D-Sub
Top entry hoods with knurled or locking screws
Identification
No. of
contacts
Part No.
Drawing
Dimensions in mm
Black thermoplastic
with short locking
screws
9
15
25
37
50
09 67 009 0442
09 67 015 0442
09 67 025 0442
09 67 037 0442
09 67 050 0442
UNC 4-40 or M3
UNC 4-40 or M3
Hood
3)
Metallized thermo-
plastic with short
locking screws
Please insert digit for
screw option
Thread 4-40 UNC
Thread M3
þ
þ
9
15
25
37
50
4
2
09 67 009 04
09 67 015 04
09 67 025 04
09 67 037 04
09 67 050 04
.
.
.
.
.
3
3
3
3
3
a
15
25
37
50
40.0
53.2
70.0
67.5
b
34.7
39.7
39.7
39.7
c
15.2
15.2
15.2
18.2
d
33.3
47.0
63.5
61.1
min.
3.3
3.5
3.5
9.3
e
max.
8.5
11.0
11.0
12.0
Knurled screw
for metallized hood
Thread UNC
Thread M3
9-50
9-50
09 67 000 9925
2)
09 67 000 9930
2)
Screened hood
Order cover and
internal metal screen
separately
Black thermoplastic
with knurled screws
9
15
25
37
A
35.0
43.0
57.5
74.0
B
54
54
54
54
C
19.1
19.1
19.1
19.1
D
34
34
34
34
Cover
4)
9
15
25
37
09 67 009 0422
09 67 015 0422
09 67 025 0422
09 67 037 0422
Internal metal screen
4)
metallized
(Crimp tool
see chapter 20)
9
15
25
37
09 67 009 0421
09 67 015 0421
09 67 025 0421
09 67 037 0421
9
15
25
37
Cable Ø (mm)
min.
max.
6.1
8.8
6.1
8.8
8.0
10.3
9.5
11.5
05
155
Use of knurled screws is possible. Please order separately
Order 2 for each hood
3)
Operating temperature: -20 °C … +90 °C
4)
Operating temperature: -55 °C … +110 °C
1)
2)
D-Sub
Hood
3)
