5-440407-1: DescriptionCONNECTOR,D-SHELL,PCB MNT,PLUG,15 CONTACTS,SKT,0.109 PITCH,PC TAIL TERMINAL,#4-40; CategoryThe connector The connector; File Size103KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

5-440407-1 Overview

CONNECTOR,D-SHELL,PCB MNT,PLUG,15 CONTACTS,SKT,0.109 PITCH,PC TAIL TERMINAL,#4-40

5-440407-1 Parametric

Parameter Name	Attribute value
Objectid	302977064
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
Other features	CONNECTOR WITH 3 AUDIO JACK
body width	1.251 inch
subject depth	0.804 inch
body length	1.543 inch
Body/casing type	PLUG
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN/LEAD OVER NICKEL
Contact point gender	FEMALE
Contact material	COPPER ALLOY
contact mode	STAGGERED
Contact resistance	30 mΩ
Contact style	RND PIN-SKT
Dielectric withstand voltage	500VAC V
maximum insertion force	2.224 N
Insulation resistance	1000000000 Ω
insulator material	POLYETHYLENE
Plug contact pitch	0.109 inch
Match contact row spacing	0.112 inch
Installation option 1	#4-40
Installation option 2	SCREW
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	2.8448 mm
Plating thickness	FLASH inch
Guideline	UL, CSA
Shell surface	TIN LEAD
Shell material	STEEL
Terminal length	0.125 inch
Terminal pitch	2.7686 mm
Termination type	SOLDER
Total number of contacts	15
Evacuation force-minimum value	2.224 N

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

D-Subminiature C onnectors

Product Feature Selector

> Product Details

5-440407-1 Product Details

Live Product Chat

Stacked Connectors

Not re vie we d for R oHS C om plia nce

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5-440407-1

T E I nternal N umber: 5 - 4 4 0 4 0 7 - 1

Product Highlights:

C onnector C onfiguration [Upper C onn./Lower C onn.] =

Mixed

Receptacle over Audio Plug

Mating C onnector Lock Type = Female Screwlocks

Without Mating Polarization

No PC B Retention Feature

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Superseded

C ontact Product Information

C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

Additional Information:

Product Line Information
