SFBCC
Filter Type
Feedthrough EMI Filter Datasheet
(8-32 UNC Thread : 4.75mm Hexagonal Head)
Circuit Configuration
Electrical Details
Electrical Configuration
Capacitance Measurement
Current Rating
Insulation Resistance (IR)
Temperature Rating
Ferrite Inductance (Typical)
Head A/F
Nut A/F
Washer Diameter
Mounting Torque
Mounting Hole Diameter
Max. Panel Thickness
Weight (Typical)
Finish
C Filter
@ 1000hr Point
10A
10G or 1000F
-55
o
C to +125
o
C
Not Applicable
4.75mm
(0.187")
6.35mm
(0.250")
8mm
(0.315")
0.5Nm
(4.42lbf in)
max. if using nut
0.25Nm
(2.21lbf in)
max. into tapped
hole
4.4mm
0.1
(0.173"
0.004")
2.9mm
(0.114")
1.2g
(0.04oz)
Silver plate on copper undercoat
Typical Insertion Loss (db)
Mechanical Details
8-32 UNC Class 2A Thread
Product Code
Hardware
(Nuts &
Washers
etc.)
0.01MHz
Capacitance
20%
UOS
10pF
15pF
22pF
33pF
47pF
-20% /
-20% /
-20% /
-20% /
-20% /
68pF
100pF
150pF
220pF
330pF
470pF
680pF
1.0nF
1.5nF
2.2nF
3.3nF
4.7nF
6.8nF
10nF
15nF
22nF
33nF
47nF
68nF
100nF
150nF
+80%
+80%
+80%
+80%
+80%
Dielectric
Rated
Voltage
(dc)
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
200
200
100
50
100MHz
0.1MHz
10MHz
1MHz
DWV
(dc)
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
500
500
250
125
*SFBCC5000100ZC
SFBCC5000150ZC
SFBCC5000220ZC
SFBCC5000330ZC
*SFBCC5000470ZC
*SFBCC5000680MC
*SFBCC5000101MC
SFBCC5000151MC
*SFBCC5000221MC
*SFBCC5000331MC
*SFBCC5000471MX
SFBCC5000681MX
*SFBCC5000102MX
SFBCC5000152MX
*SFBCC5000222MX
SFBCC5000332MX
*SFBCC5000472MX
SFBCC5000682MX
*SFBCC5000103MX
*SFBCC5000153MX
*SFBCC5000223MX
SFBCC5000333MX
*SFBCC2000473MX
SFBCC2000683MX
SFBCC1000104MX
SFBCC0500154MX
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
†X7R
† X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
1
2
4
7
1
2
4
7
10
13
16
19
22
25
1
2
4
7
10
13
16
19
22
25
29
33
35
39
41
45
1
2
4
7
10
13
16
19
23
26
30
33
36
39
41
44
46
48
50
54
57
60
4
7
10
12
15
18
22
25
29
33
35
36
41
45
50
52
55
57
60
62
65
68
70
70
70
70
* Recommended values
Ordering Information
Type
SF
Syfer Filter
0 = No hardware supplied
1 = supplied with standard nut and wavy washer
Other options available – please contact factory
†
Also available in C0G
Case
Style
B
4.75mm
Hex Head
Thread
C
8-32 UNC
Electrical
configuration
C
C = C Filter
Voltage
(dc)
500
050
100
200
500
=
=
=
=
50V
100V
200V
500V
Capacitance in
picofarads (pF)
0102
First digit is 0. Second and
third digits are significant
figures of capacitance code.
The fourth digit is the number
of zeros following.
Examples: 0101 = 100pF
0332 = 3300pF
Capacitance
Tolerance
M
M =
20%
Z = -20+80%
Dielectric
X
C = C0G/NP0
X = X7R
Hardware
0
0 = Without
1 = With
Note: The addition of a 4-digit numerical suffix code can be used to denote changes to the standard part.
Options include for example: change of pin length / custom body dimensions or threads / alternative voltage rating / non-standard intermediate capacitance values / test
requirements.
Please refer specific requests to the factory.
Syfer Technology Ltd.
Old Stoke Road, Arminghall
Norwich, Norfolk, NR14 8SQ
United Kingdom
Tel: +44 1603 723300 | Email
sales@syfer.co.uk
|
www.syfer.com
SFBCC Issue 2 (P104775)
