Ferrites and accessories
E 32/16/9 (EF 32)
Core and accessories
Series/Type:
Date:
B66229, B66230
June 2013
Data Sheet
EPCOS AG 2013. Reproduction, publication and dissemination of this data sheet and the
information contained therein without EPCOS’ prior express consent is prohibited.
E 32/16/9 (EF 32)
Core
■
To IEC 61246
■
Delivery mode: single units
B66229
Magnetic characteristics
(per set)
l/A
l
e
A
e
A
min
V
e
= 0.89 mm
–1
= 74 mm
= 83 mm
2
= 81.4 mm
2
= 6140 mm
3
Approx. weight
30 g/set
Ungapped
Material
N30
N27
N87
A
L
value
nH
3800 +30/–20%
2100 +30/–20%
2300 +30/–20%
e
2690
1480
1630
< 1.10 (200 mT, 25 kHz, 100 °C)
< 3.00 (200 mT, 100 kHz, 100 °C)
P
V
W/set
Ordering code
B66229G0000X130
B66229G0000X127
B66229G0000X187
Gapped
Material
g
mm
0.500.05
1.000.05
A
L
value
approx.
nH
244
145
e
Ordering code
** = 27 (N27)
**
= 87 (N87)
B66229G0500X1**
B66229G1000X1**
N27,
N87
172
103
The A
L
value in the table applies to a core set comprising one ungapped core (dimension g = 0) and
one gapped core (dimension g > 0).
Calculation factors
(for formulas, see
“E cores: general information”
)
Material
Relationship between
air gap – A
L
value
K1 (25 °C)
N27
N87
Validity range:
145
145
K2 (25 °C)
– 0.748
– 0.748
Calculation of saturation current
K3 (25 °C)
212
208
K4 (25 °C)
– 0.847
– 0.796
K3 (100 °C) K4 (100 °C)
196
191
– 0.865
– 0.873
K1, K2: 0.10 mm < s < 2.50 mm
K3, K4: 70 nH < A
L
< 710 nH
Please read
Cautions and warnings
and
Important notes
at the end of this document.
2
06/13
E 32/16/9 (EF 32)
Accessories
Coil former
GFR polyterephthalate (UL 94 V-0, insulation class to IEC 60085:
F max. operating temperature 155 °C), color code black
Rynite FR 530
®
E41938 (M)
, E I DUPONT DE NEMOURS & CO INC
Solderability: to IEC 60068-2-20, test Ta, method 1 (aging 3): 235 °C, 2 s
Resistance to soldering heat: to IEC 60068-2-20, test Tb, method 1B: 350 °C, 3.5 s
Winding:
see Data Book 2013, chapter “Processing notes, 2.1”
Squared pins.
Yoke
Material:
Coil former
Sections
1
A
N
mm
2
108.50
l
N
mm
64.4
A
R
value
20.42
Pins
14
B66230A1114T001
B66230A2010X000
Stainless spring steel (0.4 mm)
Ordering code
Material:
B66230
Yoke (ordering code per piece, 2 are required)
Coil former
Yoke
Please read
Cautions and warnings
and
Important notes
at the end of this document.
3
06/13
Ferrites and accessories
