MINIATURE CERAMIC SMD CRYSTALS
CRYSTALS
FE / FH / FL
FEATURES
Low Cost
Low Profile
Miniature Package
3 Optional Footprints
Tape and Reel (2,000 pcs. STD)
The FE / FH / FL series provides a miniature profile in a resin sealed
ceramic package. These designs offer low cost and high reliability,
three land patterns, and are available in tape and reel.
FE / FH / FL STANDARD SPECIFICATIONS *
PARAMETERS
Frequency Range
Frequency Tolerance
Frequency Stability, ref @ 25ºC
Temperature Range
Operating
(T
OPR
)
Storage
(T
STG
)
Shunt Capacitance
(Co)
Load Capacitance
(C
L
)
Drive Level
Aging
CONDITIONS
Ta = 25ºC
Ta = -10ºC ~ +60ºC
MIN
7.3728
- 50
- 50
-10
-30
Customer Specified
7.3728 ~ 72.000 MHz
Ta = 25ºC; per year
10.0
-5.0
MAX
72.000
+ 50
+ 50
+60
+85
7.0
Series
0.5
+5.0
UNITS
MHz
PPM
PPM
ºC
pF
pF
mW
PPM
Frequency Range (MHz) Operating Mode Max ESR
W
80
Fundamental
7.3728 ~ 8.000
60
Fundamental
8.000+~ 16.000
Frequency Range (MHz) Operating Mode Max ESR
W
Fundamental
40
16.000+ ~ 32.000
60
3rd OT
28.000 ~ 67.000
* Other stabilities & operating temperature ranges available. Consult Fox Customer Service for specific requirements, or use crystal order form on page 6.
All specifications subject to change without notice. Rev. 03/02/00
Prefer red Design
Alter nate Designs
**
** Optional 1.4mm (MAX)
height available
All dimensions are in millimeters.
See page 31 for tape and reel specifications.
22
FOXElectronics
5570 Enterprise Parkway
Fort Myers, Florida 33905
941-693-0099
FAX 941-693-1554
http://www.foxonline.com
© 2000 FOX ELECTRONICS
