PART NUMBER
LED COLOR (nm)
REV
A
REVISIONS
NEW RELEASE
DRN APP
LD
NO
DATE
3-22-19
5988C10102F
5988C10107F
5988C30102F
5988C30107F
5988C40102F
5988C40107F
5988C60102F
5988C60107F
5988C80102F
5988C80107F
5988C90102F
5988C90107F
RED (625)
ORANGE (605)
YELLOW (590)
YELLOW GREEN (570)
GREEN (525)
BLUE (470)
B
ADDED VIEWING ANGLE
LD
NO
4-25-19
RECOMMENDED RoHS SOLDER PROFILE
.087 .001
[ 2,2 0,05 ]
.055 .001
[ 1,4 0,05 ]
UNITS: mm
TOLERANCE (UNLESS OTHERWISE SPECIFIED): ±0.2mm
TAPING SPECIFICATIONS
POLARITY MARK
MARK
ABSOLUTE MAXIMUM RATINGS AT 25 C
.024 .001
[ 0,6 0,05 ]
.051 .001
[ 1,3 0,05 ]
LED COLOR
RED
ORANGE
YELLOW
YELLOW GREEN
GREEN
PIN 2
PIN 1
BLUE
POWER
DISSIPATON
(mW)
48
70
48
48
70
70
OPERATING CHARACTERISTICS AT 25
LED COLOR
IF (mA)
RED
ORANGE
.035 .000
[ 0,9 0,01 ]
YELLOW
YELLOW GREEN
GREEN
BLUE
20
LUMINOUS
INTENSITY
(mcd)
MIN.
280
230
280
40
1500
350
TYP.
405
290
405
65
1900
440
MAX.
530
350
530
90
2300
530
DOMINANT
WAVELENGTH
(nm)
MIN
620
600
585
565
520
465
TYP.
625
605
590
570
525
470
MAX
630
610
595
575
530
475
10µA @ VR=5V
C
FORWARD
VOLTAGE
IF=5mA
TYP.
1.8
1.8
1.8
1.8
2.8
2.8
MAX.
2.4
2.4
2.4
2.4
3.3
3.3
120
110
VIEWING THERMAL
ANGLE RESISTANCE
(DEG)
( C/W)
TYP
MAX
20
60
5
-40 TO +85
-40 TO +100
FORWARD PEAK FORWARD
CURRENT
CURRENT
(mA)
(mA)
REVERSE
VOLTAGE
(V)
OPERATING
STORAGE
TEMPRATURE TEMPRATURE
( C)
( C)
DERATING
CURVE
(mA/ C)
.49
.45
.51
.49
.57
.51
2000
95
ELECTROSTATIC JUNCTION
DISCHARGE TEMPERATURE
(V)
( C)
TS
max
TS
min
s
L
L
T
T
t
DEFINITION
Maximum of pre-heating temperature
Minimum of pre-heating temperature
Time form Tsmin to Tsmax
Reference temperature
Retention time for TL
Peak Temperature
Time for peak temperature
Temperature rising rate
Temperature decreasing rate
CONDITION
200 C
150 C
60-120 sec
217 C
within 60s
T
P
t
P
DTr/Dt
DTd/Dt
260 C
within 10s
under 3 C/sec
under -3 C/sec
REVERSE
CURRENT
MAX
.024 .000
[ 0,6 0,01 ]
.030
[0,75]
.035
[0,9]
PIN 2
ANODE
PIN 1
CATHODE
LED SCHEMATIC
.043
[1,1]
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND THE SOLE
PROPERTY OF DIALIGHT CORP. REPRODUCTION OF THIS DRAWING OR
CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE FORBIDDEN WITHOUT
THE WRITTEN CONSENT OF DIALIGHT CORP.
DIALIGHT CORP INTERNAL REFERENCE ONLY = 3D MODEL : 4500521848X15-A.1
NOTES:
SCALE: 35.00
ALL DIM'S IN: INCHES (MM)
DRAWING NUMBER
REV
ATTENTION:
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES
RECOMMENDED SOLDER PAD LAYOUT
1. PIN NUMBERS ARE FOR REFERENCE ONLY, DESIGNATION NON-EXISTENT
ON PART.
2. LABELING FOR REEL AND OUTSIDE OF ALUMINUM BAG,
DIALIGHT P/N, QUANTITY PER REEL, DATE CODE, INTENSITY BIN CODE,
LOT NUMBER AND COUNTRY OF ORIGIN
3. THIS PRODUCT IS RoHS COMPLIANT. EACH BAG IS TO BE MARKED WITH RoHS
COMPLIANT LABEL OR EQUIVALENT MARKINGS. LED MUST BE Pb FREE.
4. MOISTURE SENSITIVITY LEVEL 3
5. QUANTITY IS 3,000 PCS/ REEL
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
FRACTIONS:
1/64
.01
.005
.0005
MATERIAL
TITLE
DECIMALS (.XX):
DECIMALS (.XXX):
DECIMALS (.XXXX):
ANGLES:
FINISH
1
C18403
MINI-PLCC2 PACKAGE
B
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
(732) 919-3119
www.dialight.com
FSCM 83330
SHEET
1
OF
1
FAMILY TABLE:
