Probe Pin
XP3A
Electroplated Probe Pin for High
Reliability
• The Probe Pin is made of only one part.
• The flat structure helps you reduce the pin pitch in comparison
with standard probe pins.
• Separating the spring and relay achieves a stable resistance
and greater durability.
Features
■
Achieves the functions of four parts with one part
Standard Probe Pin
Plunger
Barrel
Electroformed Probe Pins
■
The electroformed Probe Pins use a flat structure.
This allows you to position the pins at any angle.
In comparison with round pins, these flat Probe Pins help you reduce
the pin pitch
Round Holes:
Standard Probe Pins
B: Pitch
Long Holes:
Electroformed Probe Pins
B’: Pitch
Spring
Plunger
(Cross-section diagram)
■
Separating the spring and relay achieves a
stable resistance and greater durability
A: Formed thickness
Relay
A: Formed thickness
Round hole pitch B > Long hole pitch B’
Round Hole formed thickness A = Long hole formed thickness A
Spring
■
Socket
Model
Appearance
XP3A-@@@@-@@@@D-R/S
XP3A-@@@@-@@@@D-S/S
XP3A-@@@@-@@@@D-D/S
XP3A-@@@@-@@@@D-T/S
■
Ratings and Characteristics
Rated current (see note)
Contact resistance (see note)
Contact force
Ambient operating temperature
0.25 A/pin
100 mΩ max./pin
15 g min.
−
25 to 85°C
■
Materials and Finish
Item
Contacts
XP3A
Nickel alloy/gold plating (1
μm)
Note:
The performance values are doubled for two pins.
Probe Pin
XP3A
1
XP3A - Top Terminal, R Shape
Dimensions
Mounting Hole Dimensions
t
±0.007
F
±0.025
(0.35)
C
±0.01
D
±0.01
0.05
(Bottom terminal)
(Top terminal)
E
±0.02
0.60
±0.01
B
±0.01
A
±0.01
R0.08
D
Round holes
T
Slits
W
Ordering Information - Standard Models
Probe Pins
Pitch
Round
Holes
Load
Slits
Overall Spring
Recom- Length Length
mended
Stroke
F
E
0.3
0.5
0.4
0.4
0.5
0.5
0.3
0.4
0.65
0.5
0.5
0.5
0.5
0.3
0.4
0.8
0.7
15 g
min.
0.5
0.5
0.5
0.5
0.3
0.4
1.0
0.8
0.5
0.5
0.5
0.5
0.3
0.4
1.2
1.0
0.5
0.5
0.5
0.5
4.15
4.95
5.95
6.95
2.95
4.25
5.15
6.15
7.15
2.45
3.05
4.35
5.15
6.15
7.15
2.45
2.95
4.35
5.15
6.15
7.15
2.45
2.95
4.35
5.15
6.15
7.15
3.2
4.0
5.0
6.0
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
0.9
0.975
0.75
0.826
0.828
0.827
0.826
0.825
0.976
0.92 dia.
0.1 x 0.92
0.08
0.2
0.77 dia.
0.1 x 0.77
0.58
0.665
0.2
0.655
0.6 dia.
0.1 x 0.6
0.07
0.46
0.535
0.48 dia.
0.1 x 0.48
0.15
0.38
0.455
0.06
0.4 dia.
0.1 x 0.4
Width
A
Width with
bypass
D
Thick-
ness
t
Lower
Contact
C
Upper
Contact
B
Recommended
Mounting Hole
Dimensions
Round
Slits
Holes
TxW
(Tolerance: (Tolerance:
±
0.01)
±
0.01)
Model
XP3A-3846-0642D-R/S
XP3A-3846-0650D-R/S
XP3A-3846-0660D-R/S
XP3A-3846-0670D-R/S
XP3A-4654-0730D-R/S
XP3A-4654-0742D-R/S
XP3A-4654-0750D-R/S
XP3A-4654-0760D-R/S
XP3A-4654-0770D-R/S
XP3A-5866-0725D-R/S
XP3A-5866-0730D-R/S
XP3A-5866-0742D-R/S
XP3A-5866-0750D-R/S
XP3A-5866-0760D-R/S
XP3A-5866-0770D-R/S
XP3A-7583-0825D-R/S
XP3A-7583-0830D-R/S
XP3A-7583-0842D-R/S
XP3A-7583-0850D-R/S
XP3A-7583-0860D-R/S
XP3A-7583-0870D-R/S
XP3A-9098-0825D-R/S
XP3A-9098-0830D-R/S
XP3A-9098-0842D-R/S
XP3A-9098-0850D-R/S
XP3A-9098-0860D-R/S
XP3A-9098-0870D-R/S
Probe Pin
XP3A
3
XP3A - Top Terminal, S Shape
Dimensions
Mounting Hole Dimensions
t
±0.007
F
±0.025
(0.35)
C
±0.01
D
±0.01
0.10
(Bottom terminal)
(Top terminal)
E
±0.02
0.60
±0.01
B
±0.01
A
±0.01
D
Round holes
T
Slits
W
Ordering Information - Standard Models
Probe Pins
Pitch
Round
Holes
Load
Slits
Overall Spring
Recom- Length Length
mended
Stroke
F
E
0.3
0.5
0.4
0.4
0.5
0.5
0.3
0.4
0.65
0.5
0.5
0.5
0.5
0.3
0.4
0.8
0.7
15 g
min.
