
M
M
M
M
M
M
Low Cost
Hermetically-sealed
Expanded frequency range
Extremely low phase jitter
Complementary output (VC916)
Wide pullability
VC914
4-Lead VCXO
SPECIFICATIONS
Supply Voltage
Control Voltage
Input Current
Calib Tolerance
@ 251C
Frequency Range
Output Waveform
Pull Range
Stability over Temp
Aging @ 251C
Oper Temp Range
Storage Temp Range
Logic “1”, V
OH
Logic “0”, V
OL
Load
Rise & Fall Time
Duty Cycle
Start-Up Time
RMS Jitter
Linearity
M
6-Lead VCXO, Enable/Disable
Complementary Output
VC916
VC914
3.3 Vdc
!10%
0.3 Vdc to 3.0 Vdc
80 mA max
5.0 Vdc
!10%
0.5 to 4.5 Vdc
120 mA max
4-Lead
6-Lead, Enable/Disable
Complementary Output
VC916
!
20 ppm @ Center Voltage
3.3V: 1.65 Vdc
5.0V: 2.5 Vdc
19.44 to 155.52 MHz (Inverted Mesa UM-1)
Positive ECL Square Wave
See options in Part Numbering Key below
See options in Part Numbering Key below
!
1 ppm / year max
01C to 701C (std); -401C to 851C (optional)
-551C to 1251C
Vdd -1.025 Vdc min
Vdd -1.620 Vdc max
50
✡
2.0 nS (20% to 80% of Waveform)
50%
!
10% (50% of Waveform)
10 mS max
3.5 pS max
!
10% max
Units=mm
PART
NUMBERING
KEY
Sample Part Numbers
SERIES
VC914
4-Lead
6-Lead,
Enable/Disable
Compl Output
SUPPLY
VOLTAGE
3 = 3.3V
5 = 5.0V
STABILITY
OVER TEMP
1=
2=
3=
4=
!
20 ppm**
!
25 ppm
!
30 ppm
!
50 ppm
TEMP RANGE
2 = 01C ~ 701C*
5 = -401C ~ 851C
PULL RANGE
1
2
3
4
=
=
=
=
!
30 ppm
!
50 ppm
!
75 ppm
!
100 ppm
PACKAGING
A = Bulk
E = Tape & Reel
(1000 pcs/reel)*
X = Cust spec
FREQUENCY
VC916
** @ 01C ~ 701C only
VC9143221E @ =
33.333 MHz
VC9165452E @ =
155.52 MHz
* Standard
VC914
VC916
3
5
2
4
2
5
1
2
E
E
33.333
155.52
Call factory for additional options. Use full descriptive part number when ordering. Parts will be marked with series and frequency only.
Monitor Products Company Inc reserves the right to make changes to its products and product specifications without notice. No liability is assumed as a result of their use or application.
12-18-01
502 VIA DEL MONTE, OCEANSIDE, CA 92054
TEL:
760.433.4510
FAX:
760.434.0255
