MAX5500BGAP+T Overview

digital to analog converters - dac 12-bit 4ch precision dac

MAX5500BGAP+T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Maxim
Parts packaging code	SSOP
package instruction	SSOP, SSOP20,.3
Contacts	20
Reach Compliance Code	compli
Factory Lead Time	12 weeks
Is Samacsys	N
Converter type	D/A CONVERTER
Enter bit code	BINARY
JESD-30 code	R-PDSO-G20
JESD-609 code	e3
Maximum linear error (EL)	0.048%
Humidity sensitivity level	1
Number of digits	12
Number of functions	4
Number of terminals	20
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Encapsulate equivalent code	SSOP20,.3
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	225
power supply	5 V
Certification status	Not Qualified
Maximum slew rate	1.1 mA
Nominal supply voltage	5 V
surface mount	YES
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

19-4368; Rev 1; 4/09

Low-Power, Quad, 12-Bit

Voltage-Output DACs with Serial Interface

General Description

The MAX5500/MAX5501 integrate four low-power, 12-bit

digital-to analog converters (DACs) and four precision

output amplifiers in a small, 20-pin package. Each nega-

tive input of the four precision amplifiers is externally

accessible providing flexibility in gain configurations,

remote sensing, and high output drive capacity, making

the MAX5500/MAX5501 ideal for industrial-process-con-

trol applications. Other features include software shut-

down, hardware shutdown lockout, an active-low reset

which clears all registers and DACs to zero, a user-pro-

grammable logic output, and a serial-data output.

Each DAC provides a double-buffered input organized

as an input register followed by a DAC register. A 16-bit

serial word loads data into each input register. The seri-

al interface is compatible with SPI™/QSPI™/

MICROWIRE™. The serial interface allows the input and

DAC registers to be updated independently or simulta-

neously with a single software command. The 3-wire

interface simultaneously updates the DAC registers. All

logic inputs are TTL/CMOS-logic compatible. The

MAX5500 operates from a single +5V power supply,

and the MAX5501 operates from a single +3V power

supply. The MAX5500/MAX5501 are specified over the

extended -40°C to +105°C temperature range.

Features

Four 12-Bit DACs with Configurable Output

Amplifiers

+5V or +3V Single-Supply Operation

Low Supply Current:

0.85mA Normal Operation

10µA Shutdown Mode (MAX5500)

Force-Sense Outputs

Power-On Reset Clears All Registers and DACs

to Zero

Capable of Recalling Last State Prior to Shutdown

SPI/QSPI/MICROWIRE Compatible

Simultaneous or Independent Control of DACs

through 3-Wire Serial Interface

User-Programmable Digital Output

Guaranteed Over Extended Temperature Range

(-40°C to +105°C)

MAX5500/MAX5501

Ordering Information

PART

MAX5500AGAP+

MAX5500BGAP+

MAX5501AGAP+

MAX5501BGAP+

PIN-

PACKAGE

20 SSOP

INL (LSB)

±0.75

±2

±0.75

±2

SUPPLY (V)

Applications

Industrial Process Controls

Automatic Test Equipment

Microprocessor (μP)-Controlled Systems

Motion Control

Digital Offset and Gain Adjustment

Remote Industrial Controls

Denotes a lead(Pb)-free/RoHS-compliant package.

Note:

All devices are specified over the -40°C to +105°C operating

temperature range.

Pin Configuration appears at end of data sheet.

Functional Diagram

DOUT CL

PDL

DGND

AGND

REFAB

FBA

OUTA

FBB

OUTB

DAC B

FBC

OUTC

DAC C

FBD

OUTD

DAC D

DECODE

CONTROL

INPUT

DAC

DAC A

MAX5500

MAX5501

16-BIT

SHIFT

INPUT

DAC

INPUT

DAC

CONTROL

CS DIN SCLK

LOGIC

OUTPUT

UPO

INPUT

DAC

REFCD

SPI/QSPI are trademarks of Motorola, Inc.

MICROWIRE is a trademark of National Semiconductor, Corp.

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,

or visit Maxim’s website at www.maxim-ic.com.

MAX5500BGAP+T Related Products

	MAX5500BGAP+T	MAX5500AGAP+T	MAX5501AGAP+T	MAX5501BGAP+T
Description	digital to analog converters - dac 12-bit 4ch precision dac	digital to analog converters - dac 12-bit 4ch precision dac	digital to analog converters - dac 12-bit 4ch precision dac	digital to analog converters - dac 12-bit 4ch precision dac
Is it lead-free?	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to
Maker	Maxim	Maxim	Maxim	Maxim
Parts packaging code	SSOP	SSOP	SSOP	SSOP
package instruction	SSOP, SSOP20,.3	SSOP, SSOP20,.3	SSOP, SSOP20,.3	SSOP, SSOP20,.3
Contacts	20	20	20	20
Reach Compliance Code	compli	compli	compli	compli
Factory Lead Time	12 weeks	6 weeks	9 weeks	5 weeks
Is Samacsys	N	N	N	N
Converter type	D/A CONVERTER	D/A CONVERTER	D/A CONVERTER	D/A CONVERTER
Enter bit code	BINARY	BINARY	BINARY	BINARY
JESD-30 code	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20
JESD-609 code	e3	e3	e3	e3
Maximum linear error (EL)	0.048%	0.018%	0.018%	0.048%
Humidity sensitivity level	1	1	1	1
Number of digits	12	12	12	12
Number of functions	4	4	4	4
Number of terminals	20	20	20	20
Maximum operating temperature	105 °C	105 °C	105 °C	105 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SSOP	SSOP	SSOP	SSOP
Encapsulate equivalent code	SSOP20,.3	SSOP20,.3	SSOP20,.3	SSOP20,.3
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	225	225	225	225
power supply	5 V	5 V	3.3 V	3.3 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum slew rate	1.1 mA	1.1 mA	1.1 mA	1.1 mA
Nominal supply voltage	5 V	5 V	3.3 V	3.3 V
surface mount	YES	YES	YES	YES
technology	BICMOS	BICMOS	BICMOS	BICMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	MATTE TIN	MATTE TIN	MATTE TIN	MATTE TIN
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.635 mm	0.635 mm	0.635 mm	0.635 mm
Terminal location	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	1	1	1	1
