Amplified Low Pressure Sensors
1 mbar (0.4 In H2O) to 30 In H2O Pressure Sensors
R
www.allsensors.com
Industrial Temperature Grade
Features
• 0 to 1 mbar to 0 to 30 In H2O Pressure Ranges
• Ratiometric 4V Output
• Temperature Compensated (-25C to 85C)
• Calibrated Zero and Span
R
Applications
www.allsensors.com
Signed Original On File
Signed Original On File
• Medical Instrumentation
General Description
The Amplified line of low pressure sensors is based upon a proprietary technology to reduce all output offset or common mode er-
rors. This model provides a ratiometric 4-volt output with superior output offset characteristics. Output offset errors due to change
all sensors
f
408 225 2079
e
www.allsensors.com
p
408 225 4314
a
16035 Vineyard Blvd. Morgan Hill, CA 95037
• Environmental Controls
• HVAC
R
www.allsensors.com
R
in temperature, stability to warm-up, stability to long time period, and position sensitivity are all significantly reduced when
compared to conventional compensation methods. In addition the sensor utilizes a silicon, micromachined, stress concentration
enhanced structure to provide a very linear output to measured pressure.
These calibrated and temperature compensated sensors give an accurate and stable output over a wide temperature range. This
series is intended for use with non-corrosive, non-ionic working fluids such as air, dry gases and the like.
The output of the device is ratiometric to the supply voltage over a supply voltage range of 4.5 to 5.5 volts.
www.allsensors.com
Signed Original On File
Physical Dimensions
0.25
(6.4)
Pin Size
0.010 x 0.020
(0.25 x 0.50)
0.174 to 0.190
(4.4 to 4.8)
Pin 1 2 3 4
1
0.21
(5.3)
A
1.08
(27.4)
0.66
(16.0)
B
0.42
(10.5)
0.10 Typical
(2.54)
Signed Original On File
pin 1: Vsupply
pin 2: Common
pin 3: Voutput
pin 4: do not connect
R
www.allsensors.com
R
0.48
(12.2)
0.55
(14.0)
0.80
(20.3)
0.85
(21.6)
1.10
(27.9)
NOTES:
1) Dimensions in inches (millimeters)
www.allsensors.com
Original On File
Signed Original O
Approvals
MKT
DATE
MFG
DATE
ENG
DATE
QA
DATE
As Is
With Change
As Is
With Change
As Is
With Change
As Is
With Change
All Sensors
DS-0025 Rev B
R
ors.com
R
Signed Original On File
w.allsensors.com
Signed Original On F
R
www.allsensors.com
Pressure Sensor Ratings
Supply Supply Voltage VS
Common-mode pressure
Lead Temperature, max
(soldering 2-4 sec.)
+4.5 to +5.5 Vdc
-10 to +10 psig
250°C
Environmental Specifications
Temperature Ranges
Compensated
Operating
Storage
Humidity Limits
-25 to 85° C
-40 to 125° C
-40 to 125° C
0 to 95% RH
(non condensing)
R
www.allsensors.com
Signed Original On File
Standard Pressure Ranges
Part Number
1 MBAR-D-4V-PRIME
1 INCH-D-4V-PRIME
1 INCH-G-4V-PRIME
5 INCH-D-4V-PRIME
5 INCH-G-4V-PRIME
10 INCH-D-4V-PRIME
10 INCH-G-4V-PRIME
20 INCH-D-4V-PRIME
20 INCH-G-4V-PRIME
30 INCH-D-4V-PRIME
30 INCH-G-4V-PRIME
Operating Pressure
±1 mbar
±1 In H2O
0 - 1 In H2O
± 5 In H2O
0 - 5 In H2O
±10 In H2O
0 - 10 In H2O
±20 In H2O
0 - 20 In H2O
±30 In H2O
0 - 30 In H2O
Nominal Span
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
Proof Pressure
100 In H2O
100 In H2O
100 In H2O
200 In H2O
200 In H2O
200 In H2O
200 In H2O
300 In H2O
300 In H2O
500 In H2O
500 In H2O
Burst Pressure
200 In H2O
200 In H2O
200 In H2O
300 In H2O
300 In H2O
300 In H2O
300 In H2O
500 In H2O
500 In H2O
800 In H2O
800 In H2O
Signed Original On File
R
www.allsensors.com
R
www.allsensors.com
Signed Original On File
Signed Original On File
Performance Characteristics for: 1 MBAR-D-4V-PRIME
Parameter,
NOTE
1
Operating Range, differential pressure
Output Span,
NOTE
5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-25°C to 85°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-25°C to 85°C),
NOTE
2
Minimum
--
±1.80
2.00
--
--
--
--
--
--
Nominal
±1.0
±2.0
2.25
--
±20.0
±40.0
±20.0
0.05
--
Maximum
--
±2.20
2.50
±120
--
--
--
0.25
±4.0
