Crystal Clock Oscillator
TCO-7086X1A
SMO-N-K CMOS
Absolute Maximum Ratings
Features
CMOS logic output
Ceramic package
Space savings
Enable / Disable feature
Parameter
Supply voltage
Input voltage
Output voltage
Input current
Output current
Storage temperature
Soldering condition
Specifications
Parameter
Frequency
Frequency Stability
Operating Temperature
Supply Voltage
Supply Current
Input Voltage
Output Voltage
Symmetry
Rise/Fall time
Load Capacitance
Start-up time
*2 Rise time (0 to +2.97V) of Vcc
>
150µs
Symbol
V
cc
V
IN
V
O
I
IN
I
O
T
stg
T
sol
T
Rating
-0.5 to +7.0 V
-0.5 to V
cc
+0.5 V
-0.5 to V
cc
+0.5 V
±10 mA
±25 mA
-55 to +125
°C
+260°C / 20sec
or +230°C / 180sec
TCO-7086X1A
fo
∆f/fo
Topr
Vcc
Icc
V
IH
V
IL
V
OH
V
OL
Conditions
1.5 to 75 MHz
±50 ppm max.
0
°C
to +70
°C
+3.3 V ±10 %
20mA max.
V
IH
=70 % Vcc min. / V
IL
=30 % Vcc max.
V
OH
=90 % Vcc min. / V
OL
=10 % Vcc max.
40 to 60 %
6 ns max.
15 pF max.
10 ms max.
(*2)
DC
Vcc= +3.63V
#1:V
IH
or OPEN ... Enable
#1:V
IL
or GND ... Disable
I
OH
= -5mA, I
OL
=+5mA at Vcc=+2.97V
(*1)
SYM
tr/tf
CL
tst
at 50% Vcc
at 10% to 90% Vcc
*1 Inclusive of calibration tolerance at +25°C, operating temperature, operating voltage range.
Package Outlines
[Dimensions in mm]
7.0
±0.2
#4
#3
Model
Date Code
Test Circuit
See Test Circuit page TEST-4
Footprint
[Dimensions in mm]
1.8
#4
#3
5.0
±0.2
Marking
#1
#2
1.6
±0.2
4.2
2.0
Frequency
Denotes Lead#1 Location
Cby
#1
#2
5.08
Cby=0.1µF min.
1.4
±0.15
C0.5
LEAD
#1
#2
#3
#4
CONNECTION
E/D CONTROL
GND
OUTPUT
Vcc (DC)
5.08
±0.15
1.2
±0.13
(2002.12.)
