Ultra Low Jitter Crystal Oscillator 3.2 x 2.5mm
2.5V/3.3V CMOS XO
UX31/UX321
3.2 x 2.5mm Ceramic SMD
Package:
(Scale: none; dimensions are in mm)
Product Features
•
Ultra low phase jitter for 40G/100G systems
- 0.1ps RMS max. (12kHz to 20MHz), Category 1
- 0.2ps RMS max. (12kHz to 20MHz), Category 1
- 0.3ps RMS max. (12kHz to 20MHz), Category 2
Recommended Land Pattern:
•
Industrial Temperature Range
•
Pb-free & RoHS compliant
CREATED USING CADSTD LITE FREEWARE FROM WWW.CADSTD.COM. NON-COMMERCIAL USE ONLY.
Product Description
The UX31/UX321 XO series is a high
performance CMOS crystal oscillator family
with ultra low jitter performance. It supports
various options including wider frequency range,
1.8V/2.5V/3.3V voltage, and various stabilities.
It is designed to meet the clock source
specifications for communication systems, and
other high performance equipment.
*Extended high frequency power
decoupling is recommended (see test
circuit for minimum recommendation).
To ensure optimal performance, do not
route RF traces beneath the package.
Pin Functions:
Pin
Function
1
2
3
4
OE
Ground
Output
V
DD
Applications
•
Networking systems
•
Servers and storage systems
•
Profession video equipments
•
Test and measurement
•
FPGA/ASIC clock generation
Part Ordering Information Category 1:
UX31 XXX YYY
YYYY = Specification½Code
XXX = Frequency½Code
Product½Family
*Not for all frequencies in the
frequency range. Please contact
sales for details.
Part Ordering Information Category 2:
UX 32
1
V I FFFF.FFFFFF
A
B
C
Voltage:
1=+3.3V
2=+2.5V
3=+1.8V
Stability and Temp Range:
Stability
A = +/-20 ppm
B = +/-25 ppm
C = +/-50 ppm
D = +/-25 ppm
E = +/-50 ppm
Temp Range
-20/+70°C
-20/+70°C
-20/+70°C
-40/+85°C
-40/+85°C
Frequency:
FFFF.FFFFFF
MHz, “4 digits/decimal/6 digits” format
© Diodes Incorporated
A product Line of
Diodes Incorporated
•
US: +1-408-232-9100 TW: +886-3-4518888
16-0047
•
www.diodes.com
UX31/UX321 Rev B 08/19/16
1
All specifications are subject to change without notice.
2.5V/3.3V CMOS XO
UX31/UX321
Ultra Low Jitter Crystal Oscillator 3.2 x 2.5mm
Electrical Performance
Parameter
Min.
Typ.
Max.
Units
Notes
Output Frequency
Supply Voltage
Supply Current, Output Enabled
Supply Current, Output Disabled
Frequency Stability
Operating Temperature Range
Output Logic 0, V
OL
Output Logic 1, V
OH
Output Load
Duty Cycle
Rise and Fall Time
Jitter, Phase RMS (1-σ), Category 1
Jitter, Phase RMS (1-σ), Category 2
Jitter, pk-pk
50
3.135
2.375
1.71
3.3
2.5
1.8
156.25
3.465
2.625
1.89
25
10
±50
MHz
V
mA
uA
ppm
°C
V
V
pF
%
ns
ps
ps
ps
ps
Measured 50% V
DD
Measured 20/80% of waveform
12kHz to 20 MHz frequency band, See
ordering information category 1
12kHz to 20 MHz frequency band, See
ordering information category 2
100,000 random periods
See ordering options
See ordering options
See ordering options
-40
V
DD
-0.4
+85
0.4
15
45
55
5
0.1
0.2
0.3
40
Notes:
1. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance (25°C),
aging (1 year at 25°C average effective ambient temperature), shock and vibration.
2. For specifications othere than those listed, please contact sales.
Output Enable / Disable Function
Parameter
Min.
Typ.
Max.
Units
Notes
Input Voltage (pin 1), Output Enable
Input Voltage (pin 1), Output Disable (low power standby)
Internal Pullup Resistance
Output Disable Delay
Output Enable Delay
Start up Time
0.7 V
DD
0.3 V
DD
30
200
2
2
V
V
kΩ
ns
ms
ms
or open
Output is Hi-Z
Absolute Maximum Ratings
Parameter
Min.
Typ.
Max.
Units
Notes
Storage Temperature
-55
+125
°C
For the latest product information visit:
http://www.pericom.com/products/timing/oscillators/
For test circuit go to:
http://www.pericom.com/pdf/sre/tc_cmos.pdf
For soldering reflow profile and reliability test ratings go to:
http://www.pericom.com/pdf/sre/reflow.pdf
For tape and reel information go to:
http://www.pericom.com/pdf/sre/tr_3225_xo.pdf
© Diodes Incorporated
A product Line of
Diodes Incorporated
•
US: +1-408-232-9100 TW: +886-3-4518888
16-0047
•
www.diodes.com
UX31/UX321 Rev B 08/19/16
2
All specifications are subject to change without notice.
