Ripple and Noise (20MHz bandwith, with 1µF MLCC on output)
Temperature Coefficient
Transient Response (25% load step change)
Input Voltage Variation, dv/dt
Over Load Protection (% of full load at nominal Vin)
Overvoltage Protection (Single)
Undervoltage Protection
Short Circuit Protection
Efficiency
Isolation Voltage (rated for one minute)
Isolation Resistance
Isolation Capacitance
Operating Frequency
Operating Temperature Range (No derating)
Maximum Case Temperature
Storage Temperature Range
Thermal Impedance
Case Material
Potting Material
Weight
Packing Quantity
Conducted Emissions
(3)
Radiated Emissions
(3)
ESD
Radiated Immunity
Fast Transient
Natural convection
5.1, 12, 15, ±12, ±15V
3.3, ±5V
In to Out and I/O to case
DC-DC ON
DC-DC OFF
Nominal input
RP12-S_DAW
Series
9-36VDC
18-75VDC
Pi Type
50VDC (24V Type), 100VDC (48V Type)
20mAp-p
450ms typ.
Open or 3.0V < Vr < 12V
Short or 0V < Vr < 1.2V
2.5mA
12W max.
±1.2%
0%
±0.2%
±0.5% Single, ±0.5%
±5%
85mVp-p
±0.02%/°C max.
250µs
complies with ETS300 132, part 4.4
5V/ms
150% typ
Zener Diode Clamp
See Application Notes
Continuous, automatic recovery
see „Selection Guide“ table
1600VDC
10 GΩ min.
1500pF max.
400kHz typ.
-40°C to +65°C
-40°C to +61°C
+105°C
-55°C to +125°C
20°C/Watt
Nickel plated copper with non-conductive plastic base
Epoxy (UL94-V0)
18g (DIP), 20g (SMD)
Refer to App Notes for tube dimensions
EN55022
EN55022
EN61000-4-2
EN61000-4-3
EN61000-4-4
7pcs per Tube
Class A
Class A
Perf. Critera B
Perf. Critera A
Perf. Critera B
continued on next page
RP12-AW
www.recom-international.com
REV: 0/2014
P-23
POWERLINE
DC/DC-Converter
Specifications
(typical at nominal input and 25°C unless otherwise noted)
Surge
Conducted Immunity
Thermal Shock
Vibration
Relative Humidity
MTMF
(2)
EN61000-4-5
EN61000-4-6
RP12-S_DAW
Series
Pref. Critera B
Pref. Critera A
MIL-STD-810D
10-55Hz, 10G, 30 Min. along X, Y and Z
5% to 95% RH
Bellcore-TR-NWT-000332
2350 x 10
3
hours
Notes :
1.
2.
3.
4.
5.
6.
7.
The ON/OFF control pin voltage is referenced to negative input.
BELLCORE TR-NWT-000332. Case l: 50% Stress, Temperature at 40°C (Ground fixed and controlled environment).
Requires external filter to meet EN55022 Class A
Typical value at nominal input voltage and no load.
Maximum value at nominal input voltage and full load
Typical value at nominal input voltage and full load.
Test by minimum Vin and constant resistor load.
Package Style and Pinning (mm)
DIP24 Package Style
31.80
20.30
10.20
3.8
2
20.30
5.10
15.20
Pin Connections
Pin #
Single
1
ON/OFF
2
-Vin
3
-Vin
9
NC
11
NC
14
+Vout
16
-Vout
22
+Vin
23
+Vin
NC = No Connection
Dual
ON/OFF
-Vin
-Vin
Com
-Vout
+Vout
Com
+Vin
+Vin
RP12-AW
2.54
0.25 x 0.50
Rectangular Pin
9
11
1 2 3
Bottom View
23 22
Pin Pitch Tolerance ±0.35 mm
16
14
SMD Package Style and Pinning (mm)
(Same spec. as the original DIP sepc. and pin definition, excl. of the SMD Typ pin.)
32.00
31.40
11.20
10.90
Pin Connections
2.54
3.81
6.35
21.30
25.40
Pin #
Single
1
ON/OFF
2
-Vin
3
-Vin
9
NC
11
NC
14
+Vout
16
-Vout
22
+Vin
23
+Vin
Others
NC
NC = No Connection
Dual
ON/OFF
-Vin
-Vin
Com
-Vout
+Vout
Com
+Vin
+Vin
NC
20.30
Pin area
0.1 x 0.50
1 2 3 4 5
0.50
9 10 11 12
2.54
1.60
2.40
23.40
Bottom View
24 23 22 21 20
16 15 14 13
26.54
24.14
1
Top View
Pin Pitch Tolerance ±0.35 mm
27.94
11 x 2.54
The product information and specifications are subject to change without prior notice. All products are designed for non-safety critical commercial and industrial applications.
The Buyer agrees to implement safeguards that anticipate the consequences of any failures that might cause harm, loss of life and/or damage property.
