RAS3 SERIES
INDUSTRIAL RELAYS
FEATURES
•
•
•
•
High contact capability.
Standard design and manufactured according to DIN IEC 225.
High anti–vibration performance.
Single and dual coil relay available.
OUTLINE DIMENSIONS / WIRING DIAGRAM /
MOUNTING HOLES – T TYPE
Unit: mm
TYPICAL APPLICATIONS
Electrical Equipment, Air Compressor, Industrial Machinery
ORDERING INFORMATION
RAS3
(1)
(1)
1
(2)
12
(3)
D
(4)
M
(5)
1
(6)
(5)
–M –XX
(7)
(8)
Contact Form
Nil
= Form C
M
= Form A
Coil Type
1
= Single Coil
2 = Dual Coils
Terminal Type
M
= Soldering
T = Screw Mounting
Special Parameter
Nil = Standard Type
Letter or Number
= Special
Requirement
Type Designation
RAS3
= RAS3 Series
Number of Poles
1
= 1 Pole
Coil Voltage (VDC)
05, 06, 09, 12, 15, 24, 48
Coil Power
L–single/dual
= 1.0W/2.0W
D–single/dual
= 1.5W/3.0W
(2)
(6)
(3)
(7)
(4)
(8)
COIL DATA (AT 20ºC)
Nominal
Voltage
(VDC)
5
6
9
12
15
18
24
48
Nominal
Dual Coil
Single Coil
Set
Reset
Pulse
Nominal
Operating
Resistance Resistance Voltage Voltage Duration Operating
Current
± 10% (Ω)
±10% (Ω)
(Max.)
(VDC)
(ms)
Power
± 10% (mA)
200
12.5
12.5
25
166.70
18
18
36
111
40.5
40.5
81
80% of 80% of
83
72
72
144
Single / Dual:
Nominal Nominal 20 Min.
1.0W / 2.0W
66.67
112.5 112.5
225
Voltage Voltage
55.56
162
162
324
41.70
288
288
576
20.8
1152 1152
2304
COIL DATA (AT 20ºC)
Nominal
Voltage
(VDC)
5
6
9
12
15
18
24
48
Nominal
Dual Coil
Single Coil
Set
Reset
Pulse
Nominal
Operating
Resistance Resistance Voltage Voltage Duration Operating
Current
± 10% (Ω)
±10% (Ω)
(Max.)
(VDC)
(ms)
Power
± 10% (mA)
200
8.68
8.68
17.36
167
12.5
12.5
25
111
28.12 28.12
56.25
80% of 80% of
83
50
50
100
Single / Dual:
Nominal Nominal 20 Min.
1.5W / 3.0W
67
112.5 112.5
225
Voltage Voltage
50
162
162
324
42
200
200
400
21
800
800
1600
WORLD PRODUCTS INC.
19654 Eighth Street East, Sonoma, CA 95476 | Phone (707) 996-5201 | Fax (707) 996-3380 | www.worldproducts.com
76
| Industrial Relays Catalog
Rev. 1.2 - 03.04.13
RAS3 SERIES
OUTLINE DIMENSIONS / WIRING DIAGRAM /
MOUNTING HOLES – M TYPE
Unit: mm
CONTACT CAPACITY
Model
Nominal Switching
Capacity (res. load)
Max. Switching
Current
Max. Switching Voltage
Max. Switching
Power
RAS3
25A 250VAC
25A
250VAC
6250VA
CHARACTERISTIC DATA
Contact Material
Initial contact resistance
(@ 6VDC 1A)
Operate time
(@ nominal voltage)
Release Time
(@ nominal voltage)
Initial insulation resistance
Initial dielectric strength
Silver Alloy
10mΩ Max.
10msec. Max.
10msec. Max.
1000M Ω Min. (DC500V)
Between open contacts: AC1500V, 50/60Hz 1 Min.
Between coil and contact: AC4000V, 50/60Hz 1Min.
Functional
Destructive
Functional
Destructive
Mechanical (@10,800 ops./h)
Electrical (@1,800 ops./h)
10 ~ 60Hz @ double amplitude of 1.5mm
10 ~ 60Hz @ double amplitude of 1.5mm
10G Min.
100G Min.
10,000,000
30,000
Vibration Resistance
Shock Resistance
Endurance
(operations)
Ambient Temperature
Unit Weight
–40ºC to +85ºC (no condensation)
Approximately 32.0 g
WORLD PRODUCTS INC.
19654 Eighth Street East, Sonoma, CA 95476 | Phone (707) 996-5201 | Fax (707) 996-3380 | www.worldproducts.com
Rev. 1.2 - 03.04.13
Industrial Relays Catalog |
77
