Cal Crystal Lab, Inc. / Comclok, Inc. 800-333-9825
1156 North Gilbert Street • Anaheim, CA 92801
VCXO
(FULL & HALF SIZE)
MODEL CY
3.3VDC
Model
Frequency Range
Frequency Stability
Operating Temperature Range
CY Half Size
1.25MHz ~ 65.0MHz
100ppm Standard, Optional Tolerances
Available
0
o
C ~+70
o
C Extended Temperature
Ranges Available
o
o
-55 C ~+125 C
1.25KHz ~ 28.000MHz:
15mA Max
28.000MHz ~ 65.000MHz: 30mA Max
+3.3 VDC
±
10%
60/40 @ 50% Vcc, Optional Tolerances
Available
6 nSec Max
3.0 VDC Min
0.5 VDC Max
10TTL / 20pF
< 5ppm per year
1.65 VDC
±
50ppm Standard, Optional Pullability
up
±500ppm
Available
CY Full Size
1.25MHz ~ 65.0MHz
100ppm Standard, Optional Tolerances
Available
0
o
C ~+70
o
C Extended Temperature
Ranges Available
-55
o
C ~+125
o
C
1.25KHz ~ 28.000MHz:
15mA Max
28.000MHz ~ 65.000MHz: 30mA Max
+3.3 VDC
±
10%
60/40 @ 50% Vcc, Optional Tolerances
Available
6 nSec Max
3.0 VDC Min
0.5 VDC Max
10TTL / 20pF
< 5ppm per year
1.65 VDC
±
50ppm Standard, Optional Pullability
up
±500ppm
Available
CY Full Size
65.0MHz ~ 160.0MHz
100ppm Standard, Optional Tolerances
Available
0
o
C ~+70
o
C Extended Temperature
Ranges Available
-55
o
C ~+125
o
C
65.0MHz ~ 99.999MHz:
30mA Max
100.00MHz ~ 129.9MHz: 35mA Max
130.00MHz ~ 160.00MHz: 40mA Max
+3.3 VDC
±
10%
60/40 @ 50% Vcc, Optional Tolerances
Available
3 nSec Max
3.0 VDC Min
0.5 VDC Max
2TTL / 20pF
< 5ppm per year
1.65 VDC
±
50ppm Standard, Optional Pullability
Available
Storage Temperature Range
Current Consumption
Supply Voltage
Symmetry
Rise & Fall Time (Tr & Tf)
Logic “1”
Logic “0”
Output Load (Max)
Aging
Frequency Control Voltage
Pullability
FULL SIZE VCXO
PINS
CONNECTIONS
1
CONTROL VOLTAGE
7
GND
8
OUTPUT
14
+3.3 VDC
±10%
TEST CIRCUIT FULL SIZE
HALF SIZE VCXO
PINS
CONNECTIONS
1
CONTROL VOLTAGE
4
GND
5
OUTPUT
8
+3.3 VDC
±10%
TEST CIRCUIT HALF SIZE
NOTE:
1.
C
L
Capacitance includes probe and test jig 20pF typical (10kHz ~ 69.999MHz)
C
L
Capacitance includes probe and test jig 15pF typical (70MHz ~ 160.000MHz)
2. R
L
= 400Ω - 10 TTL
2kΩ - 10 LSTTL
3. All diodes are 1N941, 1N43064 or equivalent