0.5
0.5
0.5
0.5
0.3
0.4
1.0
0.8
0.5
0.5
0.5
0.5
0.3
0.4
1.2
1.0
0.5
0.5
0.5
0.5
4.15
4.95
5.95
6.95
2.95
4.25
5.15
6.15
7.15
2.45
3.05
4.35
5.15
6.15
7.15
2.45
2.95
4.35
5.15
6.15
7.15
2.45
2.95
4.35
5.15
6.15
7.15
3.2
4.0
5.0
6.0
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
0.9
0.975
0.75
0.826
0.828
0.827
0.826
0.825
0.976
0.92 dia.
0.1 x 0.92
0.08
0.2
0.77 dia.
0.1 x 0.77
0.58
0.665
0.2
0.655
0.6 dia.
0.1 x 0.6
0.07
0.46
0.535
0.48 dia.
0.1 x 0.48
0.15
0.38
0.455
0.06
0.4 dia.
0.1 x 0.4
Width
A
Width with
bypass
D
Thick-
ness
t
Lower
Contact
C
Upper
Contact
B
Recommended
Mounting Hole
Dimensions
Round
Slits
Holes
TxW
(Tolerance: (Tolerance:
±
0.01)
±
0.01)
Model
XP3A-3846-0642D-S/S
XP3A-3846-0650D-S/S
XP3A-3846-0660D-S/S
XP3A-3846-0670D-S/S
XP3A-4654-0730D-S/S
XP3A-4654-0742D-S/S
XP3A-4654-0750D-S/S
XP3A-4654-0760D-S/S
XP3A-4654-0770D-S/S
XP3A-5866-0725D-S/S
XP3A-5866-0730D-S/S
XP3A-5866-0742D-S/S
XP3A-5866-0750D-S/S
XP3A-5866-0760D-S/S
XP3A-5866-0770D-S/S
XP3A-7583-0825D-S/S
XP3A-7583-0830D-S/S
XP3A-7583-0842D-S/S
XP3A-7583-0850D-S/S
XP3A-7583-0860D-S/S
XP3A-7583-0870D-S/S
XP3A-9098-0825D-S/S
XP3A-9098-0830D-S/S
XP3A-9098-0842D-S/S
XP3A-9098-0850D-S/S
XP3A-9098-0860D-S/S
XP3A-9098-0870D-S/S
4
Probe Pin
XP3A
XP3A - Top Terminal, D Shape
Dimensions
Mounting Hole Dimensions
t
±0.007
F
±0.025
(0.35)
C
±0.01
D
±0.01
0.05
(Bottom terminal)
(Top terminal)
E
±0.02
0.60
±0.01
B
±0.01
A
±0.01
D
Round holes
T
Slits
W
Ordering Information - Standard Models
Probe Pins
Pitch
Round
Holes
Load
Slits
Overall Spring
Recom- Length Length
mended
Stroke
F
E
0.3
0.5
0.4
0.4
0.5
0.5
0.3
0.4
0.65
0.5
0.5
0.5
0.5
0.3
0.4
0.8
0.7
15 g
min.
0.5
0.5
0.5
0.5
0.3
0.4
1.0
0.8
0.5
0.5
0.5
0.5
0.3
0.4
1.2
1.0
0.5
0.5
0.5
0.5
4.15
4.95
5.95
6.95
2.95
4.25
5.15
6.15
7.15
2.45
3.05
4.35
5.15
6.15
7.15
2.45
2.95
4.35
5.15
6.15
7.15
2.45
2.95
4.35
5.15
6.15
7.15
3.2
4.0
5.0
6.0
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
1.5
2.0
3.2
4.0
5.0
6.0
0.9
0.975
0.75
0.826
0.828
0.827
0.826
0.825
0.976
0.92 dia.
0.1 x 0.92
0.08
0.2
0.77 dia.
0.1 x 0.77
0.58
0.665
0.2
0.655
0.6 dia.
0.1 x 0.6
0.07
0.46
0.535
0.48 dia.
0.1 x 0.48
0.15
0.38
0.455
0.06
0.4 dia.
0.1 x 0.4
Width
A
Width with
bypass
D
Thick-
ness
t
Lower
Contact
C
Upper
Contact
B
Recommended
Mounting Hole
Dimensions
Round
Slits
Holes
TxW
(Tolerance: (Tolerance:
±
0.01)
±
0.01)
Model
XP3A-3846-0642D-D/S
XP3A-3846-0650D-D/S
XP3A-3846-0660D-D/S
XP3A-3846-0670D-D/S
XP3A-4654-0730D-D/S
XP3A-4654-0742D-D/S
XP3A-4654-0750D-D/S
XP3A-4654-0760D-D/S
XP3A-4654-0770D-D/S
XP3A-5866-0725D-D/S
XP3A-5866-0730D-D/S
XP3A-5866-0742D-D/S
XP3A-5866-0750D-D/S
XP3A-5866-0760D-D/S
XP3A-5866-0770D-D/S
XP3A-7583-0825D-D/S
XP3A-7583-0830D-D/S
XP3A-7583-0842D-D/S
XP3A-7583-0850D-D/S
XP3A-7583-0860D-D/S
XP3A-7583-0870D-D/S
XP3A-9098-0825D-D/S
XP3A-9098-0830D-D/S
XP3A-9098-0842D-D/S
XP3A-9098-0850D-D/S
XP3A-9098-0860D-D/S
XP3A-9098-0870D-D/S
Probe Pin
XP3A
5
