Features
• Efficient means of shipping or storing ESD sensitive circuit boards and
other items
• For physical protection, foam secures items, minimizing movement
and reduces stress from physical shock
• Pink static dissipative foam (1/2" thick, Rv < 1 x 10
4
< 1 x 10
11
ohms)
laminated to top, and conductive crosslink black polyethylene foam
(1/4" thick, Rv < 1 x 10
4
ohms) in bottom (All dimensions are ± 1/16")
• Impregnated corrugated static dissipative surface of 1 x 10
5
to
< 1 x 10
11
ohms per ANSI/ESD STM11.11 and IEC 61340-2-3
• No assembly required
• Custom foam configurations available
• Made in the United States of America
---
---
D
Item
37000
37008
37001
37003
37004
37006
Size I.D. - L x W x D
2-1/2 x 1-1/4 x 1
2-3/4 x 2-3/4 x 1
3-1/2 x 1-1/4 x 1
3-7/16 x 2-1/8 x 1
3-3/4 x 3-3/4 x 1
4-1/8 x 3-1/16 x 1
Item
37009
37002
37010*
37007
37005
37011*
Size I.D. - L x W x D
4-3/8 x 4-3/8 x 1
4-1/2 x 1-1/4 x 1
4-1/2 x 3-3/4 x 1
5-1/2 x 1-1/2 x 1
7 x 3-1/2 x 1
12-7/8 x 4 x 1
* These items made to order
---
---
---
---
---
L
-
Meets ANSI/ESD S20.20 and Packaging standard ANSI/ESD S541
---
---
W
Note:
These are inside Dimensions
Protektive Pak Impregnated Corrugated Specifications
Properties
Surface Resistance:
Static Shielding:
Typical Values
1 x 10
5
to < 1 x 10
11
ohms
99.9% attenuation at 10kV; 99.6% attenuation at 30kV
Test Procedures/Method
ANSI/ESD STM11.11
EIA 541, appendix E, capacitive probe test
Per Packaging standard ANSI/ESD section 6.2 Outside an EPA “Transportation of
sensitive products outside of an EPA shall require packaging that provides:
1. Low charge generation.
2. Dissipative or conductive materials for intimate contact.
3. A structure that provides electrostatic discharge shielding.”
Unless otherwise noted, tolerance is ±10%.
Specifications and procedures subject to change without notice.
Made in the
United States of America
Small Component Shippers
PROTEKTIVE PAK
13520 MONTE VISTA AVENUE, CHINO, CA 91710
PHONE (909) 627-2578
ProtektivePak.com
DRAWING NUMBER
37000
DATE:
April
2014
© 2014 DESCO INDUSTRIES INC.
Employee Owned
